HS-5243, HS-5244, HS-5245, HS-5246, HS-5252, HS-5253, HS-5254, HS-5255
For use with Hoshizaki Ice Machines: KM-515M_J, KM-901M_J, KM-1301S_J/3
Check to ensure that all parts are included:
• Only qualified service technicians should install this kit to reduce the risk of death, electric shock, serious injury, or fire.
• Move the icemaker control switch to the "OFF" position and turn off the power supply before servicing. Lockout/Tagout to
prevent the power supply from being turned back on inadvertently.
• CHOKING HAZARD: Ensure all components, fasteners, and thumbscrews are securely in place after any maintenance is
done to the appliance. Make sure that none have fallen into the ice storage bin.
• No installation or service should be undertaken until the technician has thoroughly read these instructions.
Installation Instructions
1) Turn off the power supply. Lockout/Tagout to prevent the power supply from being turned on inadvertently.
2) Remove and discard the front panel and screw(s). See Fig. 1 and Fig. 2.
3) Place the new front panel in its correct position and secure with Torx screw(s) (4 mm-large) provided in this kit.
4) Remove all screws from the sides of the appliance (KM-1301 and KM-1900S_J/3) and replace with Torx screws (4 mm-large)
provided in this kit. See Fig. 2.
Model Shown:
KM-515MAJ
4 mm-large
Fig. 1
Hoshizaki Prison Kit
and KM-1900S_J/3
Index
No. Description
1
Front Panel
2
Torx Screw (4 mm-small)
3
Torx Screw (4 mm-large)
4
Torx Screw (5 mm)
5
Torx Pin Bit (small)
6
Torx Pin Bit (large)
Side
4 mm-large
Kit
Number
Model
HS-5243
KM-515MAJ
HS-5244
KM-515MWJ
HS-5245
KM-901MAJ
HS-5246
KM-901MWJ
HS-5252
KM-1301SAJ/3 2A7289G01
HS-5253
KM-1301SWJ/3
HS-5254
KM-1900SAJ/3 2A7292G01
HS-5255 KM-1900SWJ/3 2A7252-01
All
All
All
All
All
All
All
All
All
All
WARNING
Model Shown:
KM-1900SAJ3
4 mm-large
1
Part
Number
Qty
2A7285G01
1
2A7285G02
1
2A8612G01
1
2A8612G02
1
1
2A7251-01
1
1
1
7PP2I0812
20
7PP2-0410
6
7PP2-0512
3
7PP2-0001
1
7PP2-0002
1
Fig. 2
Side
4 mm-large
2A8478-012
Advertisement
Related Manuals for Hoshizaki HS-5243
Summary of Contents for Hoshizaki HS-5243
- Page 1 Hoshizaki Prison Kit HS-5243, HS-5244, HS-5245, HS-5246, HS-5252, HS-5253, HS-5254, HS-5255 For use with Hoshizaki Ice Machines: KM-515M_J, KM-901M_J, KM-1301S_J/3 and KM-1900S_J/3 Check to ensure that all parts are included: Index Part No. Description Number Model Number Front Panel HS-5243...
- Page 2 5) Remove all but the drain valve fitting screws from the rear of the appliance and replace with Torx screws (4 mm-small) provided in this kit. See Fig. 3 and Fig. 4. 6) Remove the drain valve fitting screws and replace them with Torx screws (5 mm) provided in this kit. 7) Dispose of any remaining screws.
