Summary of Contents for Monsoon Multimedia HAVA Titanium
- Page 1 10-2007 Quick Start Guide Step 1 HAVA Titanium Setup UNPACK: Check that your package includes the following. HAVA Titanium Unit 2 Composite A/V Cable Power Supply IR Blaster Cable Hava Software CD 2 Component Cables USB Dongle this Quick-Start Guide.
- Page 2 HAVA is ready. It takes about one minute after plugging HAVA in for this light to stay on. CONNECT USB DONGLE : Connect USB Dongle to either USB port on the back panel of Hava Titanium Page 2 of 7...
- Page 3 10-2007 Step 2 Connect to your Video signal COMPONENT CABLE CONNECTION: Use the Component Cable (not included) to connect one end from the available Y, Pb, Pr outputs on your Cable/Satellite box to the HD Component Input on your HAVA. For audio use the composite cable, but don’t connect the video input.
- Page 4 10-2007 COMPOSITE CABLE CONNECTION: Use the included Composite Cable to connect one end from the available outputs on your Cable/Satellite box to the inputs labeled “A/V In” on your HAVA unit Composite Cable Cable Set-Top/Satellite/DVR Box HAVA Device Yellow = Video Red = Audio Right White = Audio Left Connect to video source...
- Page 5 10-2007 Use an S-Video Cable (not supplied) to connect one end from the S-Video Out on your Cable/Satellite box to the S-Video Input on your HAVA. For audio, use the composite connection (Step 2.1), but don’t connect the video input. S-Video Cable Cable Set-Top/Satellite/DVR Box (not included)
- Page 6 10-2007 Step 3 Connect the Infrared (IR) Blaster Cable The IR blaster cable allows HAVA to send commands to your video device, just like a remote. Make sure you properly connect the IR blaster cable before you install the HAVA software so that the Setup Wizard and Player can control your device.
- Page 7 HAVA with MCE, please refer to the MCE section of on-line help of Setup Wizard Congratulations! You have just completed the Quick Start Guide. Enjoy HAVA Titanium! For more advanced instructions or for troubleshooting, please consult the HAVA Setup Wizard and Player User’s Guides available on the installation CD.
