Tools Needed
Drill
¼ " Drill Bit
Lag Bolts
to mount awning
brackets to wall
Sockets or wrench
tighten non-provided
installation hardware
Level
Caulking Measuring
Tape
4 mm Allen Key
INSTALLATION
1
Mounting Brackets must be installed into solid structure (wood beams, studs, concrete, and/
or roof rafters), sufficient to support the weight and anticipated wind load. (Note: it is highly
recommended that the awning be retracted in moderate to strong wind conditions to prevent
damage). Locate stud, beam or rafter and confirm that the structure is solid.
The awning can be either wall-mounted or ceiling-mounted.
The instructions provided below are for wall mounting. If the
procedure is different for ceiling installation, explanations will be
provided as needed. This procedure must be performed by at
least two workers.
--------------------------------------------------------------------------------------------------
SOLANA RETRACTABLE AWNING
CONGRATULATIONS
Retractable Awning.
Thank you for your business. Please read this entire manual
before beginning installation.
We are confident you will enjoy many years of shade and worry free
operation from your awning. This installation manual will outline the steps
required to install your awning. It is important that the awning is installed
properly to ensure worry free operation. Improper installation may cause
damage or failure not covered by your warranty.
to
Mounting hardware is not included because it is different for every attachment
surface. Please seek out professional advice in order to determine proper
installation hardware selection.
If you are having any issues with the installation or determining mounting
hardware please call 877-702-5463 for assistance from one of our shade
experts.
Please be sure to be cautious in removing packaging materials. The fabric
is just below the packaging material and can easily be damaged.
Never use a knife to remove packaging.
on the purchase of a Blindsgalore Solana
Toll Free 877-702-5463 | Fax 858-642-6841
blindsgalore.com | customercare@blindsgalore.com
Installation Instructions
2
Advertisement
Summary of Contents for blindsgalore SOLANA
- Page 1 SOLANA RETRACTABLE AWNING Installation Instructions -------------------------------------------------------------------------------------------------- CONGRATULATIONS Tools Needed on the purchase of a Blindsgalore Solana Retractable Awning. Thank you for your business. Please read this entire manual Drill before beginning installation. ¼ “ Drill Bit We are confident you will enjoy many years of shade and worry free operation from your awning.
- Page 2 SOLANA RETRACTABLE AWNING Installation Instructions -------------------------------------------------------------------------------------------------- INSTALLATION cont. Before starting installation, take note of the following information, which is indispensable to find the right position for fastening the brackets: Dimensions of the awning (height and width of box Protrusion of awning when opened or closed) Side of awning where control is located Dimensions of the wall/ceiling where the awning is to be installed.
- Page 3 SOLANA RETRACTABLE AWNING Installation Instructions -------------------------------------------------------------------------------------------------- Hand Crank – Place hook of hand crank into the eyelet located at the bottom of the gear. Turn crank to extend the awning. Do not crank past the point of full extension, as fabric will slacken. Fabric must be retracted on the top of the roller tube, not the bottom.
