http://www.tyentusa.com
The user should be responsible for failure or
improper selection or improper use of the
products such as use in any manner for which
the product was not originally intended.
This product is subject to changes that enhance
its performance without prior notification.
Tyent does not assume any responsibility for
users' negligent or improper use of the product.
pH Chart
How to Measure: Place 10-15 mL of test water in a container
and add 2-3 drops of reagent. Then mix well and check the
color of the water with the pH chart above.
(The color depends on water quality and reagent.)
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
This appliance is not intended for use by persons (including
children) with reduced physical sensory or mental capabilities
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
MADE IN KOREA
W A T E R
I O N I Z E R
User Manual
This product is intended for domestic use only.
Keep this user manual handy for easy reference.
Carefully read this User Manual, particularly "all safety warnings."

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ace YT20-TL Series and is the answer not in the manual?

Questions and answers

Susan Foster
August 9, 2025

There is no water coming out of the lower hose.

User image 689691c7b4eaa
1 comments:
Mr. Anderson
September 10, 2025

Possible causes of no water coming out of the lower hose on a Tyent YT20-TL Series include:

1. Hose not firmly seated in the unit holes or connections.
2. Water supply not connected properly to the inflow (cold water) source.
3. Water pressure too low—may require a pressure pump or larger hose.
4. Source water temperature exceeds 95℉ (35℃), triggering an automatic stop.
5. Unit powered off or not plugged in.
6. Automatic water discharge interruption after 15 minutes of use.
7. Valve turned off or water line connected to a hot water supply, which is not allowed.

This answer is automatically generated

Summary of Contents for Tyent Ace YT20-TL Series

  • Page 1 This product is subject to changes that enhance its performance without prior notification. Tyent does not assume any responsibility for users' negligent or improper use of the product. pH Chart How to Measure: Place 10-15 mL of test water in a container and add 2-3 drops of reagent.
  • Page 2: Table Of Contents

    Table of contents o Our Valued Customers able of Contents Thank you for purchasing the Tyent Ace YT20-TL series Water Ionizer. To Our Valued Customers Please read all safety warnings and this User Manual carefully before using this product Table of Contents to ensure proper product usage.
  • Page 3: Before Usage

    Before Usage Safety Precautions and Warnings efore Usage afety Precautions and Warnings Safety precautions are provided for the safe and proper use of this unit and can prevent danger, bodily harm and/or possible damage due to misuse. Please make sure you are Regarding the Power Supply familiar with all the safety precautions and warnings associated with this unit.
  • Page 4 Safety Precautions and Warnings Safety Precautions and Warnings Only use the unit with the correct voltage. All units sold within North America are made to be plugged into 115 Place this product near a sink and always allow the Volt outlets only. Do not plug unit into an outlet outside water to drain into the sink.
  • Page 5 Safety Precautions and Warnings Safety Precautions and Warnings Cleaning Do not place any objects on top of this unit no matter how small they are. Do not store the unit near chemicals, food, metals or medication If water leaks out of the unit (other than the Turn off hoses) or if the unit is standing in a puddle of Do not spray water on the main unit.
  • Page 6: Product Features

    Product Features Product Features roduct Features FULL TOUCH LCD – TRANSFORMATION AT YOUR FINGERTIPS Electrodes with Solid/Mesh Hybrid Technology These platinum-coated titanium plates are made with highly stable, durable Solid/Mesh Hybrid Technology that enhances The Industry’s First Full Touch Screen Panel the instantaneous electrolysis effect.
  • Page 7 Product Features Product Features roduct Features SELF-MAINTENANCE MADE EASY – FROM INSTALLATION TO AFTER SERVICE Automatic Electrolysis Tank Cleaning Function The interior of the electrolysis tank is automatically cleaned on a regular basis, ensuring stable electrolysis operating condi- tions. Filter Usage Indication and Replacement Time Guide The level of filter usage can be identified through the LCD screen on a real-time basis.
  • Page 8: Package Contents

    Package Contents Unit Overview ackage Contents nit Overview Make sure you are familiar with the parts and features of this unit, and carefully read the user manual and other important information 8.2 ft (2.5 m) of Hose Front View 2 Tube Suction Cups Water Outlet Unit Front Cover 1 Water Outlet Tube...
  • Page 9: How To Install The Unit

    How to Install the Unit How to Install the Unit ow to Install the Unit Option B – Under-Sink Installation Determine whether you will connect the unit directly to the cold water supply line (under sink) or to the faucet (see image). Option A l Faucet: A faucet connection requires a faucet diverter (included).
  • Page 10: Water Hose Installation

