Assembly Instructions
Assembly Packing List
M6 Screws
M6 Nuts
12-24 Screws
QTY: 12
QTY: 12
QTY: 24
Top and Bottom
Side Bracket
Mounting Profile
Grounds
Bracket
QTY: 2
QTY: 4
QTY: 1
QTY:2
Step 1: Position side brackets
To start, position both side brackets parallel to each other.
1/2
Advertisement
Table of Contents
Summary of Contents for NetworX WMR S301
- Page 1 Assembly Instructions Assembly Packing List M6 Screws M6 Nuts 12-24 Screws QTY: 12 QTY: 12 QTY: 24 Top and Bottom Side Bracket Mounting Profile Grounds Bracket QTY: 2 QTY: 4 QTY: 1 QTY:2 Step 1: Position side brackets To start, position both side brackets parallel to each other.
- Page 2 Assembly Instructions Step 2: Adjust depth and mount top and bottom brackets Next, find the desired depth and secure the top and bottom brackets to the side brackets using 12 M6 screws and nuts. (Use 3 screws and 3 nuts for each of the four sides, like seen above) Step 3: Attach mounting profile to the top and bottom brackets To position the mounting profile on the front opening of the frame, pull back the metal pins located on the inside of the mounting profile,...
