- Page 1 ECHO Display Kit - Loaner Installation Manual ECHO-DT1L...
- Page 2 Reorder P/N: ECHO-DT1L-INST Rev B (ECHO Display Kit - Loaner) NOTICE: NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information...
-
Page 3: Table Of Contents
Contents INTRODUCTION ..................... 2 List of Parts ..................................2 TECHNICAL SPECIFICATIONS ................3 INSTALLATION ......................4 Installation with Control Module Serial Number 3200 and Lower .................4 Installation with Control Module Serial Number 3199 and Lower .................5 ... -
Page 4: Introduction
1 Introduction The ECHO™ Display Kit Manual is intended to be used in conjunction with the UC5™ Spray Height Control Installation Manual. This manual provides instructions to interface the UC5 Control Module to the ECHO Display. For installation of the rest of the UC5 Spray Height Control System please refer to the sprayer specific manual provided with the kit. -
Page 5: Technical Specifications
2 Technical Specifications CAN ICES-3(A)/NMB-3(A) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. -
Page 6: Installation
3 Installation Ensure the ECHO power switch is OFF for the remainder of the installation (Bottom of switch pressed IN). There are two different ways that the ECHO can be installed depending on the serial number of the control module (part #43710). Follow the instructions that match the control module serial number. -
Page 7: Installation With Control Module Serial Number 3199 And Lower
(E01). This is the end of the control module that only has one Deutsch connector. 4. Disconnect the network cable from the control module NORAC bus (end of control module with two Deutsch connectors). 5. Connect the 3-way coupler (E10) to the disconnected network cable. Connect cable C02 between the 3-way coupler and the control module. -
Page 8: Cable Drawings
4 Cable Drawings ITEM C01: 43220-01 - CABLE UC5 NETWORK 14 AWG - 1M ITEM C01: 43220-0.5 - CABLE UC5 NETWORK 14 AWG – 0.5M... - Page 9 Canada NORAC Systems International Inc. Phone: (+1) 306 664 6711 Toll Free: 1 800 667 3921 Shipping Address: 3702 Kinnear Place Saskatoon, SK S7P 0A6 United States NORAC, Inc. Phone: (+1) 952 224 4142 Toll Free: 1 866 306 6722...
