BENECOM BNC-15T-IP User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
B
N
C
-
1
B
N
C
-
1
U
s
e
r
G
U
s
e
r
G
5
T
-
I
P
5
T
-
I
P
u
i
d
e
u
i
d
e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BNC-15T-IP and is the answer not in the manual?

Questions and answers

Summary of Contents for BENECOM BNC-15T-IP

  • Page 3: Introduction

    BENECOM co., Ltd. Corporation 2007. All right reserved. Disclaimer BENECOM shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from using this material, or the performance or use of this product.

  • Page 4: General Guideline

    BNC-15T-IP User Guide General Guideline 1. Read all of these instructions. 2. Save these instructions for future use. 3. Follow all warnings and instructions marked in the computer. 4. Except as explained elsewhere in this Installation Guide, do not attempt to service the computer yourself. Opening or removing covers that are marked “Do Not Remove”...
  • Page 5 BNC-15T-IP User Guide must not be blocked or covered. The product should never be placed near or over a radiator or heat register, or in a built-in installation unless proper ventilation is provided. 8. This product should be operated from the type of power indicated on the marking label.

  • Page 6: Thermal Restrictions

    BNC-15T-IP User Guide in damage and will often require extensive work by a qualified technician to restore the product to normal condition. • If the product has been dropped or the cabinet has been damaged. • If the product displays a distinct change in performance, indicating a need for service.

  • Page 7: Requirements

    BNC-15T-IP User Guide WARNING: Do not attempt to service the computer yourself. Opening or removing covers might expose you to dangerous voltage points or other risk, have a qualified person repair it. WARNING: Keep hair, loose clothing, fingers, and all parts of body away from openings, moving parts and fan.

  • Page 8: Power Cord Set Requirements

    BNC-15T-IP User Guide ♦ The power cord set must have a minimum current capacity of 10A and a normal voltage rating of 125 or 250 volts AC, as required by each country’s power system. ♦ The appliance coupler must meet the mechanical configuration of an EN 60320.
  • Page 9 BNC-15T-IP User Guide French IL Y A DANGER D'EXPLOSION S'IL Y A REMPLACEMENT INCORRECT DE LA BATTERIE. REMPLACER UNIQUEMENT AVEC UNE BATTERIE DU MÊME TYPE OU D'UN TYPE RECOMMANDÉ PAR LE CONSTRUCTEUR. METTER AU RÉBUT LES BATTERIES USAGÉES CONFORMÉMENT AUX INSTRUCTIONS DU FABRICANT.

  • Page 10: Fcc Information

    BNC-15T-IP User Guide Vaihda paristo ainostaan laitevalmistajan suosittelemaan tyyppiin. Hävitä käyteet paristo valmistajan ohjeiden mukaisesti. WARNING: The following caution statement is located in the service and operating Installation Guide or on the label adjacent to the battery. FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 11: Television Antenna Connectors Protection (For System Tv Tuner Card)

    BNC-15T-IP User Guide classification label (shown below) is location on the drive. Class 1 laser product Caution: invisible laser radiation when open. Do not stare into beam. Caution: Use to any controls or adjustments or procedures other than those specified herein may result in hazardous radiate exposure.
  • Page 12 BNC-15T-IP User Guide Lightning protection For added protection of any product during a lightning storm or when it is left unattended or unused for long periods of time, unplug the product from the wall outlet and disconnect the antenna or cable system.
  • Page 13 BNC-15T-IP User Guide Headphones, Headsets or Earphones WARNING: Continuously listening to music at very high volumes and for extended durations, can cause hearing damage. In order to reduce the risk of damage to hearing, user should lower the volume to a safe, comfortable level, and avoid listening at very high volume, Headsets should comply with EN 50332-2 requirements.

