Orphek Atlantik V2 Wireless
Operational & Safety Guide
Orphek
LED
Lighting

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Atlantik V2 Wireless and is the answer not in the manual?

Questions and answers

Related Manuals for Orphek Atlantik V2 Wireless

Summary of Contents for Orphek Atlantik V2 Wireless

  • Page 1 Orphek Atlantik V2 Wireless Operational & Safety Guide Orphek Lighting...
  • Page 2 Please be fully familiarized with the information included in the Safety Guide and in this operational Guide before beginning installation or use of Orphek Atlantik V2 Wireless. Orphek is not liable for any damages of any kind resulting from the purchase,...
  • Page 3 Orphek Atlantik V2 Wireless at Glance What are the features? 78 customized high efficiency power LEDs Wi-Fi/ WLAN/ Wireless technologies Android technology Built-in battery backup memory High efficiency Mean Well drivers Eight pre-installed programs & four channels Full dimming capacity in all channels...
  • Page 4 What are the LED features? 10 pcs 410nm - wide range 18k UV - white LEDs 21pcs 420nm - wide range 6k violet - white LEDs 7 pcs 470nm wide range blue - cyan LEDs 10 pcs 450nm royal blue LEDs 7 pcs 430nm violet LEDs 4 pcs 410nm UV LEDs7 12 pcs full spectrum18000k white LEDs...
  • Page 5 What is in the box? One Light Unit One Power Box One Power Cord One Hanging Kit What are the dimensions? Length: 24.21” (615mm) Width: 9.37” (238mm) Height: 2.11” (53.6mm) Orphek Atlantik V2 Wireless dimensions...
  • Page 6 What are the specifications? Color/Materials Light Unit Body Material: White acrylic housing and silver stainless steel grill Weight Light Unit Weight: 215.lbs (7.6kg) Power box Weight: 3.97 lbs (1.02 kg) Cords Power extension cord with waterproof connector from Light Unit to Power Box: total 112″ (2.85m) Power Cord: 59″...
  • Page 7 Power consumption: 180 – 186 watt Electrical outlet: Region appropriate What is optional at an additional cost? Customized Ratio 2 chips in one LED (Orphek Atlantik V2 B) Mean Well Waterproof no fans driver 7” Android tablet Extension Cables from Light Unit to Power Box (118”/3m)
  • Page 8 Orphek Atlantik V2 Wireless looks like this! Orphek Atlantik V2 Wireless accessories look like this!

  • Page 9: Table Of Contents

    Epilepsy & Photosensitivity More Tips for Injury Prevention Important Safety Instructions for Installing your Atlantik V2 Wireless Safety Instructions for Storing your Atlantik V2 Wireless Safety Instructions for Cleaning your Atlantik V2 Wireless How to clean your Orphek Atlantik V2 Wireless...

  • Page 10: First Observations

    Never rely on your memory, read our manual and the safety guide before you start to install your Orphek Atlantik V2 Wireless and have it with you for reference during installation. If you have any questions, or did not understand any information of this guide please kindly contact Orphek Customer Assistance Team.

  • Page 11: Epilepsy & Photosensitivity

    These are some of the safety tips. Orphek cannot provide you a full guide. Please check a complete electrical safety guide for all...

  • Page 12: Important

    Your Orphek Atlantik V2 Wireless comes with an Orphek power supply – do not use another power supply from any other company Do not use extension cables provided by any other company. If extension cables and cords are needed, contact Orphek for a price quotation.

  • Page 13: Safety Instructions For Storing Your Atlantik V2 Wireless

    DO NOT use any form of alcohol or solvent to clean your Orphek Atlantik V2 Wireless. 10. Never place any objects or instruments on top of your unit(s) ordinances. 11. Do not pull or cut the cord.

  • Page 14: How To Clean Your Orphek Atlantik V2 Wireless

    9. Do not pull cords while cleaning your unit(s). Remember: Keeping your units clean is very important to keep your Orphek Atlantik V2 Wireless running well, but over or unnecessary cleaning may cause temporarily or permanently damage! So don’t over do it!
  • Page 15 Orphek Atlantik V2 Wireless Operational Guide Table of contents Getting Started Turning on the unit for the first time Checking your Wi-Fi connection Downloading Orphek App Set Ups How to set a wireless connection of the Android tablet/ mobile to the Atlantik unit Starting Set up for one unit 4B.1 Searching the light...
  • Page 16 5.2.2 Programming channels Clouds 5B.1 Understanding Clouds buttons & screen Feedback Final Observations...

  • Page 17: Getting Started

    2 Checking your Wi-Fi connection IMPORTANT: To install and use Orphek’s operational system you must have an Internet connection! Please go to settings in your android and turn Wi-Fi to ON as shown in the pictures:...

  • Page 18: Downloading Orphek App

    Please enter to Orphek Atlantik product website page http://orphek.com/orphek-atlantik-v2-wifi/ to download the program. Go to download folder in your android tablet or mobile: Inside your download files you will find Orphek App. Click on the App. to start installing the program.
  • Page 19 The next screen will ask if you want to install the application.
  • Page 20 Please click on the option INSTALL. Please wait until the installation is completed. Once it is completed the next screen confirming installation should appear. Please click on OPEN if you wish to open the program at this moment. If not, click DONE.
  • Page 21 If you don’t want to open the program and you have clicked the option DONE an Orphek App (with logo) should be displayed in your desktop screen: To open the Orphek App just click on the logo. OBS: Either by touching the Orphek App or by choosing OPEN at installation, Orphek’s first screen should open to start the...

