Summary of Contents for Mira flight SFE Pivot Enclosure
- Page 1 CFI254H Pivot Enclosure S S FE with 762, 800, 900 door (71 & 90) Fitting Instructions For latest prices and delivery to your door visit MyTub Ltd - www.mytub.co.uk - info@mytub.co.uk 0844 556 1818...
-
Page 2: Safety Precautions
People not familiar with the fitting of Mira products may require the assistance from another person at certain stages of the procedure. We have indicated these points in the process with the Caution Symbol. Caution Care &... - Page 3 Components IMPORTANT Do not remove the panel wall channel or transit clamps until the door has been fitted to the tray. Panel Wall Channel Door Wall Channel Transit Clamps Cover Strip Panel Magnetic Door Magnetic Side Panel Cover Strip Sealing Strip Sealing Strip Before installation check that all components are correctly supplied.
- Page 4 Glass Fixing Clamp Top Caps Fixing Bolt Glass Fixing Cover 4mm Allen Key Door Handle Assembly 3mm Allen Key Plug (2 Not Required) Glass Moulding Plug Spacer (1 Not Required) Splashguard 0844 571 5000 CFI254H For latest prices and delivery to your door visit MyTub Ltd - www.mytub.co.uk - info@mytub.co.uk 0844 556 1818...
- Page 5 Fit tray and then tile walls before fitting the unit. Carefully lay the door on a soft horizontal surface. Remove the tape from the transit clamps. NOTE Unit is reversible. RH fitting shown. LH fitting is a mirror image of these instructions. DOOR SIDE The door must be installed with the pivot by the wall, not the side panel.
- Page 6 Carefully lift the door assembly into place. Unscrew the bolts top and bottom and remove the panel wall channel. IMPORTANT Leave the transit clamps in place to support the door assembly. Caution The line on the wall channel marks the maximum amount of adjustment.
- Page 7 Have a person stand inside the enclosure. Break one spacer in half. Carefully lift the panel into place. Place the 3mm section into the base of the wall channel (Use the 6mm section or omit the spacer if the tray is not Caution perfectly level).
- Page 8 Carefully pull the transit clamp away from the Check that the door and panel are far enough into track and door. the wall channels to lock securely (See Step 11). Adjust if required. Lock the panel into the wall channel by turning the cam through 90 Locked position STEP...
- Page 9 Fit the seals to the side of the door and the For 762 & 800 enclosures, cut the splashguard side of the panel. to the correct length. 762 = 470mm 800 = 510mm (900 = 610mm Uncut) Fit splashguards to the underside of the door. The splashguard lip should face inside the The two magnetic strips should enclosure.
- Page 10 Fit the top caps. Slide the covers over the glass fixing clamps top and bottom. Note: If the glass is higher than the wall channel, trim away the recessed section of the top cap. STEP STEP Fit one of the smaller plugs to blank off each of the Lay a thin bead of sealant between wall channel holes on the panel side of the top and bottom tracks.
- Page 11 Lay a thin bead of sealant along the bottom of Fit the door handle. track and fill the gap between the glass and tray on the outside of the enclosure. Do not use the enclosure for at least 24 hours. 24hrs STEP STEP...
-
Page 12: Spare Parts
Spare Parts CFI254H For latest prices and delivery to your door visit MyTub Ltd - www.mytub.co.uk - info@mytub.co.uk 0844 556 1818... -
Page 13: Guarantee Of Quality
Our Service Force is available to provide a quality service at a reasonable cost. You will have the assurance of a Mira trained engineer/agent, genuine Mira spare parts and a 12 month guarantee on the repair. Payment should be made directly to the engineer via cheque on the day, alternatively an invoice will be sent after the visit if you would prefer to pay via credit or debit card.