  • Page 14: Table Of Contents

    BNC-15T-IP User Guide Table of Contents Introduction ................1 Copyright ....................1 Disclaimer ....................1 Trademarks ....................1 General Guideline ..................2 Restrictions ....................2 Installation Restrictions ................2 Thermal Restrictions .................. 4 Safety instructions ..................4 Requirements ....................5 General Requirements ................
  • Page 15 BNC-15T-IP User Guide Chapter 2 System Setup ............24 2.1. Exploring Your Panel PC ..............24 2.2. Prepairing for first time use .............. 26 2.3. Installation Procedures ..............26 2.4. Installation System Software ............30 2.5. Installing the drivers ................30 Chapter 3 Using the Panel PC ..........
  • Page 16 BNC-15T-IP User Guide Memo www.benecomc.co.kr...

  • Page 17: Chapter 1 General Information

    BNC-15T-IP User Guide General Information BNC-15T-IP is an Intel® Celeron M processor based Panel PC with a bright 15" LCD display. The powerful Celeron M CPU and Intel 910GMLE/ ICH6M chipsets bring the most dynamic applications to life without sacrifices to any industrial reliability.

  • Page 18: Specification

    BNC-15T-IP User Guide The BNC-15T-IP flat panel PC is a flexible, multi-functional flat panel PC. With following specifications that can be applied in diverse operational environments and implemented in multi-faceted applications. 1.2.1. System Specification CPU: Embedded Intel® Celeron-M Processor 1.0GHz Secondary Cache: 512KB System Chipset: Intel®...
  • Page 19 BNC-15T-IP User Guide Luminance (cd/m²): 400 cd/m² Viewing Angle: 60° (left), 60° (right), 60° (up), 60° (down) Operating Temperature: 0℃~70℃ Lamp Life Time: 50,000 hours 1.2.3. Touch Screen Touch Screen type: 5-wire Analog resistive type Light Transmission: 80% Durability (Touch lifetime): 35 million 1.2.4.
  • Page 20 BNC-15T-IP User Guide Power Input Voltage: Support wide range DC 12V~24V input voltage Power Adapter: AC to DC, DC19V / 4.72A, 65W Power Button: 1 x Power Button LED: Power / HDD LEDs 1.2.7. Environment Dimensions: 372 x 292 x 60.6 mm Temperature: Operating: 0°C ~ 50°C / Storage: -20°C ~ 70°C...
  • Page 21 BNC-15T-IP User Guide 1.2.9. Software Software Support: Microsoft Windows XP Professional, XP Embedded. 1.2.10. Certifications EMI/EMS: Meet the CE and FCC class B regulation RoHS: RoHS compliant www.benecom.co.kr...
  • Page 22 BNC-15T-IP User Guide The following sections provide information for the BNC-15T-IP dimensions. Dimensions (units in mm) www.benecomc.co.kr...
  • Page 23 BNC-15T-IP User Guide www.benecom.co.kr...
  • Page 24 BNC-15T-IP User Guide Panel Mounting Instruction www.benecomc.co.kr...
  • Page 25 BNC-15T-IP User Guide THIS PAGE IS INTENTIONALLY LEFT BLANK www.benecom.co.kr...

  • Page 26: Chapter 2 System Setup

    BNC-15T-IP User Guide System Setup Before starting to set up the panel PC, take familiar with the locations and purposes of controls, drives, connectors and ports, which are illustrated in the figures below. When placed upright on the desktop, the front panel of the panel PC appears as shown in Figure 2.1.
  • Page 27 BNC-15T-IP User Guide Lineout e-SATA USB3 COM2 USB1 COM1 USB2 10 DC12-24 Lineout Port Lets you plug in a stereo headphone or powered speakers. e-SATA Port Lets you plug in an e-SATA HDD device. USB Ports (x3) The Universal Serial Bus (USB) port allows you to connect USB 2.0-compliant devices (for example, printers, scanners and so on)

