Summary of Contents for peerless-AV SUA746H
- Page 1 Ultra-Thin Articulating Mount for Flat Panel Displays Model: SUA746H EXTENDED COLAPSED Max Load Capacity: 60 lb (27.2 kg) 2300 White Oak Circle • Aurora, Il 60502 • (800) 865-2112 • Fax: (800) 359-6500 • www.peerless-av ISSUED: 05-01-12 SHEET #: 125-9307-1...
-
Page 2: Wall Construction
Note: Read entire instruction sheet before you start installation and assembly. WARNING • Do not begin to install your Peerless product until you have read and understood the instructions and warnings contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, for US customers please call Peerless customer care at 1-800-865-2112, for all international customers, please contact your local distributor. -
Page 3: Parts List
Before you begin, make sure all parts shown are included with your product. Parts List Description Qty. Part # A wall arm assembly 201‐P1991 B cable clip 046‐P1138 C wood screws 520‐1202 D concrete anchors 590‐0320 E M6 x 12 mm socket pin screw 510‐1050 F cable tie 046‐0136 G 4 mm allen wrench 560‐9646 H fastener cap 590‐1324 cable anchor... -
Page 4: Installation To Single Wood Stud Wall
Installation to Single Wood Stud Wall WARNING • Installer must verify that the supporting surface will safely support the combined load of the equipment and all attached hardware and components. • Tighten wood screws so that wall plate is firmly attached, but do not overtighten. Overtightening can damage the screws, greatly reducing their holding power. -
Page 5: Installation To Solid Concrete Or Cinder Block
Installation to Solid Concrete or Cinder Block WARNING • When installing Peerless wall mounts on cinder block, verify that you have a minimum of 1-3/8" (35 mm) of actual concrete thickness in the hole to be used for the concrete anchors. Do not drill into mortar joints! Be sure to mount in a solid part of the block, generally 1"... - Page 6 Installing Adapter Brackets to Display WARNING • Tighten screws so display brackets are firmly attached to display. Do not tighten with excessive force. Overtightening can cause stress damage to screws, greatly reducing their holding power and possibly causing screw heads to become detached. Tighten to 40 in. • lb (4.5 N.M.) maximum torque. •...
-
Page 7: Roll Adjustment
Roll Adjustment Adapter plate may be rolled +/- 5°. Roll locking screw may be tightened or loosened using 4 mm allen wrench (G). CAUTION JOINT SCReWS • Do not tighten joint screws. Doing so may cause damage to screws, greatly reducing their holding power.
