VERSA PATROL SERVICE MANUAL
VERSA PATROL SERVICE MANUAL
Contents
1.
Foreword .............................................................................................................................................
2.
Document Revision .............................................................................................................................
3.
Radio Information ...............................................................................................................................
4.
Package Layout ...................................................................................................................................
4.1
Box Dimension ............................................................................................................................
4.2
Box Layout ...................................................................................................................................
5.
Parts of the Radio ................................................................................................................................
6.
Initial Assembly and Preparation ........................................................................................................
6.1
Charging ......................................................................................................................................
6.2
Battery Pack ..............................................................................................................................
6.3
Antenna .....................................................................................................................................
6.4
Belt Clip .....................................................................................................................................
6.5
Earpiece (Optional) ...................................................................................................................
7.
Basic Operation .................................................................................................................................
7.1
Power on and Adjust volume knob ...........................................................................................
7.2
Channel selector knob ..............................................................................................................
7.3
PTT button ...............................................................................................................................
7.4
Monitor button .......................................................................................................................
8.
Features ..........................................................................................................................................
8.1
Voice Prompt ..........................................................................................................................
8.2
CTCSS/DCS ...............................................................................................................................
8.3
Channel Scan ...........................................................................................................................
8.4
Time-Out-Timer (TOT) .............................................................................................................
8.5
Low Power Alarm ....................................................................................................................
8.6
Squelch Level Adjustment .......................................................................................................
8.7
High/Low Power Selection ......................................................................................................
23
34
45
46
46
47
48
49
49
510
611
711
712
913
913
913
1014
1014
1115
1115
1115
1115
1115
1115
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VERSA PATROL and is the answer not in the manual?

Questions and answers

Summary of Contents for Tech1 VERSA PATROL

  • Page 1: Table Of Contents

    VERSA PATROL SERVICE MANUAL VERSA PATROL SERVICE MANUAL Contents Foreword ............................. Document Revision ..........................Radio Information ..........................Package Layout ........................... Box Dimension ..........................Box Layout ........................... Parts of the Radio ..........................Initial Assembly and Preparation ......................Charging ............................Battery Pack ..........................
  • Page 2 VERSA PATROL SERVICE MANUAL Wireless cloning .......................... Cable cloning ..........................8.10 VOX Function ..........................8.11 Emergency Alarm ........................8.12 Channel Keylock .......................... 8.13 Dual Watch Operation ........................ Radio Assembly and Disassembly ....................... Assembly and Disassembly ......................Exploded View ..........................Quality Check ..........................

  • Page 3: Foreword

    VERSA PATROL SERVICE MANUAL 1. Foreword SCOPE OF THIS MANUAL This manual is intended for use by experienced technicians familiar with similar types of commercial grade communications equipment. It contains all the required service information for the equipment and current released data.

  • Page 4: Document Revision

    VERSA PATROL SERVICE MANUAL 2. Document Revision DOCUMENTED BY DESCRIPTION DATE Winston Yves L. Esguerra Initial Release December 2019...

  • Page 5: Radio Information

    VERSA PATROL SERVICE MANUAL 3. Radio Information 4. Package Layout 4.1 Box Dimension 4.2 Box Layout 5. Parts of the Radio 6. Initial Assembly and Preparation 6.1 Charging Before charging the battery, make sure that the transceiver has been turned OFF. To charge the battery, plug in to AC outlet (110-240Vac) and insert the bottom of the battery into the charger.

  • Page 6: Battery Pack

    VERSA PATROL SERVICE MANUAL Connect adaptor to charger then plug in to AC outlet 100V-240VAC Insert battery to the charger. ways of charging, with transceiver battery only. Note: The battery may be charged either attached or removed from the transceiver. Never charge the battery at temperature below -10°C (14°F) or above 35°C (95°F).

  • Page 7: Antenna

    VERSA PATROL SERVICE MANUAL Remove: Make sure the radio is turned OFF. Press down the battery latch at the bottom of the transceiver then pull the battery. 6.3 Antenna Connect the antenna to the antenna connector then turn the antenna clockwise to install and...

  • Page 8: Belt Clip

    VERSA PATROL SERVICE MANUAL 6.4 Belt Clip Fit the belt clip at the back of the transceiver. Screw the belt clip. 6.5 Earpiece (Optional) Open the earmic cover located at the left side of the transceiver.
  • Page 9 VERSA PATROL SERVICE MANUAL Connect Earpiece.

  • Page 10: Basic Operation

    VERSA PATROL SERVICE MANUAL 7. Basic Operation 7.1 Power on and Adjust volume knob - Turn the Power/ Volume knob clockwise. Beep sound indicates that the power is on. - To adjust the sound, Press MON and rotate the Power/ Volume to desired level.

  • Page 11: Ptt Button

    VERSA PATROL SERVICE MANUAL 7.3 PTT button - To make a call, Press PTT. Keep mouth 3-4cm away from mic when speaking. - Release PTT button to receive signals. - Light Indicator: Steady Red when Transmitting / Steady Green when Receiving.

  • Page 12: Features

    VERSA PATROL SERVICE MANUAL 8. Features 8.1 Voice Prompt Voice prompting when selecting channel. 8.2 CTCSS/DCS Reduces the interference by adding a low frequency. 8.3 Channel Scan Scan Channel 1 to 99. 8.4 Time-Out-Timer (TOT) Limit the transmission period 0 to 300 seconds.