  • Page 28: Prepairing For First Time Use

    BNC-15T-IP User Guide COM1 Port Your Panel PC is fitted with a COM port to enable connection of a serial device such as a modem or mouse. COM2 Port Lets you connect a 9-pin external serial device such as a modem, mouse, or other serial devices.
  • Page 29 BNC-15T-IP User Guide To connect the power cord: 1. Plug the AC power cord into the power socket of the AC power adapter. 2. Plug the other end of the AC power cord to a live AC wall outlet. 3. Plug the connector of the AC adapter to the DC-IN port found at the bottom side of the Panel PC.
  • Page 30 BNC-15T-IP User Guide 2.3.2. Connecting the keyboard and mouse A keyboard is an input device; a mouse is a pointing device. Please connect these two devices as graphics shown below to interact with your panel PC. 2.3.3. Switching on the power The Power button is found on the left bottom on the rear side of the Panel PC.
  • Page 31 BNC-15T-IP User Guide www.benecom.co.kr...

  • Page 32: Installation System Software

    CD-ROM disc entitled "Drivers and Utilities”. The CD-ROM can be found in your accessory box. follow the procedures below The drivers and utilities used for the BNC-15T-IP Panel PC are subject to change without notice. www.benecomc.co.kr...
  • Page 33 BNC-15T-IP User Guide www.benecom.co.kr...

  • Page 34: Chapter 3 Using The Panel Pc

    BNC-15T-IP User Guide Using the Panel Your panel PC is designed and pre-configured for easy setup and use. This chapter describes the installation steps you should follow to get the system up and running as quickly as possible. This chapter describes the basic features and procedures for using the panel PC.

  • Page 35: Using The Serial Ports (Com)

    BNC-15T-IP User Guide There are two serial COM ports on the bottom. It is simple to attach a serial device to the panel PC, like an external modem or mouse. Please follow these instructions below for connecting : 1. Be sure the panel PC and any other peripheral devices that are connected to the panel PC are turned off.

  • Page 36: Using The Vga Port

    BNC-15T-IP User Guide An external VGA-compatible device may be connected to the system through the 15-pin external port located on the bottom of the system unit. The panel PC simultaneously supports an external CRT monitor in addition to the built-in LCD display.

  • Page 37: Using The Usb Ports

    BNC-15T-IP User Guide An external USB device may be connected to the system through the 4-pin USB ports located on the bottom side of the system unit. 1. Connect the external device to the system. 2. The USB ports support hot plug-in connections. Install the device driver before using the device.

  • Page 38: Using The Lan Port

    BNC-15T-IP User Guide To connect to an audio jack: 1. Locate the audio port (Headphone or powered speaker) that you want to use to the target device. 2. Plug the jack into the port at the bottom side of the system.
  • Page 39 BNC-15T-IP User Guide be up to 100Mbps. The 10Base-T standard also called Twisted Pair Ethernet is connected with RJ-45 connectors. The 100Base-TX is based on the older Ethernet standard. Because it is 10 times faster than Ethernet, it is often referred to as Fast Ethernet. The built-in LAN module provides a standard RJ-45 connector.

  • Page 40: Touchscreen

    BNC-15T-IP User Guide BNC-15T-IP is designed using Color Active Matrix LCD technology with a high quality touch sensitive surface. The touchscreen is a display that can detect the presence and location of a touch within the display area by a finger, hand or other passive objects, such as a stylus.

  • Page 41: Chapter 4 The Bios Setup Program

    BNC-15T-IP User Guide The BIOS Setup Program This system comes with a chip from Award BIOS that contains the ROM Setup information for your system. (This chip serves as an interface between the processor and the rest of the system components.) This section explains the information contained in the Setup program and tells you how to modify the settings according to your system configuration.
  • Page 42 BNC-15T-IP User Guide Standard CMOS Features This option lists all the features for standard CMOS configuration. Advanced BIOS Features This option lists all the features for advanced BIOS configuration. Advanced Chipset Features This option lists all the features for advanced chipset configuration.

