THE INSTRUCTION MANUAL
(For Workers' Use)
for
SHUTTER OPERATOR
WITH
BUILT-IN SENSING MECHANISM
ULA-25GSC
(RECEIVER-LESS SPECIFICATION)
ULA-25GSCR
(RADIO RECEIVER BUILT-IN TYPE)
（Single phase 220-230V）
[ A REQUEST ]
Be sure to check the contents in this instruction manual
in advance of the installation.
Advertisement
Table of Contents
Summary of Contents for Seiki ULA-25GSC
- Page 1 THE INSTRUCTION MANUAL (For Workers’ Use) SHUTTER OPERATOR WITH BUILT-IN SENSING MECHANISM ULA-25GSC (RECEIVER-LESS SPECIFICATION) ULA-25GSCR (RADIO RECEIVER BUILT-IN TYPE) （Single phase 220-230V） [ A REQUEST ] Be sure to check the contents in this instruction manual in advance of the installation.
-
Page 2: Table Of Contents
A Table of Contents Cares for Safety・・・・・・・・・・・・・・・・・・・・・・・・・・P1 Characteristics ・・・・・・・・・・・・・・・・・・・・・・・・・・P2 Appearance of Operator ・・・・・・・・・・・・・・・・・・・・・・ P2 Appearance of Control Panel・・・・・・・・・・・・・・・・・・・・ P3 Specification of Operator・・・・・・・・・・・・・・・・・・・・・ P4 Specification of Transmitter ・・・・・・・・・・・・・・・・・・・ P4 Particulars of Packed Parts・・・・・・・・・・・・・・・・・・・・ P4 Changeover between Right-hand and Left-hand Side Settings ・・・・・P5 Obstacle Sensing Function upon Descent ・・・・・・・・・・・・・・... -
Page 3: Cares For Safety・・・・・・・・・・・・・・・・・・・・・・・・・・P1
① Cares for Safety Our company thinks it important to give priority to safety all the time in regard to shutter systems to which our operator is applied as well as the operator. We ask you please to take ample measures and cares toward the shutter system and the environment around it so that danger may be avoided not only when the shutter operates but also even should the shutter not work normally. -
Page 4: Characteristics ・・・・・・・・・・・・・・・・・・・・・・・・・・P2
In this case cooling time is needed for a short while. It gets reset after a certain time automatically. Consider the opening & closing frequency for using the motor. ③ Appearance of Operator ULA-25GSC (Handchain manual type sketch drawing) -
Page 5: Appearance Of Control Panel・・・・・・・・・・・・・・・・・・・・ P3
④ Appearance of Control Panel Details of tape switch connection part For the connection of tape switch, see ⑭(3) on page 9. Details of upper & lower limit output connection part (for upper & lower limit output specification only) See ⑪ on page 6 for Upper-& lower-limit output changeover and ⑭... -
Page 6: Specification Of Operator・・・・・・・・・・・・・・・・・・・・・ P4
⑤ Specification of Operator Model ULA-25GSC Single-phase 220-230V （50/60Hz） Voltage 220V 230V Operator’s full load current （A） Torque （N･m） 88.2 Output Shaft Min. descent torque （N･m） Rotation speed （r.p.m） 24.3/19.4（ascent / descent） Output （kW） 0.25 Rotation speed （r.p.m） 1500/1200 （ascent / descent）... - Page 7 ⑧ Changeover between Right-hand and Left-hand Side Settings The operator is shipped in the exclusive installation for the right-hand side or the left-hand side. If you want the changeover on the installation side between the right-hand and the left-hand, follow the procedures described below.
