SmartPool EZ LIGHT EZ2420 Instruction & Operation Manual

Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Important Safety Instructions ..........................................................................1
List of Components and Specifications............................................................2
Installation ...................................................................................................2-5
Operation ........................................................................................................5
Winterization...................................................................................................6
Troubleshooting...............................................................................................7
Warranty.............................................................................................8
!
To reduce the risk of injury, do not permit children to use this product unless they are
WARNING:
closely supervised at all times.
!
Any modifications to this product will void the warranty.
WARNING:
!
Do not allow children to use, touch, or play near or around the unit's power pack.
WARNING:
!
Do not use if unit is damaged in any way.
WARNING:
Make sure the battery is removed before opening the unit or performing any other
!
WARNING:
maintenance.
To protect against risk of electrical shock, do not perform maintenance while standing in
!
WARNING:
water or in pool.
!
If the light is not working as it should or has been dropped or damaged in any way,
CAUTION:
contact
INSTRUCTION/OPERATION MANUAL
FOR EZ LIGHT
MODEL: EZ2420

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS

READ AND FOLLOW ALL INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZ LIGHT EZ2420 and is the answer not in the manual?

Questions and answers

Summary of Contents for SmartPool EZ LIGHT EZ2420

  • Page 1 INSTRUCTION/OPERATION MANUAL FOR EZ LIGHT MODEL: EZ2420 TABLE OF CONTENTS Important Safety Instructions ................1 List of Components and Specifications............2 Installation ....................2-5 Operation ......................5 Winterization....................6 Troubleshooting....................7 Warranty……………............……………….8 IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS To reduce the risk of injury, do not permit children to use this product unless they are WARNING: closely supervised at all times.
  • Page 2 LIST OF COMPONENTS BATTERY LIGHT: COMPLETE SYSTEM WITH RETURN ITEM DESCRIPTION WHITE LED LIGHT STRAIGHT RETURN FITTING 90 DEGREE RETURN FITTING PRESSURE CLEANER FITTING CONTROL SWITCH/BATTERY CASING POWER PORT PLUG WINTER PLUG HOSE CLAMP RETURN W/SEAL RING AND PLUG THREADED HOSE ADAPTOR FLEX HOSE ADAPTOR TEFLON TAPE BLUE MOUNTING SCREWS...
  • Page 3 Step 1: Preparing the Light 1) Remove the (2) screws that secure the control to the return fitting (Figure 1). IMPORTANT: Keep these screws and control switch readily available for use in the following steps. 2) Remove the large nut, along with the washer and one gasket (Figure 2 and 3). IMPORTANT: Ensure to leave one gasket on the light to seal on the inside of the pool.
  • Page 4 Step 3: Installing the EZ Light/Fitting CAUTION: Be careful not to rest tools or light on the top ledge of the pool as objects may fall into the pool. IMPORTANT: Have the EZ light prepared as instructed in Step R1, ensuring one gasket is on the return.
  • Page 5 Step 4: Installing the Battery 1) Remove the (4) screws from the battery casing (Figure 9). 2) Align the battery (not included) with the contacts of the battery housing (Figure 10). 3) Install the battery casing and secure using the (4) screws (Figure 11). NOTE: The curved portion of the casing should face the pool wall.
  • Page 6 WINTERIZATION Leaving Water Level Above the Return IMPORTANT: Winterization of the EZ Light does not cover the winterization of your filter system. Please follow the filter manufacturer’s recommendations for winterizing your system. NOTE: Some water will drain from the pool during this process. 1) Remove the 2 screws securing the battery housing to the return fitting (Figure 15).
  • Page 7 Light Not Turning ON or is Flashing TROUBLESHOOTING 1) Ensure the battery still has power (try a new battery). 2) Ensure the battery is securely installed/resting on the contacts (Figure 10). Light Not Turning ON or is Flashing 3) Make sure the return fitting is level as this could cause the battery to tilt (Figure 5). 4) Ensure the battery housing is installed correctly (Figures 12 and 13).
  • Page 8 1 YEAR LIMITED WARRANTY One year limited warranty from date of original purchase for manufacturing defects under normal and reasonable use, and subject to the maintenance requirements and installation guidelines set forth in the product instruction manual. This warranty applies only while using this product in the United States and Canada. Customers outside the continental United States will be responsible for inbound and outbound freight on all claims.