  • Page 43: Standard Cmos Features

    BNC-15T-IP User Guide Frequency/Voltage Control This option lists CPU host clock control, frequency ratio and voltage. Load Fail-Safe Defaults This option allow users to restore all of the BIOS settings to the default Fail-Safe values. The Fail-Safe Defaults are the default values set by the BIOS vendor for stable system performance.
  • Page 44 BNC-15T-IP User Guide Date To set the date, highlight the Date field and then press PgUp/PgDn or +/- keys to set the current date. Follow the week, month, day and year format. Time To set the time, highlight the Time field and then press PgUp/PgDn or +/- keys to set the current time.
  • Page 45 BNC-15T-IP User Guide BIOS CMOS Setup Utility will detect and configure had disk parameter automatically by pressing this item. IDE Channel 0 Master: Options are: None, Auto and Manual. Access Mode: Options are: CHS, LBA, Large and Auto. Capacity: The hard disk size. The unit is Bytes.

  • Page 46: Advanced Bios Features

    BNC-15T-IP User Guide Extended Memory This field displays the amount of extended memory (above 1 MB in CPU ís memory address map) installed in the system. Total Memory This field displays the total system memory size. CPU Feature This item allows the user to adjust CPU settings.
  • Page 47 BNC-15T-IP User Guide system or allow the user to select the boot sequence for system devices. Virus Warning This item allows you to choose the Virus Warning feature for IDE hard Disk boot sector protection. If this function is enabled and someone attempt to write data into this area, BIOS will show a warning message on screen and alarm beep.
  • Page 48 BNC-15T-IP User Guide Gate A20 Option This item allows the user to control the Gate A20 by chipset or keyboard controller with setting the option to Fast or Normal. Typematic Rate Setting This item allows you to activate or close the "Typematic Rate Setting"...

  • Page 49: Advanced Chipset Feature

    BNC-15T-IP User Guide DRAM Timing Selectable This item allows you to set the optimal timings. The system default setting is "By SPD". CAS Latency Time This item allows you to set the timing delay in clock cycles before SDRAM starts a read command.
  • Page 50 BNC-15T-IP User Guide DRAM RAS# Precharge This item allows you to set the DRAM RAS# precharge timing. Precharge delay (tRAS) This item allows you to adjust memory precharge time. System Memory Frequency This item allows you to adjust memory frequency to improve performance.

  • Page 51: Integrated Peripherals

    BNC-15T-IP User Guide OnChip IDE Device This item enables users to set the OnChip IDE device status, including IDE devices and setting PIO and DMA access modes. Some chipsets support newer SATA devices (Serial-ATA) Onboard Device This item enables users to set the Onboard Device status, including USB AC97, MC97 and LAN devices.
  • Page 52 BNC-15T-IP User Guide uses the onboard I/O controller. The options are: Disabled, 280, 288, 2A0 and 2A8. Serial Port 3 Use IRQ Lets you specify the parameter for Serial Port 3 use IRQ. options are: IRQ3, IRQ4, IRQ5, IRQ7, IRQ9, IRQ10 and IRQ11.
  • Page 53 BNC-15T-IP User Guide executed when you change the system configuration, you change the system backup battery, or the system detects a configuration error and asks you to run the Setup program. Use the arrow keys to select, and press Enter to run the selected program.
  • Page 54 BNC-15T-IP User Guide IDE Primary Master PIO Lets you specify the parameter to "Auto", "Mode 0", "Mode 1", "Mode 2", "Mode 3" or "Mode 4". IDE Primary Slave PIO Lets you specify the parameter to "Auto", "Mode 0", "Mode 1", "Mode 2", "Mode 3"...
  • Page 55 BNC-15T-IP User Guide PATA IDE Mode SATA port 4.5.2. USB Controller This field lets you activate or close the onboard USB 1.0 feature. options are: "Disabled" and "Enabled". USB 2.0 Controller This field lets you activate or close the onboard USB 2.0 feature.
  • Page 56 BNC-15T-IP User Guide Azalia/AC97 Audio Select 4.5.3. The Setup utility program allows you to update the system configuration settings. The BIOS setup values will be saved in the CMOS. It is executed when you change the system configuration, you change the system backup battery, or the system detects a configuration error and asks you to run the Setup program.
  • Page 57 BNC-15T-IP User Guide "Disabled", "3F8/IRQ4", "2F8/IRQ3", "3E8/IRQ4" and "2E8/IRQ3". Onboard Serial Port 2 This field lets you modify your serial port parameters, when the serial port uses the onboard I/O controller. The options are: "Disabled", "3F8/IRQ4", "2F8/IRQ3", "3E8/IRQ4" and "2E8/IRQ3".