-
Page 8: Motion Frequency Display・・・・・・・・・・・・・・・・・・・・・・P6
⑨ Obstacle Sensing Function upon Descent The obstacle sensing function upon descent is set up by the dip switch. In case of not needing the function, change the sensing power over to “OFF”. Upon shipping the sensing power is set up to “ON”. Sensing power “ON”... -
Page 9: Installation Of Operator・・・・・・・・・・・・・・・・・・・・・・P7
⑬ Installation of Operator （1）A request before installing Fix sub-bracket and angle bracket tightly, which have enough strength to support all weight. In a suitable position on the structural members. Weld our exclusive bracket at an appropriate angle on sub-bracket solidly. ※... -
Page 10: Connection ・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P8
⑭ Connection In doing electric work, never fail to keep to the following to prevent a fire, an electric shock, and an abnormal motion. ・Let a qualified electrician do electric work. ・Do electric work in conformity to the electric installation standards and the connection regulations. - Page 11 （2） Connection of Emergency Switch (Auxiliary Limit Switch) As for the emergency switch, please either get it ready yourself or use the company-made one LMS-208A (sold separately). ※ For safety precautions, install the emergency switch (auxiliary limit switch). Upon delivery a short-circuit connector is connected. In installing the emergency switch (auxiliary limit switch), cut the cable of the short-circuit connector and connect it to the switch.
- Page 12 ⑯ Setting of Upper- and Lower Limit There are 3 methods for setting of upper-and lower-limit as follows. As for upper-and lower-limit setting, its method differs between a case in which upper-and lower-limit has not been set yet and a case in which it is reset. Please select the proper way depending on the situation.
- Page 13 （2） Resetting of Upper Limit When you want to change the position of upper limit, reset upper limit by following the procedure shown below. ①With the operation of pushbutton switch or ②When pressing “Stop” button of push-button switch or “Stop” button of transmitter 5 times, then limit transmitter, let the shutter descend to the setting mode is effected.
- Page 14 （3） Resetting of Lower Limit When you want to change the position of lower limit, reset upper- and lower- limit by following the procedure shown below. ②When you press “Stop” button of push-button ①Let the shutter descend to the position of lower switch or “Stop”...
-
Page 15: Method Of Operation・・・・・・・・・・・・・・・・・・・・・・・・ P13
⑰ Method of Operation Prior to opening and closing the shutter, ensure that there is no obstacle on its track. While the shutter is in motion, don’t enter on the shutter’s track. When you operate the shutter with pushbutton switch, don’t stay away from nearby the WARNING shutter until its opening and closing is finished, thus confirming that its opening and closing has been finished. - Page 16 （6） Operation after Power Failure Restoration When a power failure has recovered and shutter stops at the position except for a lower limit point, power failure restoration mode will start. CAUTION Descend shutter with care by push button switch/transmitter until lower limit. Only descending shutter is operationable in power failure restoration mode.
- Page 17 ⑱Registration of transmitter to receiver of the shutter opener Each transmitter of card remote controller ASKA7 (AF7-T3) has unique ID code. The receiver receives the radio signal from registered transmitter only and accordingly it operates. Register the transmitter to be used according to the following steps. The transmitter supplied together with the shutter opener is already registered CAUTION You do not need to register it again.
- Page 18 ⑲Deletion of transmitter by receiver You can choose either of two methods for deletion of transmitter. Choose the deletion method suitable for application and delete the transmitter according to the steps described below. Deletion method 1: Direct deletion (direct operation of deletion switch of the receiver and deletion of all registered transmitters) Deletion method 2: Remote deletion (deletion of separate transmitter remotely) If you press Register/Delete All switch on the control panel for a while,...
- Page 19 ⑳Handling of transmitter (Replacement of battery) ・If the battery level of transmitter is low, the transmitter continuously beeps while pressing the button. In such case, replace the battery with new one. ・The battery is coin type lithium battery (CR2025) 3V. Buy it in electric appliance shop, etc. ・Battery life is about one year under average operating conditions (10 operations/day), but it may be shortened depending on storage environment or operating conditions.
-
Page 20: Abnormality Code List・・・・・・・・・・・・・・・・・・・・・・・ P18
Abnormality Code List Motion when abnormality of operator is detected: The motion frequency LED flickers in the same frequency as abnormality code № (The control panel buzzer sounds for 30 seconds interlocking with LED after abnormality is detected. LED flickers up until abnormality becomes restored.) Motion frequency display LED Detailed Description of Operator Abnormality Code... - Page 21 ④ 登 録 し た お問い合わせ・ ⑧左右勝 ご不明な点がご 送 信 機 の 操 手の設定 ざいましたら下 Troubleshooting Method 作 で シ ャ ッ 記までご連絡下 タ ー が 確 実 さい。 大阪営業所：大 Page for reference に上昇、 Item Possible cause Method of action 阪市中央区安土...
