Token R232 Installation Instructions

SRAM GXP Adaptor Set Installation Instructions

IMPORTANT NOTICE:

BEFORE RIDING:

your local TOKEN dealer for service or replacement.
improperly attached cranks.

AFTER RIDING:

prematurely.

WARRANTY:

All TOKEN products are guaranteed against defects in materials or workmanship for two (2) years from the original date of purchase. This warranty applies to the original owner only and is
not transferable. The warranty is considered void if resold. The warranty does not cover normal wear and tear or damage from abuse. Please see our website or contact your local dealer or
distributor for more details.
MODEL: R232
Description
No.
GXP Adaptor
1
2 Wave Washer
1mm Spacer
3-1
2.5mm Spacer
3-2
4 2.5mm Spacer
2 mm Spacer
5
0.6mm Spacer
6

For use with:

BB841TS-41/BB841TS-41TBT
BB841PS/BB841PS-TBT
BB86P/BB86P-TBT/BB90
Note: BB86P / BB86P-TBT is NOT compatible with
SRAM GXP MTB cranksets. Attemp to use this
product with GXP MTB cranksets by modification
or adding spacers will lead to poor fitment,
potential harm and void of warranty.
Q'ty
1
1
2
2
1
1
3
3
89.5mm-MTB: 2.5mm spacer * 1
92mm-MTB: 2.5mm spacer * 1
3
SRAM GXP ROAD CRANKSET + BB86 FRAME
86.5mm
Non-Drive
Side
3 1
SRAM GXP ROAD CRANKSET + BB86 FRAME
86.5mm
Non-Drive
Side
1
SRAM GXP MTB CRANKSET + BB89.5/92 FRAME
89.5 / 92mm
Non-Drive
Side
1
SRAM GXP ROAD CRANKSET + BB90 FRAME
90.5mm
Non-Drive
Side
1
www.tokenproducts.com
Drive Side
3
Drive Side
89.5mm-MTB: 1mm spacer * 1
+2.5mm spacer * 1
92mm-MTB: 1mm spacer * 1
Drive Side
Drive Side
Bruce 2020.01.20
2
3 2
3 2
5 2
2020-Jan.
