Iceberg Enterprises
03/17
Mobile Clarity Glass Easel
Assembly Instructions
A
B
Bolt and washer
www.icebergenterprises.com
INS620 REV B
Wrench
O
H
M
N
D
C
C
I
H
O
J
K Washer (3X)
K Washer (3X)
I
J
K
L
E
F
G
M/N
Attach (1X) locking castor
and (1X) non-locking
caster per leg.
L Nut (3X)
(1 of 2)
A Glass
1X
B Stand
1X
C Leg
2X
D Tray
1X
E Side
2X
Bracket
F Pad Hook 2X
G Cap
2X
H Leg Bolt 2X
I Washer 2X
J Screw
3X
K Washer 6X
L Nut
3X
M Caster
2X
N Caster
2X
w/Brake
O Wrench 1X
CAUTION!
Be sure glass edge
protectors (2X) are
in place to protect
glass.
