SERVICE MANUAL
1. Caution....................................................................................
2. Specification..............................................................................
3. Alignment Procedure..................................................................
4. Troubleshooting .....................................................................
5. Scheme Diagram........................................................................
6. Explode drawing................................................................................................
This manual is the latest at the time of printing, and does not
include the modification which may be made after the printing, by
the constant improvement of product
32D1240_3MS663
