Summary of Contents for Ekckom XC8602JE
- Page 1 XC8602JE Optical Receiver Manual 2013. Version 2013. （ Version ） （ ）...
- Page 2 Manual 1. Product Summary XC8602JE outdoor optical receiver is our latest 1GHz optical receiver. With wide range receiving optical power, high output level, low power consumption and compact structure, easy to install. It is the ideal equipment to build the high-performance NGB network.
- Page 3 XC8602JE 8602JE 8602JE Optical Optical Optical Receiver Receiver Receiver Manual Manual Manual General Characteristics Power Voltage A: AC (150~265) V B: AC (35~90) V Operating Temperature -40~60 ℃ Consumption ≤14 Dimension 220（L）* 205（W）* 65（H） Note: The forward RF indexes above are tested when adopt NEC module. Use other module, the indexes will be a little different.
- Page 4 XC8602JE 8602JE 8602JE Optical Optical Optical Receiver Receiver Receiver Manual Manual Manual 6. Structure Description 1. Working indicator 2. Optical receiving port 3. LED digital display tube (or external, optional) 4. Enter key 5. Down key 6. Up key 7. Power Interface 8.
- Page 5 XC8602JE 8602JE 8602JE Optical Optical Optical Receiver Receiver Receiver Manual Manual Manual 7. Function Display and Operating Instruction Mode: Mode selection button, total twelve modes, press the mode selection button to enter the corresponding status display, twelve modes to cycle.
- Page 6 XC8602JE 8602JE 8602JE Optical Optical Optical Receiver Receiver Receiver Manual Manual Manual 8. NMS setup instructions If users configured the network management responder, need to do the following settings: Responder IP setup instruction: Network management directly modify: Default IP is 192.168.1.168 ， default gateway is 192.168.1.1 ， default subnet mask is 255.255.255.0...
- Page 7 XC8602JE 8602JE 8602JE Optical Optical Optical Receiver Receiver Receiver Manual Manual Manual 9. Common Failure Analysis and Troubleshooting Failure phenomenon Failure cause Solution 1. Check the input optical power and make After connecting the 1. The input optical power of the...
- Page 8 XC8602JE 8602JE 8602JE Optical Optical Optical Receiver Receiver Receiver Manual Manual Manual After connecting the 1. Check the type of optical fiber active network, the received The optical fiber active connector connector and adopt the APC type optical optical power of the optical...
