Merloni Elettrodomestici 85510 Service Information

Creda rf panel heaters

Advertisement

Quick Links

Service
Information
© 2004 Reg. Office: Peterborough PE2 9JB Registered in London: 106725
Merloni Elettrodomestici UK Ltd
5411760 Issue 1
CREDA
RF PANEL
HEATERS
Models Covered:
400 mm High
85510
(800W) RF/E408
85520
(1000W) RF/E410
85530
(1200W) RF/E412
85540
(1500W) RF/E415
85550
(2000W) RF/E420
200 mm High
85610
(800W) RF/E208
85620
(1000W) RF/E210
85630
(1200W) RF/E212
85640
(1500W) RF/E215
400 mm High - IP24
85820
(600W) RF/E406S
85840
(1000W) RF/E410S
Feb. 2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 85510 and is the answer not in the manual?

Questions and answers

Summary of Contents for Merloni Elettrodomestici 85510

  • Page 1 85610 (800W) RF/E208 85620 (1000W) RF/E210 85630 (1200W) RF/E212 85640 (1500W) RF/E215 400 mm High - IP24 Service 85820 (600W) RF/E406S 85840 (1000W) RF/E410S Information Merloni Elettrodomestici UK Ltd © 2004 Reg. Office: Peterborough PE2 9JB Registered in London: 106725...
  • Page 2: Safety Notes & General Servicing Advice

    SAFETY NOTES & GENERAL SERVICING ADVICE 1 . This Manual is NOT intended as a comprehensive repair/maintenance guide to the appliance. It should ONLY be used by suitably qualified persons having technical competence, applicable product knowledge, and suitable tools and tests equipment. 2.
  • Page 3: Table Of Contents

    INDEX Safety Notes & General Servicing Advice ....... . . 2 Introduction .
  • Page 4: Technical Specification

    Comfort temperature 5 - 30°C Supply Fixing Model Rating Current Width Height Depth Centres Code Single Other (amps) (mm) (mm) (mm) (mm) Phase AC 85510 RF/E408 230-240V 85520 RF/E410 1000 230-240V 85530 RF/E412 1200 230-240V 85540 RF/E415 1500 230-240V 1095 85550 RF/E420 2000...
  • Page 5: Safety In Use

    OPTIONAL CONTROLLERS (Not supplied) • CredaZone 1 or 4 Remote controller requires 3 x AAA 1.5V alkaline batteries. (Battery lifetime 2 years.) Hand held or wall mounted. Note: - Requires CredaZone Receivers. • CredaZone Receiver Plug-in cartridge with integral thermostat back-up. Note: - Requires CredaZone 1 or 4 Controllers.
  • Page 6: Installation

    Cat. No. Watts 85610 800W 1095 85620 1000W 1275 1000 85630 1200W 1545 1270 85640 1500W 1725 1450 Cat.No Watts 85510 800W 85520 1000W 85530 1200W 85540 1500W 1095 85550 2000W 1365 1090 Cat.No Watts 85820 600W 85840 1000W Fig. 1...
  • Page 7: Wiring Diagram

    CONNECTING THE HEATER TO THE MAINS All heaters incorporate a 4 core mains cable. The heater must be connected to fixed wiring via a double pole isolating switch having a contact separation of 3 mm in each pole and in accordance with I.E.E. regulations currently in force and in accordance with any local code of practice.
  • Page 8: Setting The Controls

    SETTING THE CONTROLS Ensure that the appliance is securely fixed to the wall with the correct electrical connections made. Switch on the heater by pressing the switch A, and turn the thermostat dial (B) to 30 (max.). Red LED C should come on, indicating that the heater is on and working. When the required room temperature is reached, slowly turn the thermostat dial B backwards from the 30 until the light C goes out.
  • Page 9: Credasaver

    CREDASAVER CREDA PLUG-IN CONTROL MODULE (Optional) C = Mode Button D = Set / Pause Button E = Display F = Selected Mode Indicators G = Thermostat Knob Fig. 5 Credasaver Module Description The CREDASAVER is a timed control, which can be plugged into all Creda thermostat heaters, type 85**0.
  • Page 10 The 15 defined pre-programmes will be indicated as P0, P1, ..,P9, E1, E2, .., E5 in the display. Refer to the programme chart below and select one pre-programmed to suit the end user. Press the MODE key once more. The DAY (F) LED will light up and indicate that a weekday may be chosen.
  • Page 11 PROGRAMME HEATING PROFILES Fig. 7...
  • Page 12: Rf Receiver

    RF RECEIVER CREDAZONE PLUG-IN CONTROL MODULE Description The following RF Receiver plug-in module will operate Creda Panel heater types 855*0, 856*0 and 858*0 with thermostat control and must be controlled by one of the following central controllers: - CredaZone 1 or CredaZone 4. RF Receiver First Time Installation Switch the heater off.
  • Page 13: Installing & Setting The Credazone Controller

    INSTALLING & SETTING THE CREDAZONE CONTROLLER The following information is taken from the user instructions for the controller. CredaZone1 CredaZone4...
  • Page 14 CLOCK SETTING THE CREDAZONE1 & CREDAZONE4 Press the key and the value of the room temperature is displayed. CLOCK ADJUSTMENT By passing the 24.00 Hrs, the following day will display. Quick pressing of the keys gives 1 minute steps. Press and hold gives fast change. Remember: 1 = Monday;...
  • Page 15 Setting Frost Protection Temperature Setting the Set-Back Temperature...
  • Page 16 PROGRAMMING THE CREDAZONE CONTROLLER Week Programming...
  • Page 17: Quick Reference Chart For Fault Diagnosis

    QUICK REFERENCE CHART FOR FAULT DIAGNOSIS Heater is cold Safety Cut-out operated Reset Thermostat or controller set too low Adjust settings Heater switched off either at heater switch, local isolator or consumer unit Check and switch on Bad wiring connection Check wiring Supply failure Check electrical supply...
  • Page 18: Dismantling Procedure

    DISMANTLING PROCEDURE ALWAYS ISOLATE THE HEATER FROM THE ELECTRICAL SUPPLY/SUPPLIES before undertaking any maintenance work. As Tele-switching of off peak supplies becomes more common, and the times at which off peak supplies are available varies, it is essential that the off peak consumer unit as well as the adjacent isolator switch are both switched off prior to servicing the heater.
  • Page 19 Prise the 2 plastic, thermostat-securing lugs apart, and lift the thermostat from the plastic bracket. Note the orientation of the thermostat to ensure new unit is fitted back in the same way. Remove the 2 terminals from the old thermostat and fit the new unit in the same way. If enhanced access is required the plastic housing can be removed by pulling the top edge towards you, and twisting the housing anti-clockwise through 45°.
  • Page 20 For spare parts contact: Applied Energy Products Ltd. National Spares Line: 08700-102829...

This manual is also suitable for:

855208553085540855508561085620 ... Show all
