Manual plastic bending machine
O-501 / O-801 / O-1301 / O-2001 / O-1302 / O-2002 / O-1304 / O-2004
WARNING: do not place on machine unattended objects
Please use instructions for machine´s installation.
If a defect is detected, do not use the machine and contact the producer.
Make sure you have adequate ventilation when working with gasifying materials.
All occupants and personnel should be alerted to the potential hazards indicated by the product safety labelling on this unit.
The following conventions are used to indicate and classify precautions and on product safety labelling. Failure to observe
precautions could result in injury to people or damage to property.
WARNING: Never touch heating lines risk of burns.
WARNING: Always disconnect power, to the equipment and unplug, before performing any service or maintenance,
is detected, do not use the machine and contact the producer.
WARNING: No contact with flammable products
WARNING make sure you have adequate ventilation when working with gasifying materials.
Use heat resistant gloves
CAUTION: Do not operate without proper electrical ground
DANGER: To prevent the risk of severe or fatal electrical shock, special precautions must be taken.
Equipment should be plugged into an approved Ground Fault Circuit Interrupt (GFCI) receptacle.
Intended for indoor use only
Do not alter the construction or design. Do not remove safety labels or devices.
For keeping warranty always use machine according to usage and always use original parts for service.
Do not exceed equipment's maximum rated flow capacity and/or operating pressure.
Do not use equipment for other than its intended purpose, as described in the equipment manual.
Equipment should be protected from the elements and from temperatures below freezing.
On equipment with blowers keep inlet and outlet vents, clean and clear of objects.
CAUTION: Machine can be used only in dry places
Do not operate equipment if the power cord and/or plug are damaged, or if any other damage to the unit is visible or suspected.
Machine must not be disposed of in the trash.
Use safety goggles

Advertisement

loading
Need help?

Need help?

Do you have a question about the O-501 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ovili O-501

  • Page 1 Manual plastic bending machine O-501 / O-801 / O-1301 / O-2001 / O-1302 / O-2002 / O-1304 / O-2004 WARNING: do not place on machine unattended objects Please use instructions for machine´s installation. If a defect is detected, do not use the machine and contact the producer.
  • Page 2 A - ELEMENT HEIGHT ADJUSTMENT OF HEATING WIRE B - END STOP C - HEATING WIRE D - CONTROL PANEL E - ELEMENT FOR CHANGING AND ADJUSTMENT HEATING WIRE CONTROL PANEL OF MACHINE O-501, O-801, O-1301, O-2001 ON/OFF POWER BUTTON TEMPERATURE SETTINGS WORKING TIME SETTINGS START BUTTON...
  • Page 3 MACHINE O-1302, O-2002 A - ELEMENT HEIGHT ADJUSTMENT OF BOTTOM HEATING WIRE B - ELEMENT HEIGHT ADJUSTMENT OF TOP HEATING WIRE C - END STOP D - BOTTOM WIRE TEMPERATURE SETTING SHEATING WIRE E - TOP ARM WITH HEATING ELEMENT F - TOP HEATING WIRE G - ELEMENT FOR CHANGING AND ADJUSTMENT HEATING WIRE H - CONTROL PANEL...
  • Page 4 MACHINE O-1304. O-2004 A - WORKING TABLES B - POWER SWITCH C - POWER CORD CONNECTOR D - WORKING TABLE POSITION REGULATION SCREW E - FUSE FOR EACH HEATING LINE (4 PCS) F - ELEMENT HEIGHT ADJUSTMENT OF EACH HEATING WIRE G - GENERAL FUSE H - END STOP CONTROL PANEL OF...
  • Page 5 Bending process Bending process Materials such as PVC, PETG, polystyrene, etc., can be deformed after heating. You can heat precisely these plastics and make them deformable. 1. Place a flat board of plastic on the heating line area. 2. Switch "on" the machine. The distance between the heating wire and the work piece to be bent should be at least equal to the thickness of the work piece.
  • Page 6 It could be possible that you have to cut a little heating wire. Use only original heating wire Ovili., by contacting your provider. Reparing Repairs permitted only by a qualified electrician. During guaranty only by Ovili service. Before opening the control box, please unplug the machine.
  • Page 7: Technical Information

    Technical information O-501 O-801 working area length 19 1/2" | 50cm 31 1/2" | 80 cm working area width 2 x 9 1/4" | 2 x 23.5 cm 2 x 9 3/4" | 2 x 25 cm machine size 26 1/4" x 19" x 2 2/5" | 67x48.5x6cm 37 1/2"...