  • Page 58: Power Management Setup

    BNC-15T-IP User Guide ACPI Function This item defines the ACPI (Advanced Configuration and Power Management) feature that makes hardware status information available to the operating system for communicating PC and system devices in power management improvement. ACPI Suspend Type This item allows you to select the sleep state when the computer is in suspend mode.
  • Page 59 BNC-15T-IP User Guide Power Management This item allows you to select the system power saving mode. Min Saving Lets you set the minimum power management to 1 hr. in Suspend Mode. Max Saving Lets you set the maximum power management to1 min.
  • Page 60 BNC-15T-IP User Guide Delay 4 Sec. Press and hold the power button for 4 sec to power off Wake-Up by PCI card This item allows you to enable and define how PCI cards wake the system up from suspend mode.

  • Page 61: Pnp/Pci Configurations

    BNC-15T-IP User Guide Init Display First This item lets you start up video display from the PCI or onboard device. The options are: "PCI Slot" and "Onboard". Reset Configuration Data This item lets you clear any PnP configuration data stored in the BIOS.

  • Page 62: Pc Health Status

    BNC-15T-IP User Guide IRQ Resources This item lets you assign an interrupt type to IRQ-3, 4, 5, 7, 9, 10, 11, 12, 14, or 15. DMA Resources This item lets you assign an interrupt type to DMA-0, 1, 2, 3, 4, 5, 6, or 7.

  • Page 63: Frequency/Voltage Control

    BNC-15T-IP User Guide Current System Temp / Current CPU1 Temperature / Fan1 Speed / Fan2 Speed / Vcore / +12V / VCC (V) / VBAT (V) / 5VSB (V) Smart Fan2 Temperature This item lets you set the parameter to "Disabled", "40°C/104°F", "45°C/113°F"...

  • Page 64: Load Fail-Safe/Optimized Defaults

    BNC-15T-IP User Guide Spread Spectrum This feature allows you to activate or close the spread spectrum function. The options are: Disabled and Enabled. CPU Host/SRC/PCI Clock This feature allows you to set the parameter for CPU Host/SRC/PCI Clock. The options are: Default and 100/100/33MHz.

  • Page 65: Save & Exit Setup

    BNC-15T-IP User Guide & & After you have made changes under Setup Utility, press Esc to return to the main menu. You can move the cursor to Save and Exit Setup or press F10 and then press Y to change the CMOS Setup. If you did not change anything, press Esc again or move the cursor to Exit Without Saving and press Y to retain the Setup settings.

  • Page 66: Chapter 5 Jumpers And Connectors

    OPEN a jumper means removing the plastic clip from a jumper. The following jumpers can be found on the motherboard installed in the BNC-15T-IP. Before the motherboard is installed, the jumpers must be set in accordance with the desired configuration. The jumpers on the motherboard are listed as below.
  • Page 67 BNC-15T-IP User Guide RS-232 (default) JP1: (1-2) short JP2: (1-3) short JP3: (2-4) short RS-422 JP1: (3-4) short JP2: (3-5)short JP3: (4-6) short RS-485 JP1: (5-6) short JP2: (3-5) short JP3: (4-6) short www.benecom.co.kr...
  • Page 68 BNC-15T-IP User Guide CMOS: CMOS clear connector Normal: (1-2) short-default CMOS clear: (2-3) short Internal Connector CF_SEL: CF-Card device select Master: (1-2) Short-Default Slave: (2-3) Short MPCIE: PCIE Connector www.benecomc.co.kr...
