POWER SWEEPER ATKSP120
Never store any machine
with raw, unstabilized gas
in it unless it's packaged
fuel,
which
does
contain
ethanol
additives and is sold in
steel cans at hardware
stores, home centers, and
outdoor-power-equipment
dealerships. Storing an
engine with unstabilized
gas in it for more than 30
days will void the engine
manufacturers warranty.
OPERATION & PARTS MANUAL
FOR YOUR SAFETY!
Please read these instructions carefully before using! Check all fluid
levels before each use! GREASE ALL FITTINGS BEFORE OPERATING!
Rugged Labor Saving Equipment Since 1995
Specifications subject to change without notice.
not
or
Save This Manual for Future Reference
www.Betstco.com
Phone: 541-895-3083
E-mail cservice@betstproducts.com
83371 Melton Rd, Creswell OR
97426
1
1
Revision 11-22-17