    Water Hose Installation Water Hose Installation ater Hose Installation 5. Cut an appropriate length of drain hose and connect 1. Place the unit on the planned installation location and it to the drain on the rear of the unit.Make sure the Drain hose to sink screw the flexible tube clockwise into the water outlet...
  • Page 11: Customer Serviceable Parts

    Customer Serviceable Parts How to Change the Filters ustomer Serviceable Parts ow to Change the Filters ATTENTION: The consumer accepts any and all responsibility and/or liability if replacement filters and/or purchased parts are not manufacturer specific. This unit contains high-performance purifying filters and an advanced control system. Shut off the water supply to the unit.
  • Page 12: How To Reset The Filters

    How to Reset the Filters Operation of the Touch Screen ow to Reset the Filters peration of the Touch Screen Standby mode Home screen Set up Alkaline water A L K A L K F1 RESET F1 RESET : Filter 1 reset A L K A C D Voice on...
  • Page 13 Operation of the Touch Screen Operation of the Touch Screen Menu window LCD Display Push the upper part of the LCD screen. The menu window will appear on the LCD screen. 09:30a Selected mode Setup (page 31) 15:00 Auto flow stop time indicator 알칼리...
  • Page 14: When Using The Touch Screen

    Operation of the Touch Screen When using the Touch Screen hen using the Touch Screen Message Display Alkaline water out ow FILTER REPL. OUTFLOW STOP Press the “ALK” icon on the Home screen. A L K A C D TURBO When this image is displayed, it is After you suspend the water supply to time to replace the filters (p.
  • Page 15 When using the Touch Screen When using the Touch Screen Acidic water out ow Puri ed water out ow Press the ACD icon on the Home screen. Press the H O icon on the Home screen. A L K A L K A C D TURBO A C D...
  • Page 16: Ph Level Adjustment

    H Level Adjustment System Setup Method H Level Adjustment ystem Setup Method ALKALI H Level Adjustment Press the top left corner of the screen. The menu pH Chart options will fall below the upper part of the screen. 알칼리 산 성 Press the setup icon.
  • Page 17 System Setup Method System Setup Method 2 ACIDIC H Level Adjustment 3 LANGUAGE Mode Press the top left corner of the screen. The Press the top left corner of the screen. The menu options will fall below the upper part menu options will fall below the upper part of the screen.
  • Page 18 System Setup Method System Setup Method 4 VOLUME Level Adjustment 5 Setting the TIME Press the top left corner of the screen. The Press the top left corner of the screen. The menu options will fall below the upper part menu options will fall below the upper part of the screen.
  • Page 19: Selecting Voice On/Off

    Selecting Voice ON/OFF Cleaning Function electing Voice ON/OFF leaning Function Cleaning can take place automatically and/or manually. Press the top left corner of the screen. The menu options will fall below the upper part of Auto Cleaning (15 seconds) is performed during water outflow after more than 24 hours of non-operating or after 30 liters of water outflow.
  • Page 20: Eco Mode

    ECO Mode TURBO Function CO Mode URBO Function ECO Mode is a feature to indicate the time on the display during periods of nonuse. The TURBO function allows you to create strong alkaline and acidic water. These types of water are ONLY to be used for cleaning, sanitizing and disinfecting purposes. Press the top left corner of the screen.
  • Page 21: Usage Recommendations

    Usage Recommendations Usage Recommendations sage Recommendations 15:00 15:00 15:00 05:00 1st Alkaline Water 2nd Alkaline Water Clean Water TURBO Function (Drinking Level 1) (Drinking Level 2) DO NOT DRINK. Strong acid/ Creates puri ed water. For taking alkaline water that must be Suitable for initial stage of drinking Suitable for regular drinking medications and making baby formula...
  • Page 22: Temperature Sensor

    14:39 Water Cell Plate platinum and titanium will flow. Materials ※To ensure the highest functionality, Tyent reserves 11.8 (W) x 5.3 (D) x 13.9 (H) inches Product Size the right to make changes to the system without notice. 10.8 lbs Product Weight ※To make the best functionality, there may be some change without notices.
  • Page 23: Troubleshooting

    troubleshooting memo roubleshooting Symptoms Checkpoints Measures to be Taken Run the unit for one minute, draining Check period of use. stagnant water. Abnormal Taste Check the last time the lter was replaced. Replace the lter. Check whether the valve on the water Open the Valve.
  • Page 24: Product Warranty

    4. This warranty is non-transferable and valid only for the original owner. Product Name Model Number Warranty Period Lifetime ACE-YT20-TL Tyent Water Ionizer (above conditions apply) Customer’s Name/Phone Date of Purchase Customer’s Address Installation Date/Name Tyent USA,LLC 137 Hur ville Crosskeys Rd, Sewell, NJ 08080 Toll Free: 855-TYENT-US www.tyentusa.com...