  • Page 22: Set Ups

    Android tablet/mobile. At settings please enter to Wi-Fi settings. The wifi-socket name should appear in your listed Wi-Fi connections. The wifi-socket is the name of Orphek Atlantik unit wireless connection. To change this name please go to advanced settings ( ).
  • Page 23 In the next screen please click on the CONNECT button. Once the wifi-socket wireless connection is connected go to Orphek App. OBS: The wifi-socket name will appear in your wi-fi connection list only when your unit is turned on. YOU ARE NOW READY FOR AN ORPHEK EXPERIENCE!

  • Page 24: Starting Set Up For One Unit

    4B Starting Set up for one unit Click on the Orphek App to enter to the program again. The first Orphek screen should appear to you: Once the first screen has appeared the next screen should open in seconds automatically. It is the operational system’s home...

  • Page 25: Organizing Your Home Screen

    4B.1 Searching unit Since it is the first time you are using the program, the unit is not going to be displayed on screen. In this case click on SEARCH ID button and in about 10 seconds unit should be listed on screen.
  • Page 26 4B.2.2 Changing the date format of your light At the right side of the screen there is a DATE button, if you wish to alter the format click on it. A window with a menu of 9 options of date formats should appear on your screen. Please click to choose the date format of your preference.

  • Page 27: Main Menu

    5 Main menu To start programming your unit goes to operational home screen and click on SUBMIT button to enter to the programs’ menus: Quick set, Program, Clouds, Feedback. 5.1 Quick set Quick set will show to your light immediately but ONLY when staying in this page.

  • Page 28: Understanding The Quick Set Options

    5.1.1.Understanding the Quick set options Once you enter to Quick set screen you will see at the bottom of the screen 2 buttons displayed: ALL and Light 1. ALL button sets ALL ATLANTIK UNITS. Light 1 button sets ONLY THIS UNIT. You will also find 5 options for programming your Atlantik unit: ALL and 4 CHANNELS (1,2,3,4).
  • Page 29 Click on the button for ALL option displayed on the list of channel options if you wish to set all four channels, or choose which channel(s) (1,2,3,4) you wish to program by clicking on the button of each channel. Option one: Touch the button and move it from left to right to increase percentage (increase intensity).
  • Page 30 Click on the ⊳I button to have the main menu display on the right side of your screen. The main menu can be used just as the previous main menu.

  • Page 31: Program

    5B Program By choosing program in the main menu screen you will be able to set the program for all 4 channels. The PC card will remember all your settings for a month. If you do not make any changes all programs will repeat in month cycle.
  • Page 32 Beside program you will find the DATE button, which allows you to select and set the date of the program. Your Atlantik V2 Wireless unit comes with 4 channels: channel 1, channel 2, channel 3 and channel 4, as displayed on the screen.
  • Page 33 OPEN button opens a new window. RESET button clears what you have set before. 5B.2 Built-in Programs: If you wish to use Orphek’s built-in programs please click on SLOW ACCLIMATION button. The built-in programs are pre- programmed photoperiods chosen by Orphek staff after years of intensive research involving different wavelengths/spectrums.
  • Page 34 OBS: The SLOW ACCLIMATION button is also used as default button for the screen menu of the eight built-in programs. If you wish to stay and set slow acclimation please click on SEND button. The will send the slow acclimation program to the unit. Wait 5 seconds and the unit will operate accordingly.
  • Page 35 Increased Growth This program is designed to increase coral growth rate and is typically used when growing frags or immature coral colonies. Illumination 2 provides occasional cloud cast simulation while the remaining channels simulate changes in spectrum intensity throughout the day, which is typical on the reefs. Coral Color This program was designed to increase coral color while still providing plenty of PAR/PUR for good coral growth.
  • Page 36 Changing intensities & time You can also program several of your own photoperiods and adjust intensity of all four channels of light individually. This can be a useful feature in rooms flooded by sunlight or very dark rooms where adjustments in intensity will need to be made. It also allows you to control the lighting based on the types of corals you are keeping.
  • Page 37 Once you click on the SAVE button a window will open. Give a name to your customized program (with the changes you have set) and click OK: 5C Clouds This program will allow you to introduce clouds above your aquarium. It is good for acclimation of new corals when they are place on the shallower areas of your aquarium.
  • Page 38 5B.1 Understanding Cloud buttons and functions Once you enter to Clouds screen you will see at the bottom of the screen 2 buttons displayed: ALL and Light 1. ALL button sets ALL ATLANTIK UNITS. Light 1 button sets ONLY THIS UNIT. This program also offers you 2 options of programming: Strong Clouds and Soft Clouds.
  • Page 39 If you wish to erase it please click on CLEAR button. 5D Feedback Orphek wishes to hear from you! By clicking on FEEDBACK you will enter to our website contact page. This will only work if your unit is connected to a router.
  • Page 40 Final Observations For installation, connecting and programming more than one unit please use the Orphek Atlantik V2 Wireless Advanced Operational & Safety Guide.
