Toro 79018 Installation Instructions Manual

42in recycler kit 2007 and after riding mower

Advertisement

Quick Links

42in Recycler
2007 and After Riding Mower
Model No. 79018
Installation
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure
1
2
3
4
5
6
1
Preparing the Mower
No Parts Required
Procedure
1. Stop the engine and remove the ignition key.
2. Remove the mower as described in your Operator's
Manual.
3. Turn the mower upside down.
4. Remove the mower blades as described in your
Operator's Manual.
5. Locate the holes illustrated in Figure 1 and proceed
as follows:
© 2010—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
®
Description
No parts required
Upper baffle
Bolt (5/16 x 5/8 inch)
Flange-head nut (5/16 inch)
Bolt (1/4 x 5/8 inch)
Locknut (1/4 inch)
Kicker plate
Phillips head screw (#8 x 5/8 inch)
Discharge cover
Bolt (1/4 x 2-1/2 inches)
Cap nut (1/4 inch)
Recycling decal
Recycling mower blade
Register at www.Toro.com.
Kit
Qty.
1
3
3
4
4
3
6
1
2
2
1
2
• If any of the holes have fasteners in them,
remove the fasteners.
• If any of the holes have rivets in them, drill out
the center of each rivet with a 3/16 inch (5 mm)
drill bit and discard the rivet.
Form No. 3367-636 Rev A
Installation Instructions
Use
Prepare the mower.
Install the upper baffle.
Install the kicker plates.
Install the discharge cover.
Instal the decal.
Install the blades and mower
Original Instructions (EN)
Printed in the USA.
All Rights Reserved

Advertisement

loading

Summary of Contents for Toro 79018

  • Page 1 Form No. 3367-636 Rev A 42in Recycler ® 2007 and After Riding Mower Model No. 79018 Installation Instructions Installation Loose Parts Use the chart below to verify that all parts have been shipped. Procedure Description Qty. – No parts required Prepare the mower.
  • Page 2 Figure 1 1. Holes for mounting the upper baffle 2. Holes for mounting the kickers 3. Locknut (3/8 inch) from the discharge chute retaining rod 4. Cutoff baffle 6. Remove the locknut (3/8 inch) securing the discharge chute retaining rod to the mower (Figure 1). Save it for later use.
  • Page 3 Installing the Kicker Plates Installing the Discharge Cover Parts needed for this procedure: Parts needed for this procedure: Discharge cover Kicker plate Bolt (1/4 x 2-1/2 inches) Phillips head screw (#8 x 5/8 inch) Cap nut (1/4 inch) Procedure Procedure 1.
  • Page 4: Operation

    Operation Converting to Side-discharge Operation Installing the Decal DANGER Parts needed for this procedure: Without the grass deflector, discharge cover, or Recycling decal complete grass catcher assembly mounted in place, you and others are exposed to blade contact and thrown debris. Contact with rotating mower Procedure blade(s) and thrown debris will cause injury or death.
  • Page 5 and dense grass you may have to raise the height-of-cut setting another notch or convert to side discharge or bagging operations. Mowing in Extreme Conditions Air is required to cut and recut grass clippings in the mower housing, so do not set the height-of-cut too low or totally surround the housing by uncut grass.
  • Page 6 Notes:...
  • Page 7 Notes:...
