JooVuu X Manual
Welcome!
Congratulations on your JooVuu X camera and welcome to the JooVuu family. This
complete manual will give you indepth knowledge of the camera specifications,
features, and app.
Remember to check us out on:
Facebook.com/JooVuu
Twitter.com/JooVuu
Instagram.com/JooVuuX
YouTube.com/JooVuu
The JooVuu X WiFi password is 1234567890 by default. This can be changed in
the settings.
The WiFi will be turned off on the camera automatically after 2 minutes of
inactivity and no commands being sent. This is normal and cannot be altered.
The microSD once inserted into the camera needs to be formatted. Please do
this immediately. You can find how to do this below.
MicroSD cards MUST be Class 10
45mb/s or faster.
occur with slower cards. You can
purchase compatible cards from
www.JooVuu-X.com
reseller.
Vital Information
1
Important:
Problems can
or any JooVuu X

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X and is the answer not in the manual?

Questions and answers

Summary of Contents for JooVuu X

  • Page 1 YouTube.com/JooVuu reseller. Vital Information The JooVuu X WiFi password is 1234567890 by default. This can be changed in the settings. The WiFi will be turned off on the camera automatically after 2 minutes of inactivity and no commands being sent. This is normal and cannot be altered.

  • Page 2: Important Information

    The camera’s default wifi password is 1234567890 You must format the microSD card inside the camera before operation Please leave the camera to charge 1hour before installing it in your car. The JooVuu X can be charged through a USB wall plug or your PC.

  • Page 3: Table Of Contents

    All Features: ........................... 5 Available Resolutions: ......................6 LED Key ............................7 Operation (Camera) ........................8 Inserting the microSD card into the JooVuu X ............... 8 Turning on the JooVuu X ......................9 Changing Mode ........................9 Stop and Start Record ......................9 Turn On/Off WiFi ........................

  • Page 4: Features & Specifications

    Features & Specifications Hardware Beeping for certain functions (can be turned Ambarella A7LA75 off) 7G Lens F2 128gb microSD support 155 degree lens Standard tripod hole mount OVI sensor -15 to +60c working temperature G-Sensor GPS enabled (extra) Stereo microphone Manual button for video file lock.

  • Page 5: All Features

    All Features: Auto-record with power on Loop recording Clip recording (1min, 3min, 5min, 10min, continuous) clips Seamless loop recording Motion detection (choose sensitivity and length of recording) HDMI out G-Sensor (auto lock function will be enabled by default). Different sensitivities: High, medium, low, off.

  • Page 6: Available Resolutions

    Available Resolutions: All available resolutions are posted here and will be updated here and on the website: 2560x1080P 30FPS (21:9) 2304x1296P 30FPS (16:9) 1920x1080P 60FPS 1920x1080P 45FPS 1920x1080P 30FPS (HDR) 1920x1080P 30FPS 1280x720P 60FPS 1280x720 30FPS...

  • Page 7: Led Key

    Top LED Back LED Beep Noise LED Colour: Blue Red & Red & ------ Green Green Turn JooVuu X on Flickers Flickers then goes to standby that has a different LED sequence) Camera turns off Flashes Flashes three times three times...

  • Page 8: Operation (Camera)

    1) Insert a microSD, microSDHC™ or microSDXC™ card into the card slot with label facing the floor if the buttons on the JooVuu X are facing upwards. Insert the card with the narrowest part of the card going into the camera.

  • Page 9: Turning On The Joovuu X

    8gb to 128gb. Turning on the JooVuu X 1) Make sure the JooVuu X is plugged into a car, computer, or USB wall plug. 2) The camera should turn on automatically when plugged in. 3) To turn the camera off, simply press the on/off button for 3 seconds and then release.
  • Page 10 2) Insert microSD card into the camera 3) Press down M button for 3 seconds 4) Press the power button 5) Top LED should flash red – this means the card has been formatted successfully.

  • Page 11: Operation (App)

    Operation (App) The app allows full control over the JooVuu X from changing settings, to formatting the microSD card, to viewing the photos. This section takes you through each option. Formatting the MicroSD card 1) Connect the camera to your smartphone or tablet (outlined in step 4)

  • Page 12: App Breakdown

    App breakdown 1) JooVuu logo – click on this to get to reset, format, and white balance screens 2) Main settings – these settings are global, and will be applied to all Modes 3) Mode settings – these settings are specific to that Mode 4) Gallery –...

  • Page 13: Main Settings

    Select the format in which the date is displayed Select if the camera makes audible beeps Select if you want the JooVuu X to use its LEDs Select Mode 1 or 2 for the camera to start Auto-start with power or only when...

  • Page 14: Mode Settings

    Mode Settings Change between, Mode 1, Mode 2, and photo Mode. Pick the resolution for a chosen mode. See HDR below. Enable or disable audio recording Display time stamp on the video ‘Flip’ the image. If hanging the camera upside down, this should be turned on. Once the card is full the camera will overwrite the first file and so forth High, medium, low*...

  • Page 15: Wide Dynamic Range

    However, higher bitrates cause larger files and as such less data can be stored. The default for the JooVuu X is set at ‘Medium’ as this strikes the best balance between quality and recording time for your microSD card.

  • Page 16: Live Stream

    Live Stream The Live Stream function enables you to see what the JooVuu X sees. The range is about 10m (depending on the environment). 1. Advanced Settings – this screen allows you to control the: Exposure, contrast, sharpness and white balance settings.

  • Page 17: Gallery

    Gallery The gallery is where you can view all of your recordings and photos. You can stream them to your device of choice or download them to enjoy them in full HD quality. You can delete photos and videos as well as upload them to popular websites. Display either videos, photos, or all.

  • Page 18: Technical Information

    The camera can use ANY standard 5pin mini USB cable for power and data transfer. JooVuu is a UK registered business and owns JooVuu X By reading this manual you agree to give us your soul and happiness. Help & Questions?
