AutoMaxi SILVER line FIX POINT 124 Manual page 4

Montage sur véhicule - Assembly conveys - Fahrzeugmontage - Montaggio veicoli
Montaje vehiculo - Montagem veiculo - Montage op voertuig - Montaz relingów
CONVIENT POUR VEHICULE - SUITABLE FOR A VEHICLE - ENTSPRICHT FÜR FAHRZEUG - ADATTO PER VEICOLO
CONVIENE PARA UN VEHÍCULO - CONVÉM PARA VEÍCULOS - GESCHIKT VOOR VOERTUIG - ODPOWIEDNIE DO POJAZDU
ENGLISH
1
Unclip the
obturators
1
located on the
roof of the
vehicle at the
level of the
anchoring
points.
Remove the
obturators.
Adjust the
bars on the
2
2
vehicle follow-
ing the dia-
gram opposite.
Check the ori-
entation of the
aerodynamic
deflector of the
snap rings J.
Put the tabs P
in place
against the
roof.
P015
P016
Strongly tight-
3
3
en the screws
V2 (3,5 N.m)
with the help of
the tool.
307 / Mondeo II = ø6x40 mm
Focus C-Max = ø6x50 mm
KG
Mondeo II 4/5 01
FORD
Focus C.MAX 5 03
Focus II 3,5 10/04
Focus II 4 10/04
FORD
J PEUGEOT
J
P
P017
P018
3,5 Nm
V2
FIX POINT
75 B 307 3,5
PEUGEOT
75 C
75 C
75 C
Balance the
jutting out of
4
the bars from the
right/left side of
the vehicle.
Strongly tighten
the screws V1
(8 N.m) using
the tool.
Cut the obtu-
rator O and clip it
5
on in the apertures
located under the
bars.
Check the correct
position and the
appropriate fasten-
ing of the bars (in
the event of prob-
lem, redo the
mounting of the
bars).
Put the theft
protection covers
6
and lock with the
keys.
Fixation
accessories in the
7
rail: Unclip an end.
Remove the cen-
tral part of snap
ring .
Fasten the acces-
sory in the rail,
reclip the ends.
Read and
follow instruc-
8
tions for
mounting and
use.
Keep tools,
keys, packag-
ing, mounting
instructions for
future uses.
124
KG
01 75 B
4
8 N.m
5
6
7
8
75
Max. Kg
