,167$//$7,21 23(5$7,21 $1' 6(59,&( 0$18$/

7+,6 21/,1( ,167$//$7,21 0$18$/ ,6 3529,'(' )25 3/$1,1* 38326(6 21/< :(

5(6(59( 7+( 5,*+7 72 0$.( &+$1*(6 72 7+( 352'8&7 $1' 7+,6 0$18$/ )25

352'8&7 ,03529(0(17 385326(6 $/:$<6 5()(5 72 7+( ,167$//$7,21 0$18$/

$1' ,1&/8'( ,16758&7,216 3529,'(' :,7+ <285 352'8&7

PLEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLING AND

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or

any other appliance

*Do not try to light any appliance.

*Do not touch any electrical switch; do not use any phone in your building.

*Immediately call your gas supplier from a neighbors phone. Follow the gas suppliers

instructions.

*If you cannot reach your gas supplier; call the fire department.

Installation and service must be performed by a qualified installer, service agency or the gas

supplier.

This is an unvented gas fired heater. It uses air (oxygen) from the room in which it is

installed. Provisions for adequate combustion and ventilation air must be provided. See

Section 2

WARNING: This appliance is equipped for Natural Gas. Field conversion is not

permitted.

INSTALLER: Leave this manual with the appliance.

CONSUMER: Retain this manual for future reference.

WARNING: If the information in this manual is not followed exactly, a fire or

explosion may result causing property damage, personal injury or loss of life.

Old Salem Collection

Vent Free Box with Classic Coals

WHAT TO DO IF YOU SMELL GAS:

OPERATING THE APPLIANCE.

Page 1 of 16

2/' 6$/(0 *$6 &2$/ 9(17 )5(( ),5(3/$&(

Table of Contents

Need help?

Do you have a question about the Old Salem Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Four Seasons Supply Old Salem Series

