DIGITAL MIXER 6 ZONE LTS.PM62
Operation manual
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
Linear Technologie • 11 rue du Puits Rochefort • 42 100 Saint-Etienne
V.2017
Tél: +33 (0)4 77 81 49 49 • Fax: +33 (0)4 77 81 49 40 • www.lineartech.fr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LTS.PM62 and is the answer not in the manual?

Questions and answers

Summary of Contents for Linearsound LTS.PM62

  • Page 1 DIGITAL MIXER 6 ZONE LTS.PM62 Operation manual Please follow the instructions in this manual to obtain the optimum results from this unit. We also recommend that you keep this manual handy for future reference. Linear Technologie • 11 rue du Puits Rochefort • 42 100 Saint-Etienne V.2017...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety precautions Page 3 2. General description Page 5 3. Features Page 5 4. Nomenclature and functions Page 5 a. Front panel b. Rear panel 5. Operation Page 7 6. Connections Page 7 7. Applications Page 8 8.

  • Page 3: Safety Precautions

    1. SAFETY PRECAUTIONS • Be sure to read the instructions in this section carefully before use. • Make sure to observe the instructions in this manual as the conventions of safety symbols and messages regarded as very important precautions are included. •...
  • Page 4 • To prevent a fire or electric shock, never open or remove the unit case as there are high voltage components inside the unit. Refer all servicing to your nearest dealer. • Do not place cups, bowls, or other containers of liquid or metallic objects on top of the unit.

  • Page 5: General Description

    Note : An all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in the electrical installation of the building. 2. GENERAL DESCRIPTION The PM62 is a digital 6 zone mixer can provide an ideal public address solution from small to big places such us mosques, schools, hotels and factories to train stadium and air stations.
  • Page 6 13. PLAY : Key switch play message for manual activation. 14. ACTIVE : Indicator play message. 15. MIC : Internal microphone for message recording. a. Front panel 16. AC INLET : Connect to the supplied power cord. 17. IN COMMON RELE MUSIC ZONE 18.

  • Page 7: Operation

    5. OPERATION Operation attention 1. Dial REC message switch in rear panel to 1, 2, 3, which means 1, 2, 3 storage. Press REC, the indicator will be active, input signal to MIC port, start record. Press stop, it will stop record (it should be recorded mAX audio 1 minute for every storage.

  • Page 8: Applications

    Net production line method Blue White blue Brown White brown Orange White orange Green White green 7. APPLICATIONS 1 amplifier for music, 1 amplifier for voice for 6 zone.
  • Page 9 6 amplifiers one for each zone.

  • Page 10: Address Set

    8. ADDRESS SET ID console address set.
  • Page 11 ID console address set.

  • Page 12: Block Diagram

    9. BLOCK DIAGRAM...

  • Page 13: Specifications

    10. SPECIFICATIONS Sensitivity -50 / -2 dB 2, 5 / 500 mV S/N ratio >68 dB Frequency response 100 / 17.000 Hz (-3 dB) 1 microphone input Phantom power Tuner and tape input sensitivity / impedance 200 mV / 47 Kohm CD input sensitivity / impedance 500 mV / 47 Kohm S/N ratio...
