- Page 1 Network Mini Dome Camera Installation Manual...
- Page 2 Thank you for purch asing our product . If there are any questions, requests, please do not hesitate to contact the dealer. This man ual appl ies to the VSIP2MPVDMINI Network Camera. This manual may contain sev eral technical incorrect places or pri nting...
- Page 3 Installation Manual of Network Mini Dome Camera Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Seri ous injury or death may be caused if any of these warnings are neglected.
- Page 4 Installation Manual of Network Mini Dome Camera maintenance.)
- Page 5 Installation Manual of Network Mini Dome Camera Notice: 1. Make sure the power supply voltage is correct before using the camera. 2. Do not drop the camera or subject it to physical shock. 3. Do not touch sensor modules with fi ngers. If cleaning is necessary, u se a clean cloth with a b it of ethanol and wipe it gently.
-
Page 6: Table Of Contents
Chapter 1 Introduction ..................1 1.1 Network camera Functions and Features..........1 1.2 Applications ....................1 Chapter 2 Installation ..................2 2.1 Camera Description ................2 2.1.1 Camera Physical Description ............3 2.1.2 Camera Connection ..............4 2.2 Hardware Installation................5 Appendix Product Specification ..............8 VSIP2MPVDMINI.....................8 Specification..................8 Dimensions ....................9... -
Page 7: Chapter 1 Introduction
Installation Manual of Network Mini Dome Camera Chapter 1 Introduction Network camera i s a ki nd of embedde d d igital sur veillance product that combines the features of both trad itional analog camera an d network DVS (D igital Video Server). -
Page 8: Chapter 2 Installation
Installation Manual of Network Mini Dome Camera Chapter 2 Installation NOTE： 1. Please check i f all the items on the pa ckage li st hav e bee n i ncluded wi th your camera. 2. Read the following contents carefully before the installation. 3. -
Page 9: Camera Physical Description
Installation Manual of Network Mini Dome Camera 2.1.1 Camera Physical Description Serial NO. Description Back box Lens P: Power LED indicator, which turns red when power is applied to the unit. Bottom board Bottom board set screw hole Lens set screw S &... -
Page 10: Camera Connection
Installation Manual of Network Mini Dome Camera 2.1.2 Camera Connection Step1: Connect one end of the network cable to the camera and the other end to PC. Step2: Connect one end of the power cord to the camera and the other end to power sokcket to supply power for the camera. -
Page 11: Hardware Installation
Installation Manual of Network Mini Dome Camera 2.2 Hardware Installation The ceiling mount is a suitable installation method for this camera. Please stick to the following steps: NOTE: If required, user can apply the pliers to remove the clip (refer to the part marked in dotted line) on the side of the back box and then feed cables through the opening to... - Page 12 Installation Manual of Network Mini Dome Camera your need. Loosen the lens set screws Adjust horizontally and vertically the camera’s pan and tilt for your need NOTE： As the lens of camera has already been factory adjusted to the best imaging effect, thus it only needs to adjust the pan and tilt view angle.
- Page 13 Installation Manual of Network Mini Dome Camera Fig.2.2.3 Install the back box Fig.2.2.4 Done...
-
Page 14: Appendix Product Specification
Installation Manual of Network Mini Dome Camera Appendix Product Specification Specification Model 2 Megapixel 1/3” CMOS Vandal-Proof Network Mini Dome Parameter Camera Camera Image Sensor 1/3” CMOS Min. Illumination 0.5Lux @(F1.2, AGC ON) Electronic 1/25s ~1/100,000s Shutter 4mm, F1.2 Fixed Iris(2.8, 6, 8mm optional) Lens Angle of view: 90°... -
Page 15: Dimensions
Installation Manual of Network Mini Dome Camera General Operating -10°C~60°C(14°F~140°F), Humidity 90% or less(non-condensing) Condition Power Supply DC12V±10% / PoE Power 3W MAX Consumption Impact IEC60068-2-75Eh,50J;EN50102, IK10 Protection Weather Proof IP66 Dimensions(mm) 100×97.5×46.5(3.94”X3.84”X1.83”) Weight 250g(0.55lbs) Dimensions...
