Summary of Contents for Ted Baker TWO-HAND Series

  • Page 3 Ted Baker is manufactured using the highest quality materials and craftsman- ship. The incorporation of both traditional and forward thinking design philosophies result in a unique and modern product.
  • Page 4 LIMITED LIFETIME WARRANTY Thank you for choosing a Ted Baker precision timepiece. This Ted Baker Watch is warranted to you, the owner, for your lifetime against all defects in material or workmanship. Limited lifetime warranty will be honored only by Service Center in the United States, Canada, Caribbean as well as Authorized Duty Free and Military Dealers.
  • Page 5 BATTERY LIFE The battery in your Ted Baker Watch should last approxi- mately 2 years. When the battery expires, replace it as soon as possible to prevent any malfunction. For battery replace- ment, we recommend that you contact an authorized Ted Baker Dealer.
  • Page 6 TWo-HAND / THREE-HAND MoDELS 1.Second Hand To SET THE TIME: 1. Pull the crown out to the first click position B. 2. Turn the crown to set the time. 3. Push the crown back to position A.
  • Page 7 THREE-HAND MoDELS WITH BIG DATE 1. Calendar 2. Second Hand To SET THE TIME: 1. Pull the crown out to the second click position C. 2. Turn the crown to set the time. 3. Push the crown back to position A. To SET THE DATE: 1.
  • Page 8 oNE-EYE MoDELS 1. Hour Hand 2. Minute Hand 3. Second Hand 4. Date Hand To SET THE TIME: 1. Pull the crown out to the second click position C. 2. Turn the crown to set the time. 3. Push the crown back to position A. To SET THE DATE: 1.
  • Page 9 TWo-EYE MULTI-FUNCTIoN MoDELS 1. Second Hand 2. Day Hand 3. Date Hand 1. Second Hand 2. Date Hand 3. 24 Hour Hand To SET THE DAY (oF THE WEEK): 1. Pull the crown out to the second click position C. 2.
  • Page 10 To SET THE TIME: 1. Pull the crown out to the second click position C. 2. Turn the crown to set the time. 3. Push the crown back to position A. NOTE: The 24 Hour Hand will also be set during time setting.
  • Page 11 THREE-EYE MULTI-FUNCTIoN MoDELS 1. Hour Hand 2. Minute Hand 3. Second Hand 4. Date Hand 5. Day Hand 6. 24 Hour Hand (6P29) To SET THE DAY (oF THE WEEK): 1. Pull crown out to second click position C. 2. Turn crown clockwise to set day. 3.
  • Page 12 To SET THE DATE: 1. Pull crown out to first click position B. 2. Turn crown counter-clockwise to set date. 3. Push crown back to position A. NOTE: Do not set the date between 9:00 P.M. and 1:00 A.M. Otherwise, the date may not change properly on the following day.
  • Page 13 THREE-EYE CHRoNoGRAPH MoDELS 1. Hour Hand 2. Minute Hand 3. Second Hand or Chronograph 1/20 Second Hand 4. 24 Hour Hand 5. Chronograph Minute Hand 6. Chronograph Second Hand A B C 7. Calendar S1 – Chronograph start/stop button S2 – Chronograph reset button To ADJUST THE CHRoNoGRAPH HANDS PoSITIoN: Before setting the time, check if the Chronograph 1/20...
  • Page 14 In case one or several chronograph hands are not at the zero position due to certain reasons (e.g. following a battery change), that needs to be adjusted. 1. Pull the crown out to the second click position C. 2. Press the S1 button to set the Chronograph Second Hand. Holding down the button will allow quick advance.
  • Page 15 To USE THE CHRoNoGRAPH (SToPWATCH): Press the S2 button to switch the watch to chronograph mode, 1. Press the S1 button to start counting. 2. To stop counting, press the S1 button once. Press the S1 button again to resume from where it left off. 3.
  • Page 16 THREE-EYE CHRoNoGRAPH MoDELS 1. Hour Hand 2. Minute Hand 3. Second Hand 4. 24 Hour Hand 5. Chronograph Second Hand 6. Chronograph Minute Hand S1 – Chronograph start/stop button S2 – Chronograph reset button To ADJUST THE CHRoNoGRAPH HANDS PoSITIoN: Before setting the time, check if the Chronograph Second Hand and Chronograph Minute Hand are at the zero posi- tion.
  • Page 17 1. Pull the crown out to the first click position B. 2. Press the S1 button to set the Chronograph Second Hand and Chronograph Minute Hand (mechanically coupled). Holding down the button will allow quick advance. 3. Push the crown back to position A. To SET THE TIME: 1.
  • Page 18 WATCH REPAIR AND SERVICE Contact the International Service Center for your country listed at the back of this booklet.
  • Page 19 Warranty Certificate Date of Purchase __________________________________________ Model Number __________________________________________ Authorized Dealer Information __________________________________________...
  • Page 20 INTERNATIoNAL SERVICE CENTERS Argentina WATCH LAND S.A. Bme. Mitre 1617-8th Floor +5411 4373 0100 1037 Buenos Aires, Argentina Australia SEIVERS AUSTRALIA PTY LTD Level 11, 343 Little Collins Street, +61 3 9600 4984 Melbourne Vic, Australia Austria D. ZAFIR HANDELSFIRMA Porzellangasse 27, IMPORT –...
  • Page 21 Iceland ECHO EHF Skútuvogur 10-D, +354 515 9999 104 Reykjavik, Iceland Korea A-DONG A/S CENTER 254-51, Huam-Dong, +02 774 0240 0242 Youngsan-Gu, Seoul, Korea Kuwait ALYASRA FASHION On Time Marina Mall, Salmiya, +965 22244515 Kuwait City, Kuwait Lavita TOPUS RIGA LTD Mukusalas iela 71, (BRANDWATCH) Riga, Latvia...
  • Page 22 Slovakia ĽUDOVIT NAGY- QUARTZ-SERVIS Revolučná 971/18 +421 317 805 750 924 01 Galanta, Slovakia Turkey MERKEZ SAAT TIC.LTD.STI. Mimar Kemalettin Cd. +90 212 513 52 91 Ersoy Han Kat:4 Sirkeci +90 212 520 03 02 Istanbul, Turkey HOUR CHOICE LLC Rivoli Group, PO Box 121, +971 4 3531400 Dubai, UAE...
  • Page 25 TEWB0410...

This manual is also suitable for:

Three-hand seriesOne-eye seriesTwo-eye seriesThree-eye series
