Summary of Contents for Airbus TDM880i

  • Page 1 TDM880i Instruction Manual PS11129BENAC01 06/2017...
  • Page 2 The above mentioned Declaration of Conformity by Airbus Defence and Space Oy concerns the TDM880i as a standalone product. The End Product Manufacturer/System Integrator has the responsibility of providing separate Declaration of Conformity concerning the whole system/application to which TDM880i is installed.

  • Page 3: Table Of Contents

    Ignition sense (IGS ) functionality ................21 6. PARAMETER REFERENCE (TDM880I SPECIFIC PARAMETERS) ......22 Sleep mode .
  • Page 4 9. GLOSSARY ............... 36 PS11129BENAC01 TDM880i - Instruction Manual 4/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 5: Introduction

    Notes indicate additional information such as recommendations or tips. Task sequence symbol. Indicates the start of a procedure. TDM880i - Instruction Manual PS11129BENAC01 5/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 6: Important Safety Information

    PS11129BENAC01 TDM880i - Instruction Manual 6/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 7: Potentially Explosive Environments

    Care and maintenance  The TDM880i TETRA Data Module is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you fulfil any warranty obligations and enjoy this product for many years.

  • Page 8: Device Overview

    HW flow control are provided with accessories. The TDM880i also provides a set of digital I/O lines that can be configured as inputs or outputs. The outputs can be controlled by SDS messages; the inputs can be used to trigger a status message or location sending to predefined destinations.

  • Page 9: Accessories

    DC Power Cable CA-124 The DC power cable CA-124 has a matching connector for connection to the TDM880i. The other end of the cables are stripped bare wire ends (= no connector). The thickness of wire ends is AWG12 (equals to 4.0 mm²). The cable includes two fuse holders for the ATO fuses.

  • Page 10: Pc Software

    D E V I C E O V E R V I E W Select the best suitable good quality antenna for the use case. Airbus offers a selection of antennas, for which you can find more information in the accessory catalogue. Alternatively, consult your local AIRBUS distributor for the antenna selection.

  • Page 11: Installation

    For more information and local requirements about ESD protection and ESD Protected Area, contact your local Airbus Defence and Space After Market Services representative. TDM880i - Instruction Manual PS11129BENAC01 11/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 12: Environmental Conditions

    Tools and installation materials  The TDM880i is to be mounted on mechanics using ø 3 mm screws (5 pcs) suitable for a printed circuit board. The screw type depends on the material (metal/wood/plastic). For the detailed dimensions of the TDM880i, see Figure 10 and Figure 11.

  • Page 13: Installation Procedure

    Use a proper cable size for the  connector selected, for example RG58C/U, RCG316U or RG142B/U. An optional accessory (CA-127) is available in Airbus Defence and Space to convert from a IPX to a SMA (female). Installation procedure ...

  • Page 14: Powering Up Considerations

    1. When the TDM880i's own accessory antenna is used, the above-mentioned torque values are valid for both ends of the antenna ca- ble. If you use other antennas/cables/connectors than the ones listed as TDM880i accessories, the valid torque values for those must be checked from their manufacturer.

  • Page 15: Special Considerations For Vehicles, Vessels Etc

    Grounding  The TDM880i has been designed for negative ground systems. If you install the TDM880i in a system with positive ground, take a special care to ensure that the grounding and supply voltages are correctly connected. All the input...

  • Page 16: Verifying The Parametrization Functionality

    5. From the Connections: drop down menu, select the connection type as FBUS. In case of TPT errors, see TPT manual. 6. Select File Scan Product. The TPT should recognize the TDM880i as RC-18, and allow the parametrization of the device.

  • Page 17: Feature Guide

    The TDM880i can be configured to send its location information periodically to the controller that needs to keep track of the location history. When the TDM880i is in service, the location information is sent as SDS messages. When the TDM880i is out of service and the GPS tracking functionality is enabled, the TDM880i stores the location information in permanent memory until it is back in service again.

  • Page 18: Sleep Mode Activation

    Power switched ON by the end user Powering the TDM880i can be controlled by bringing high any of the IGS input signals. If the device is powered on when the Sleep mode is configured, the device will boot up into operative mode and remain in that state for a fixed time of 10 minutes.

