Electric Star PC03A User Manual

electric-star.com - info@electric-star.com
Portable charger for electric vehicle
EFFICIENT
- Max 3.7 kW
SMART
- Boxless design
UNIVERSAL
- Highly convenient
SAFETY
- Overheating protection

INTRODUCTION

The PC03A portable charger is dedicated to charge any
electric or hybrid vehicle having a Type 2 socket (Euro-
pean standard). It can be plugged in any domestic or
industrial electric socket, directly or using an adapter if
necessary. PC03A is completely universal. It fits any ve-
hicle, no matter its brand. Charging power is easily set
by the user thanks to the convenient integrated button.
This portable charger takes advantage of a unique

HOW TO USE ?

START CHARGING:
1. Plug the charger into an electric socket.
2. RCD - Press "RESET" on RCD device (see page 3).
Its LED turns green.
3. Charger's LED starts blinking in order to indicate
what charging power is currently set (see page 2).
4. LED remains fixed to show it is waiting to be used.
5. Plug charger into vehicle.
6. LED blinks slowly in order to indicate that vehicle is
currently charging.
© Electric-Star
PC03A
design since all charging electronics is directly in-
tegrated in the Type 2 plug ! Thanks to that smart and
revolutionary design, there is no box attached to the
charger, contrary to other solutions available on the mar-
ket. In other words, it is more convenient, lightweight,
easy to use and easy to store. PC03A is made from pre-
mium quality materials which is highly essential. Pow-
er and safety are both provided by this unique charger.
END CHARGING:
1. When vehicle is charged, charger's LED remains
fixed (no more blinking).
2. Unplug charger from vehicle, depending on the re-
quired procedure for your vehicle.
3. Have a nice trip :)
ES-PC03A-USER-MANUAL-EN-v2
USER MANUAL
Page 1
