- Page 1 2.4G 54Mbps Wireless Ethernet Bridge Quick Installation Guide Version 2.0...
- Page 2 This is a Class B product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. CyberTAN declared that WA638-I is limited in CH1-CH11 by specified firmware controlled in USA.
-
Page 3: Table Of Contents
2.4G 54Mbps Wireless AP User's Manual Table of Contents INTRODUCTION ......................4 ........錯誤! 尚未定義書籤。 IRELESS CCESS OINT EATURES ..............錯誤! 尚未定義書籤。 ACKAGE ONTENTS 2. HARDWARE INSTALLATION ..........錯誤! 尚未定義書籤。 ................. 錯誤! 尚未定義書籤。 HYSICAL ETAILS ............. 錯誤! 尚未定義書籤。 ARDWARE NSTALLATION .... -
Page 4: Introduction
2.4G 54Mbps Wireless AP User's Manual 1. Introduction Thank you for purchasing the WS638 Wireless Ethernet Bridge. This Ethernet Bridge provides you with an innovative wireless networking solution. The WS638 is easy to set up and use. With this innovative wireless technology, you can share files and network resources on the network—... -
Page 5: Package Contents
2.4G 54Mbps Wireless AP User's Manual Wireless LAN Security - Provide 64-bit & 128-bit Wired Equivalent Privacy encryption to protect the wireless data transmissions. Package Contents One 54Mbps Wireless Ethernet Bridge with dipole antenna connected One CD-ROM (Wireless Navigator utility software & user’ s manual included) One RJ-45 straight LAN Cable One Power Ethernet Bridge One Quick Installation Guide... -
Page 6: Hardware Installation
2.4G 54Mbps Wireless AP User's Manual 2.Hardware Installation Physical Details Rear Panel Antenna Connector Reset Button LAN Connection Power Input Reset Button “Reset” mean “Initiation”. While pressing the button, the Ethernet Bridge will reboot and reset current configurations to factory default settings. - Page 7 2.4G 54Mbps Wireless AP User's Manual LED Indications Power Wireless-g Color Status Description Power Green Power on Power off Blinking Initial Orange Hardware Error Green LAN port is connected. No connection and neither data forwarding from LAN ports. Blinking LAN is connected and data is sending or receiving via LAN port Wireless Green...
-
Page 8: Hardware Installation
2.4G 54Mbps Wireless AP User's Manual Hardware Installation Following illustration is an example showing how to install Ethernet Bridge with your PC. Be sure to use the supplied power Ethernet Bridge. Note! You may also connect the Ethernet Bridge to other Ethernet-ready device, such as printer server. - Page 9 2.4G 54Mbps Wireless AP User's Manual Connecting the Ethernet Bridge to Your Network There are two network scenarios as below: Also known as a peer-to-peer network, an ad-hoc network is one that allows all workstations and computers in the network to act as servers to all other users on the network.
- Page 10 2.4G 54Mbps Wireless AP User's Manual Wired to wireless LAN connectivity: the access point Ethernet Bridges the gap between wireless LANs and their wired counterparts. <PC to LAN> <Printer to LAN> In the next charter, you will be guided to how to connect the Ethernet Bridge to wireless...
-
Page 11: Wireless Navigator Installation
2.4G 54Mbps Wireless AP User's Manual 3. Wireless Navigator Installation Install the Wireless Navigator The Wireless Navigator Utility is provided to allow user easily to configure the Ethernet Bridge through any Windows-based PC. This section describes procedures for installing the Wireless Navigator Utility to PC. - Page 12 2.4G 54Mbps Wireless AP User's Manual Step 2: After InstallShield Wizard preparation finished, the following window will be shown. Click the Next button to continue. Step 3: Key in your User Name and Company Name, and click Next button to continue. Step 4: The screen will show you the default destination chosen by the utility.
- Page 13 2.4G 54Mbps Wireless AP User's Manual an alternate destination. Click the Next button, when you are ready to continue. The setup program will then begin to install the programs into the destination folder. Step 5: The screen will show you the Program Folder that the utility will use. You may type a new folder name to create a new program folder, or select one from the existing folder list, and click Next button to continue.
- Page 14 2.4G 54Mbps Wireless AP User's Manual Step 6: The Wireless Navigator has been installed now. Please click the Finish button to complete installation. Note! To remove Wireless Navigator Utility, click the Start button, and select Programs, Wireless Navigator, and Uninstall, and then follow the instruction on screen.