  • Page 13: Radio Assembly And Disassembly

    VERSA PATROL SERVICE MANUAL 9. Radio Assembly and Disassembly 9.1 Assembly and Disassembly 1. Remove antenna. Turn antenna counterclockwise. 2. Remove belt clip. Unscrew belt clip, turn counterclockwise to remove. 3. Remove the battery. Press down the battery latch at the bottom of the transceiver then...
  • Page 14 VERSA PATROL SERVICE MANUAL 4. Remove Power/ Volume Knob. Pull the knob. 5. Remove antenna round nut screw. Using round nut screwdriver, turn counterclockwise to remove. 6. Remove earmic cover. Unscrew by turning counterclockwise.
  • Page 15 VERSA PATROL SERVICE MANUAL 7. Remove screws on the metal body. Unscrew by turning counterclockwise. 8. Remove metal body from the housing. Pull up the metal body using chassis remover. 9. Remove earmic rubber.
  • Page 16 VERSA PATROL SERVICE MANUAL 10. Remove speaker and mic wire to the board. Using soldering iron, de-solder the wire. 11. Remove Potentiometer nut screw rubber cover. Pull the black rubber.
  • Page 17 VERSA PATROL SERVICE MANUAL 12. Remove Potentiometer nut screw. Using a wrench, turn counterclockwise to remove nut. 13. Remove screw from the board. Turn counterclockwise to unscrew. (11 screws)
  • Page 18 VERSA PATROL SERVICE MANUAL 14. Remove the antenna connector by de-soldering it from the mainboard of the transceiver. 15. Pull mainboard to the metal body.

  • Page 19: Exploded View

    VERSA PATROL SERVICE MANUAL 9.2 Exploded View...

  • Page 20: Quality Check

    VERSA PATROL SERVICE MANUAL Quality Check 10.1 Physical Appearance Check physical appearance of the radio. Housing Knobs Battery Charger Belt clip Buttons Antenna 10.2 RF Testing Measure maximum and minimum receive sensitivity, TX power and VSWR Test: Maximum and Minimum RX sensitivity, TX power and VSWR Test Objective: The purpose of this test is to verify if the RX sensitivity, TX power and VSWR is within the specifications.

  • Page 21: Schematic Diagram

    VERSA PATROL SERVICE MANUAL Schematic Diagram...
  • Page 22 VERSA PATROL SERVICE MANUAL...

  • Page 23: Block Diagram

    VERSA PATROL SERVICE MANUAL Block Diagram 10.1 Front Board...

  • Page 24: Back Board

    VERSA PATROL SERVICE MANUAL 10.2 Back Board 13. Troubleshooting and Repair 13.1 External Parts - Check physical appearance of the radio. Versa PATROL PARTS: DEFECTS SAMPLE IMAGE ANTENNA Bent or Cut The coil is separated to the insulator Torn antenna rubber...

  • Page 25: Internal Parts

    VERSA PATROL SERVICE MANUAL Faded Rubber VOLUME KNOB Separated into two No metal bezel Loosened knob 13.2 Internal Parts - Check the block diagram (page 17 to 18) for your reference. LABEL Versa PATROL PARTS: DEFECTS SAMPLE IMAGE CERAMIC FILTER...

  • Page 26: Reprogramming

    To install the Patrol programming application on a computer system running Microsoft windows 7, follow these steps: 1. Use Windows Explorer to locate the Versa Patrol programming application from the supplied CD/DVD or download. 2. Double-click on the installer. The Versa Patrol programming application welcome...
  • Page 27 VERSA PATROL SERVICE MANUAL 3. Software will be installing. The following window appears.
  • Page 28 VERSA PATROL SERVICE MANUAL 4. Click Finish to exit setup and Run Patrol Programming software.

  • Page 29: Install Prolific Usb To Serial Comm Port

    VERSA PATROL SERVICE MANUAL 14.1.3. Install Prolific USB to Serial Comm Port 1. Plug the Versa Programming cable for Quicktalk Pro. 2. Go to Device Manager and click Ports. The following window appears. 3. Right click the Prolific USB-to-Serial Comm port then click Update Driver. The...
  • Page 30 VERSA PATROL SERVICE MANUAL 4. Click Search automatically for updated software. It will automatically scan for a driver online. The following window will appear. 5. Click Close to exit setup.

  • Page 31: Radio Programming

    VERSA PATROL SERVICE MANUAL 14.2. Radio Programming 1. Plug the programming cable and Power on the Versa Patrol to be programmed. 2. Open Patrol.exe programming software. The following window will appear. 3. Setup the com port settings. The following window will appear.
  • Page 32 VERSA PATROL SERVICE MANUAL Check the available com port. If no com port is available check the programming cable if connected properly. 4. Read the program. Click “Read” icon then window will appear then click “Start” to read program. 5. Edit program...
  • Page 33 VERSA PATROL SERVICE MANUAL Edit to desired frequency and CTCSS/DCS Code. Change power settings to High and Low. 6. Write program Click “Write” icon then window will appear click “Start” to write program.
  • Page 34 VERSA PATROL SERVICE MANUAL...
  • Page 35 VERSA PATROL SERVICE MANUAL ADDRESS: www.versa.ph Tech1 Corporation U3103 Cityland Pasong Tamo Tower 2210 Don Chino Roces Avenue Makati City, Philippines CONTACT: Tel. No.: (+632)8856-5925, 8817-1449 Telefax: (+632)7756-0485...
