Ameriwood HOME 2758305COM Instruction Booklet

Ameriwood HOME 2758305COM Instruction Booklet

Nightstand
Hide thumbs

Advertisement

Quick Links

Download this manual
2758305COM
Nightstand
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
B342758305COM0
Tough

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2758305COM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ameriwood HOME 2758305COM

Summary of Contents for Ameriwood HOME 2758305COM

  • Page 1 Visit: www.ameriwoodhome.com Easy Tough Assembly Difficulty Meter WARNING Follow Ameriwood Home - Unit can tip over causing severe injury or death. - Anchor unit to stud in wall (if instructed to). - Do Not allow children to climb on unit. Tube...

  • Page 2: Helpful Hints

    Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 ESTIMATED ASSEMBLY TIME: 1 HOUR...

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.

  • Page 4: Board Identification

    Board Identification Not actual size Left Panel Right Panel Bottom Kick 35780305050 35780305010 35780305020 35780305030 35780305040 Front Leg (2) Rear Leg (2) Drawer Front Drawer Bottom 35780305060 35780305070 35780305081 35780331090 This piece is paperboard construction. It is not made from wood, but is required for the assembly of your unit.
  • Page 5 Board Identification Not actual size This piece is paperboard construction. It is not made from wood, but is required for the assembly of your unit. ameriwoodhome.com Tube...

  • Page 6: Part List

    Part List Actual Size (x8) (x8) (x10) (x4) (x10) #A22570 #A22510 #A21660 #A22900 #A22910 cam lock cam bolt wood dowel connector connector bolt (x8) (x4) (x10) (x10) #A21110 #A11600 #A11080 #A12120 nail #6x1-1/4" screw 6x7/16" screw 8x7/16" screw Not Actual Size Left Cabinet Member Right Cabinet Member Left Drawer Member...
  • Page 7 STEP 1 (x4) #A22900 You will need to tap the connector (4) with a hammer to fully insert. Be sure the connector is positioned as shown before pushing into holes. ameriwoodhome.com...
  • Page 8 STEP 2 (x4) #A22900 You will need to tap the connector (4) with a hammer to fully insert. Be sure the connector is positioned as shown before pushing into holes. ameriwoodhome.com...
  • Page 9 STEP 3 (x8) #A22910 ameriwoodhome.com...
  • Page 10 STEP 4 End View Turn screw clockwise to lock in place. ameriwoodhome.com...
  • Page 11 STEP 5 Turn screw clockwise to lock in place. End View ameriwoodhome.com...
  • Page 12 STEP 6 (x3) #A11080 (x2) (x1) (x2) #A22570 #A21660 #A22510 Left Cabinet Member Quick Assembly Proper orientation of CAM LOCK Marked with an "L" ameriwoodhome.com...
  • Page 13 STEP 7 (x3) #A11080 (x2) (x1) (x2) #A22570 #A21660 #A22510 Right Cabinet Member Quick Assembly Proper orientation of CAM LOCK Marked with an "R" ameriwoodhome.com...
  • Page 14 STEP 8 (x4) (x2) (x2) #A22570 #A21660 #A22900 You will need to tap the connector (4) with a hammer to fully insert. Be sure the connector is positioned as shown before pushing into holes. Quick Assembly Proper orientation of CAM LOCK ameriwoodhome.com...
  • Page 15 STEP 9 (x2) #A22910 Turn screw clockwise to lock in place. ameriwoodhome.com...
  • Page 16 STEP 10 ameriwoodhome.com...
  • Page 17 STEP 11 (x4) #A22510 ameriwoodhome.com...
  • Page 18 STEP 12 ameriwoodhome.com...
  • Page 19 STEP 13 (x8) (x6) #A21110 #A12120 IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERTY. 1. With the help of another person, carefully turn the unit over. 2. Start with securing back panel with screws (8), but do not tighten. 3.
  • Page 20 STEP 14 (x2) #A54213 Lay the drawer sides down on a flat surface. Line up the drawer bracket with the holes in the drawer side as shown. Using a hammer, tap each drawer bracket stem part way into each hole. Repeat this process until the drawer bracket is fully seated on the drawer side. Bracket Orientation Bracket Orientation ameriwoodhome.com...
  • Page 21 STEP 15 (x4) #A12120 Center the grooves on the drawer sides with the groove on the drawer front. ameriwoodhome.com...
  • Page 22 STEP 16 finished surface ameriwoodhome.com...
  • Page 23 STEP 17 (x4) #A11600 ameriwoodhome.com...
  • Page 24 STEP 18 Left Drawer Member (x4) Right Drawer Member #A11080 (x1) #A56770 ameriwoodhome.com...
  • Page 25 STEP 19 roller cabinet member drawer runner Note: The drawer bracket holes are slotted. Drawer roller front can be adjusted by loosening screws, making needed adjustments and retightening screws. ameriwoodhome.com...
  • Page 26 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 40 lbs. 18.1 kg 15 lbs 6.8 kg 40 lbs. 18.1 kg Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is not approved for use with a television.
  • Page 27 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com...