Page 1 2/' 6$/(0 *$6 &2$/ 9(17 )5(( ),5(3/$&( ,167$//$7,21 23(5$7,21 $1' 6(59,&( 0$18$/ Old Salem Collection Vent Free Box with Classic Coals 7+,6 21/,1( ,167$//$7,21 0$18$/ ,6 3529,'(' )25 3/$1,1* 38326(6 21/< :( 5(6(59( 7+( 5,*+7 72 0$.( &+$1*(6 72 7+( 352'8&7 $1' 7+,6 0$18$/ )25 352'8&7 ,03529(0(17 385326(6 $/:$<6 5()(5 72 7+( ,167$//$7,21 0$18$/ $1' ,1&/8'( ,16758&7,216 3529,'(' :,7+ <285 352'8&7 PLEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLING AND...
Page 2 2/' 6$/(0 *$6 &2$/ 9(17 )5(( ),5(3/$&( 7$%/( 2) &217(176 3J '(6&5,37,21 $1' '5$:,1*6 2) 7+( µ 9(17)5(( ),5(3/$&( $66(0%/$*( 3J '(7$,/(' '5$:,1* 2) 7+( µ =(52 &/($5$1&( ),5(%2; 3J :,5,1* ',$*5$0 )25 5(027( &21752/ 237,21 3J *(1(5$/ ,16758&7,216 )25 7+( 9(17)5(( µ...
Page 3 2/' 6$/(0 *$6 &2$/ 9(17 )5(( ),5(3/$&( The Old Salem vent free gas coal fireplace consists of a large firebox and a small firebox which are bolted together. This assembly provides the double wall construction needed to make the 20” a Zero Clearance Firebox.
Page 4 OLD SALEM GAS COAL VENT FREE FIREPLACE Page 4 of 16...
Page 5: Gas Valve
OLD SALEM GAS COAL VENT FREE FIREPLACE SCHEMATIC OF THE ELECTRICAL CONNECTIONS FOR VARIOUS INSTALLATIONS OPTIONAL REMOTE OR WALL SWITCH l8 GuageWire — (Rated 237 deg F. 125 Deg. C) * Supplied with Remote *Supplied by Installer for Wail Switch (Shown configured for wall switch) THERMOPILE JUMPER INSTALLED ON GAS...
Page 6 OLD SALEM GAS COAL VENT FREE FIREPLACE WARNING: This appliance is for installation only in new stud/fireproof sheet rock or masonry construction. (a) The minimum size of the opening in the framing structure should be: Width: 23.5” Depth: 13.5” Height: 34” The inside measurements of the firebox are: Width: 20”...
Page 7: Combustion Air
OLD SALEM GAS COAL VENT FREE FIREPLACE WARNING: Some state or local codes may not allow operation of unvcnted appliances. Check your state or local codes. 2) COMBUSTION AIR (a) WARNING: If the area in which the appliance is to be operated is smaller than 750 cubic feet, or it the building is of an unusually tight construction, adequate combustion and ventilation air must bc provided by one of the methods described in the National Fuel Gas Code ANSI Z223.1/NFPA 54, Air for Combustion and Ventilation, or applicable local codes.
Page 8 OLD SALEM GAS COAL VENT FREE FIREPLACE 4) INSTALLATION INSTRUCTIONS FOR THE 20” VENTFREE ZERO CLEARANCE F1REBOX ASSEMBLAGE IMPORTANT: The main gas supply shutoff valve/tap must never be located inside the fire box and must be within arm’s length from the fire and accessible at all times. The manufacturer cannot and will not accept any warranty claim if the appliance has not been installed to comply with the following instructions and with local and National Codes.
Page 9: Operation
OLD SALEM GAS COAL VENT FREE FIREPLACE fireplace opening. 5) OPERATION The ventfree firebox is a passive sheet metal installation and as such. has no operating instructions. Its use, however, with the coal set must be in compliance with the section for installation of that appliance.
Page 10 OLD SALEM GAS COAL VENT FREE FIREPLACE (c) Any safety screen or guard removed for servicing must be replaced Prior to operating the appliance. (d) The coal set is provided as a completed assembly with no loose parts. If improper handling should result in one or more of the coals becoming loosened, the coals must be repositioned in exactly the same position into which they were first attached.
Page 11 OLD SALEM GAS COAL VENT FREE FIREPLACE 10) APPLIANCE LOCATION CLEARANCE (a) Due to high temperatures the appliance should be located out of traffic and away from furniture and draperies. (b) Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or clothing ignition.
Page 12: For Your Safety Read Before Lighting
OLD SALEM GAS COAL VENT FREE FIREPLACE available upon request. 12) VENTING (a) No venting per se is required, however, review section “2) COMBUSTION AIR” for information relative to air availability requirements. 13) INSTALLATION INSTRUCTIONS FOR THE COAL BURNER IMPORTANT: The main gas supply shut-off valve/tap must never be located inside the firebox and must be within arm’s length from the fire and accessible at all times.
Page 13: What To Do If You Smell Gas
Should any of the coals become mislocated the flame pattern changes drastically, contact your distributor or call Four Seasons Supply immediately. The Coal unit is repairable only at the manufacturer.
Page 14: To Turn Off Gas To Appliance
OLD SALEM GAS COAL VENT FREE FIREPLACE 4. Wait five minutes to clear out any gas. Then smell for gas, including near the floor. If you smell gas, STOP! Follow “B” in the safety information above on this page. if you don’t smell gas, go to the next step.
Page 15: If You Smell Gas
In the event of some other malfunction a phone call to your certified maintenance technician is recommended. Should such a person he unavailable, call (Four Seasons Supply) immediately for assistance in talking through the problems symptoms. IMPORTANT: The appliance is not field repairable due to the sensitive nature of the requirements for Monoxide emissions.
Page 16: Replacement Parts List
Natural Gas ODS Valve SIT Controls 820.637 NG ODS Pilot Assembly SIT Controls 8204C Piezo Igniter SIT Controls 073.953 Four Seasons Supply Co. Winston Salem North Carolina PH 336 682 3241 www.coalbaskets.com MADE IN THE USA Page 16 of 16...