  • Page 19: Time Recovery

    The TDM880i is powered by an external DC supply (10.6 - 16 V). Starting up the TDM880i after an external power supply failure requires that at least one of the three IGS signals is held in the logic high state. If all the IGS signals are kept in the logic low state after a power supply failure, the device does not start up.

  • Page 20: Load Management (Group Management + Facch)

    IGS input , X103, X901: The TDM880i can be toggled on/off by an external application. To toggle the power on, set the IGS to logic high level (see Table 2), and to power off, set it to 0 V.

  • Page 21: Ignition Sense (Igs ) Functionality

    To turn off the TDM880i, set all IGS inputs into the low state. When detecting such a condition, the device powers down after a configurable delay. If any of the IGS inputs goes into the high state while the power off delay is in progress, the power off sequence is cancelled, and the TDM880i remains in the operational state.

  • Page 22: Parameter Reference (Tdm880I Specific Parameters)

    The end user can insert five different numbers into the Sleep mode OTA numbers fields. The OTA configuration of the Sleep mode functionality is allowed from these numbers. PS11129BENAC01 TDM880i - Instruction Manual 22/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 23: At Interface

    Acknowledgement message format Note: The acknowledgement message requires that at least the protocol and sub-protocol identifiers are correct. TDM880i - Instruction Manual PS11129BENAC01 23/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 24: Periodic Reset

    The end user can insert five different numbers into the Tracking OTA numbers fields. The OTA configuration of the Tracking functionality is allowed from these numbers. PS11129BENAC01 TDM880i - Instruction Manual 24/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 25: At Interface

    32 bits : 0 = disabled, >= distance change in meters Table 9 Tracking parametrization: SDS interface TDM880i - Instruction Manual PS11129BENAC01 25/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 26: Alerting Feature

    TETRA Terminal Programming Tool (TPT) The Alerting feature can be configured using the Mobile Parametrization view shown in Figure 7. PS11129BENAC01 TDM880i - Instruction Manual 26/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.
  • Page 27 • Include Alert statuses into LIP messages’ extended user data field • Allow alert acknowledgements from all numbers (not only the destination numbers) TDM880i - Instruction Manual PS11129BENAC01 27/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 28: At Interface

    Alert number 8 bits. Number of the alert to configure : 0<n<32 Table 12 Alerting: SDS interface PS11129BENAC01 TDM880i - Instruction Manual 28/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 29: Igs Feature

    Note: If the IGS signal goes into the high state during this delay of the timer, the power off is cancelled. TDM880i - Instruction Manual PS11129BENAC01 29/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.
  • Page 30 P A R A M E T E R R E F E R E N C E ( T D M 8 8 0 I S P E C I F I C P A R A M E T E R S ) Figure 8 IGS - Mobile Parameterisation view PS11129BENAC01 TDM880i - Instruction Manual 30/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 31: Connector Interfaces

    C O N N E C T O R I N T E R F A C E S 7. CONNECTOR INTERFACES Connector placement  The locations of the components (the pin 1 marked) in the in the TDM880i board are illustrated in Figure 9. Figure 9 TDM880i connector placement Power supply ...

  • Page 32: At Interface

    User configurable IO 1.7 pin Table 16 I/O connector (X102) pinout (Molex 15-pin board to the wire connector) PS11129BENAC01 TDM880i - Instruction Manual 32/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 33: Gps Antenna

    TETRA antenna  The TETRA antenna connector (X831) is a 50 impedance-matching female MMBX connector.  TDM880i - Instruction Manual PS11129BENAC01 33/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 34: Technical Data

    15-pin board-to-wire connector, Molex 0533981571 compatible I/O CONNECTOR 15-pin board-to-wire connector, Molex 0533981571 compatible Table 18 Technical data PS11129BENAC01 TDM880i - Instruction Manual 34/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.
  • Page 35 The mechanical dimensions of the TDM880i illustrated in Figure 10 and Figure 11. Figure 10 TDM880i assembly holes and height information Figure 11 TDM880i connector locations TDM880i - Instruction Manual PS11129BENAC01 35/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.

  • Page 36: Glossary

    : TETRA Terminal Programming Tool : Transistor-Transistor Logic : Radio transmitter : Coordinated Universal Time : Direct voltage Nbr_page PS11129BENAC01 TDM880i - Instruction Manual 36/36 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.
