- Page 1 Cognex CFG-8700 Series Hardware Manual...
-
Page 2: Legal Notices
© 2014. Cognex Corporation. All Rights Reserved. Portions of the hardware and software provided by Cognex may be covered by one or more U.S. and foreign patents, as well as pending U.S. and foreign patents listed on the Cognex web site at: http://www.cognex.com/patents. - Page 3 Tip: Tips provide helpful suggestions and shortcuts that may not otherwise be apparent. Precautions Observe these precautions when installing the Cognex product, to reduce the risk of injury or equipment damage: To reduce the risk of damage or malfunction due to over-voltage, line noise, electrostatic discharge (ESD), power surges, or other irregularities in the power supply, route all cables and wires away from high-voltage power sources.
-
Page 4: Specifications
The CFG-8704e frame grabber is a PCI Express x4 compliant device for GigE Vision image acquisition. An CFG-8704e offers the following features: 4 independent GigE Vision Ethernet ports Non-volatile memory for storing Cognex security key information. Jumbo frames Power over Ethernet (PoE), IEEE 802.3af (48V, 15.4 W per channel) compliance LAN chip: Intel®... - Page 5 The CFG-8704e Frame Grabber General Specifications PCI Express PCIe x4 ports 1 port PCIe x4, for GigE Vision GigE Vision GigE Vision Ports RJ-45 Port The CFG-8704e supports 4 GigE Vision Ethernet ports. Signal MD10+ (PoE_DC48V) MD10- (PoE_DC48V) MDI1+ (PoE_DC0V) MDI2+ (PoE_DC48V) MDI2- (PoE_DC48V) MDI1- (PoE_DC0V)
-
Page 6: Status Leds
PC. If your cameras require more power, you should attach the connector to a separate power source. Security Bits The CFG-8704e supports non-volatile memory for storing security bit information. Your CFG-8704e arrives with particular security bits enabled, but can be reprogrammed to allow additional security bits later. Contact your Cognex sales representative for details. - Page 7 The CFG-8704e Frame Grabber See your software product documentation for more information on how your Cognex software uses a security system to ensure that the software is properly licensed. Installing the CFG-8704e Perform the following steps to install a CFG-8704e frame grabber: ...
- Page 8 Regulations/Conformity Regulations/Conformity Note: For the most up-to-date regulations and conformity information, please refer to the Cognex online support site: http://www.cognex.com/Support. Safety and Regulatory CFG-8704e: Regulatory Model 207-1031R Regulatory Model MSIP-REM-CGX-207-1031R RoHS Compliant to the latest applicable Directive.
- Page 10 January 2015...
