Summary of Contents for MANPA MP21-14
- Page 1 PRODUCT’S INSTRUCTION MANUAL Model Number BELT SANDER (MP21-14) TABLE OF CONTENTS 1. Product composition & specification 2. Manufacture information ORIGNAL INSTRUCTION PROVIDED 3. Unpacking and assembly BY MANPA TOOLS 4. How to fit sandpaper center 5. Maintenance PLEASE READ ALL MANUAL FOR SAFETY 6.
- Page 2 Overall Length : 300 mm Power : 630 ~750 Watt Working width : 30 mm Sandpaper width : 30 mm Model : MP21-14 Sandpaper Hardness : #40 2. Manufacture information - Manufacturer : Manpatools Corporation - Country of manufacture : Made in Republic of korea...
- Page 3 3. Unpacking and assembly Drive Roller Please prepare a Belt sander and First, the roller is attached to angle Attach the body to the grinder. angle grinder Grinder. grinder. (Make sure no gap in between) Only Bosch or Makita can be installed.
- Page 4 4. How to fit sandpaper center Upper Bolt Bottom Bolt 3.5mm L Control bolt wrench Image 1. Image 2. Image 3. In order to fit center of sand paper, the Housing and Control bolt(right side) need to be adjusted with delicate. After putting sand paper, prepare 3.5mm L wrench and clear the control bolt if it is dirty.
- Page 5 6. Safety instruction Use of Belt sander is recommended by someone at least 18 years old or older with the experience of using grinder in woodcraft or woodcarving industry. Also, always follow the safety precautions during use. If you never used a grinder, we recommend that you receive instructions and safety training from someone that can handle grinder proficiently.
- Page 6 7. Safety precautions Please read and understand all safety precautions, instructions, explanations and specifications provided with this product thoroughly for safe work and accident prevention. a. Work area safety user loses control of the tool due to kickback, and it jumps up or cuts any - Always keep the light in work area bright.
- Page 7 d. Safety matters about tools. - Please maintain the rotation speed at above 11000RPM. If the rotation speed is lowered, the surface of wood may not be smooth, and may bear too much load. - Do not remove any safety devices or parts installed on product, but use them together. It can prevent any sudden accidents and protect your body.
- Page 8 ORIGNAL PRODUCTS INSPECTED & PROVIDED BY MANPA TOOLS...
