Summary of Contents for Xebec TRI-SCREEN
- Page 1 T R I - S C R E E N USER GUIDE Watch our video tutorials online at www.thexebec.com/tutorial...
-
Page 2: Table Of Contents
Contents | Parts overview | Inputs and buttons | Choose your cables | Set it up | Laptop display configuration | Customize your Tri-Screen 9-10 | Pack up and go | Additional help | Tech specs | Product safety | FCC compliance... -
Page 3: Parts Overview
Parts Overview Tri-Screen 2 x USB-C to USB-C (90 degree) cables V I D E O & P O W E R 2 x USB-C to USB-A Velcro Kickstand cables Cable Tie P O W E R O N L Y... -
Page 4: Inputs And Buttons
Inputs and Buttons USB-C (power only) + Pass-Through Charging Mini-HDMI (video) Thunderbolt 3 / USB-C with DisplayPort (video & power) Menu Down / Back Menu Up Menu / Enter *NOTE* This layout will be flipped for the screen on the right... -
Page 5: Choose Your Cables
Mini-Displayport Mini-DVI If your laptop has two Thunderbolt 3 / USB-C with DP ports, the simplest way to use the Tri-Screen is with the two USB-C to USB-C cables provided. USB 3.0 (with If your laptop does not have any Thunderbolt 3 / USB-C... -
Page 6: Set It Up
3. PLUG IT IN Using the necessary cables (identified on the previous page), plug one end into the Tri-Screen and the other into your laptop. See "Inputs and Buttons" on page 3 for an input diagram. -
Page 7: Laptop Display Configuration
Laptop Display Configuration PC/WINDOWS Go to your Display Settings (Start > Settings > System > Display) Click and drag screens to configuration shown If any of the screens are upside down, click on the screen in the display menu. Then click on the "Orientation"... - Page 8 Laptop Display Configuration Open "System Preferences" Select "Displays" from the menu Click "Arrangement" from display menu Click and drag screens to configuration shown If any of the screens are upside down, click on the display menu on that screen and select "180 degrees" from the dropdown To increase the zoom, click the "Scaled"...
-
Page 9: Customize Your Tri-Screen
KICKSTAND Want more screen support? Place one end of the kickstand into the back of the Tri-Screen and rest easy. Have a taller screen? Remove the rubber cap and place it on the other end (as shown) and you're set! - Page 10 Just plug your laptop's power cable into the Tri-Screen's USB-C Power Only input for pass- through charging. BRACKET ADAPTORS If the Tri-Screen bracket clips are too thin for your laptop screen, slide on the bracket adapters to give it a little more grip.
-
Page 11: Pack Up And Go
For the most convenience, simply slide the screens in, unplug the cables, shut your laptop, and pack everything up together. Tight on space? Slide the screens in, unplug the cables from your laptop, take off the Tri-Screen, and pack it up separately. -
Page 12: Additional Help
Have more questions? Check out our FAQ at @thexebec www.thexebec.com/faq @thexebec Need more support? Contact us at contact@thexebec.com @my_xebec Want to be featured? Tag us on social media with your favorite shot using the Xebec Tri-Screen! Use the hashtags #Xebec #FreeYourself... -
Page 13: Tech Specs
Tech Specs DISPLAY INPUTS AND CONNECTIVITY (PER SCREEN) Two 10.1 inch (diagonal) 1920 x 1200, Full HD LCD IPS Panels Thunderbolt / USB-C input 16:10 aspect ratio Video and Power 180 degree screen rotation Mini-HDMI input Adjustable brightness Video Only Power Consumption: 5V 2A (per USB-C input screen) -
Page 14: Product Safety
In the event that there is any liquid spilled on the Xebec Tri-Screen, unplug all the cables immediately and dry the entire product off with a dry soft towel. Wait for it to dry entirely before using again. To avoid an electric shock, unplug all the cables before cleaning the screens. -
Page 15: Fcc Compliance
FCC Compliance This part complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference (2) this device must accept any interference received, including interference that may cause undesired operation This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. - Page 16 (j) external causes such as accidents, abuse, or other actions or events beyond our reasonable control. If this product is returned to Xebec, Inc., this product must be insured during shipment, with the insurance and shipping charges prepaid by you. If this product is returned uninsured, you assume all risks of loss or damage during shipment.
- Page 17 WHATSOEVER (INCLUDING, WITHOUT LIMITATION, ALL DAMAGES REFERENCED HEREIN AND ALL DIRECT OR GENERAL DAMAGES IN CONTRACT, TORT (INCLUDING NEGLIGENCE) OR OTHERWISE), THE ENTIRE AGGREGATE LIABILITY OF XEBEC AND ANY OF ITS DISTRIBUTORS AND/OR SUPPLIERS WILL BE LIMITED TO THE AMOUNT ACTUALLY PAID BY CUSTOMER FOR ANY PRODUCT GIVING RISE TO LIABILITY. SOME STATES, PROVINCES, COUNTRIES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO CUSTOMER.
- Page 18 T R I - S C R E E N...
