Installing the
PLEASE READ CAREFULLY BEFORE STARTING INSTALLATION. Anyone with a ladder and a
few hand tools can easily do the job in an hour or two. If you prefer not to install the instrument
yourself, your television serviceman or electrician can do it for you. Regardless of who does the
installation, the owner should become familiar with these instructions. Incorrect installation or misuse
will shorten the life of the product and impair its performance.
Cape Cod
®
The
connected by wire to an indicator dial indoors. The cup-type anemometer generates power varying with
the speed of the wind, and the dial electrically measures this power. The Peak Gust Register circuit
operates 24 hours/day, powered by a small 3-watt AC/DC adapter plugged into a regular household outlet.
WIND
DIRECTION
TRANSMITTER
peak (Fig. 2), where a free flow of wind will be obtained from all
directions. The mounting assembly can be adjusted to accommo-
date any roof pitch. The 1" lag screws provided are for wooden
ridge boards; longer 2"x¼" lag screws should be used for asphalt
shingle ridge caps. (The mounting bracket can be super-imposed
over that of the wind direction indicator, aligning the two lag screw
holes, for a simpler and more compact roof installation; Fig. 1.) The
transmitter can be mounted on a chimney, if necessary, using lead
screw anchors, or it can be elevated further on a TV antenna mast
(send $5 to the address below for a "V"-bolt and bent pipe support
LOCK WASHER
BASE
FITTING
3/8" HEX NUT
Cape Cod
fitted with optional
Wind Speed Indicator consists of a wind-driven electrical generator outdoors,
Install this instrument and the
at the same time, if you have both, to take advantage of several
simplifications in the combined installation (Fig. 1).
WIND
SPEED
1. Place the cupwheel on the generator shaft with care, and securely
TRANSMITTER
tighten the set-screw. When tightening the set-screw, turn the unit
upside down and grasp the cupwheel hub, not the generator
housing, to avoid overloading the shaft and the self-aligning bear-
ings.
After
cupwheel and generator, thread
the mounting pipe into the
bottom of the generator. Mount
the transmitter with the lag
screws provided, a couple of
Fig. 1
inches in from the end of the
ridge on top of the highest roof
for offset mounting on your TV
mast).
Fig. 3
BRACKET
Always keep the transmitter upright, with the cupwheel in place
when out in the weather, to prevent water from entering the
generator. Be sure the toothed lock washer remains located between
the
bracket
MAINTENANCE below.
®
Wind Speed Indicator
Peak Gust Register
Cape Cod
assembling
the
and
the
mounting
®
Wind Direction Indicator
CUPWHEEL
SET-SCREW
GENERATOR
MOUNTING
PIPE
Mount on top,
at the end of
highest ridge
Fig. 2
fitting
(Fig.
3).
Note
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for cape cod CCWSP
Summary of Contents for cape cod CCWSP
- Page 1 Cape Cod ® Installing the Wind Speed Indicator Peak Gust Register fitted with optional PLEASE READ CAREFULLY BEFORE STARTING INSTALLATION. Anyone with a ladder and a few hand tools can easily do the job in an hour or two. If you prefer not to install the instrument yourself, your television serviceman or electrician can do it for you.
- Page 2 2. Solder and tape one end of the 50' coil of wire to the wire leads from the generator coming out the bottom of the pipe. (If installing the wind direction indicator at the same time, the spare pair of twisted gray wires in the direction cable can be used instead, thus eliminating the need to run a separate wire.) Carefully stapling the wire every foot or so, run it down the building trim to the point on the outside wall opposite the indoor location chosen for the dial.
