Digital FM/AM Receiver
Model RM-350D
54-5021-01
9609
Printed in USA
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RM-350D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bogen RM-350D

Summary of Contents for Bogen RM-350D

  • Page 1 Digital FM/AM Receiver Model RM-350D 54-5021-01 9609 Printed in USA User’s Guide...

  • Page 2: Specifications

    Specifications Band Coverage ... . AM .....530 - 1620KHz FM ..... .87.5 - 107.9MHz Tuning .

  • Page 3: Before You Begin

    Before You Begin Your Bogen RM-350D Digital Tuner/Receiver incorporates the latest in PLL digital circuitry for reliable performance for years to come. To get the maximum benefit from your Bogen product, please read all instructional materials provided with the unit. Unpacking The RM-350D is carefully checked before leaving the factory.

  • Page 4: Am Loop Antenna

    AM Loop Antenna The RM350D is provided with an external AM antenna for AM recep- tion. 1. Carefully pull the antenna lead from the holding notch in the antenna and unwind the lead from the loop. 2. Connect the antenna leads to the terminals marked AM ANT.

  • Page 5: Aux Input

    1. Unplug the unit from electrical source. 2. Remove eight (8) screws securing the unit cover to the chassis. 3. Slide cover back to remove it from chassis. 4. Locate Jumper J1 on the circuit board (right side of the unit as you look at it from front panel).
  • Page 6 25V & 70V Connection You can connect a 25 or 70V balanced or unbalanced line to the terminals marked 25V or 70V and GND. 25V line connec- tion is shown below. Speaker Zone Connection You can connect up to 4 separate speaker zones. To connect zones of 4 - 8 ance selector jumper wire to the 4-8 shorting bar between the LINK terminals.
  • Page 7 To connect zones using 25V or 70V line: Connect the impedance selector jumper to the 25V or 70V terminal. Connect the line to the desired zone terminal and COM as shown below. Impedance selector wire from back of unit. Tape Out You can connect a tape recorder to the RM350D using the Tape Out jack.

  • Page 8: Operation

    Operation Power Press the front panel POWER switch to apply power. Adjust the volume to the appropriate level using the amplifier volume control. To Select a Band Press the button marked BAND. The current band appears on the display: FM1, FM2, FM3, AM1 or AM2. You can preset up to six stations on each band for a total of 30 preset stations (18 FM and 12 AM).

  • Page 9: Microphone Volume

    Microphone Volume Use the MICROPHONE control to adjust mic volume. Aux/Tuner Volume The VOLUME control adjusts the output level of program from tuner and aux sources. It does not control the level of the microphone program. Tone Controls Use the BASS and TREBLE controls to adjust tonal balance of program from the tuner, microphone and Aux sources.

  • Page 10: Maintenance

    The warranty will become void if repairs are made by other than the Bogen Factory Service Center. We are interested in the maintenance of your Bogen equipment. In the event of any difficulty, do not hesitate to ask our advice or assistance.
