- Page 1 ST805C PON Power Meter User Manual V 1.1 Shandong Senter Electronic Co., Ltd...
-
Page 2: Table Of Contents
ST805C PON Power Meter CONTENTS 1. Summary ................2 2. Main Features ..............2 3. Function and Technical specification Function ....3 4. Configuration ..............6 5. Operation Instruction ............8 5.1 ON/OFF .............8 5.2 Relative value (differential loss) ......8 5.3 Threshold setup ..........9 5.4 Time setting ............9 5.5 Auto power off ..........10... -
Page 3: Main Features
ST805C PON Power Meter 1. Summary PON Power Meter is specially designed for PON network construction and maintenance which can be connected between OLT and ONT. The voice, data, video signal (1310nm/1490nm/1550nm) online can be measured synchronously and optical power value can be displayed with this meter. - Page 4 ST805C PON Power Meter Can set the threshold value, upload data, and calibrate wavelength through management software 32 digits CPU, easy to operate, simple and convenient Auto power off, auto backlight off, low voltage power off 3. Function and Technical specification Function ...
- Page 5 ST805C PON Power Meter @1490nm(dB) Isolation >40 >40 @1550nm(dB) Accuracy Uncertainty(dB) ± 0.5 Polarization Dependent Loss <± 0.25 (dB) Linearity(dB) ± 0.1 Through Insertion <1.5 Loss(dB) Resolution 0.01dB Unit dBm/xW Storage number: 99 items Auto backlight off time: 30 seconds ...
-
Page 6: Configuration
ST805C PON Power Meter 4. Configuration Figure 1: Front view... - Page 7 ST805C PON Power Meter Figure 2: Top View ONT interface: Connect with ONT equipment through pigtail when testing. OLT interface: Connect with OLT equipment through pigtail when testing. Figure 3: Side View...
-
Page 8: Operation Instruction
ST805C PON Power Meter USB connector: Communicate with the management software through USB connector. Charge connector: Connect with adapter to charge the meter. 5. Operation Instruction 5.1 ON/OFF Press "ON" key for about 3 seconds, meter will power on, main menu will be displayed as figure 1. The meter is on normal working mode, and then user can process related measurement. -
Page 9: Threshold Setup
ST805C PON Power Meter Press "F2" to exit relative value test after finishing test. 5.3 Threshold setup Under main interface, long press "▲" to enter 5.3.1 threshold management interface. Choose threshold group number by "▲", "▼", and 5.3.2 then browse three threshold values (1310nm, 1490nm, 1550nm) through "◄", "►"... -
Page 10: Auto Power Off
ST805C PON Power Meter "►","◄", and then press "OK" to save or press "OFF" to exit. Exit automatically without operation in 10 seconds. 5.5 Auto power off Under main interface, short press "OFF" to switch between auto power off and manual power off, icon displays when auto power off;... -
Page 11: Maintenance
ST805C PON Power Meter 6. Maintenance 1. Keep the sensor’s head face clean, make sure there’s no dust, no contamination, don’t use unclean and nonstandard adapters, don’t insert poor polished surface, or else it will damage the sensor’s head face. - Page 12 ST805C PON Power Meter Shandong Senter Electronic Co., Ltd. No.18, Liu Yishan Road, New&Hi-tech Area, Zibo City, Shandong Province, China 255086 Tel: 86-533-3589257 Fax: 86-533-3587522/3589257 Email: export@senter.com.cn http://en.senter.com.cn/...
