Rockwell Automation Allen-Bradley ControlNet 1784-PKTCS Installation Instructions Manual

Universal pci scanner card
Hide thumbs Also See for Allen-Bradley ControlNet 1784-PKTCS:
Table of Contents

Advertisement

Quick Links

Download this manual
ControlNet
Universal PCI
Scanner Card
1784-PKTCS
Installation
Instructions

Advertisement

Table of Contents
loading

Related Manuals for Rockwell Automation Allen-Bradley ControlNet 1784-PKTCS

Summary of Contents for Rockwell Automation Allen-Bradley ControlNet 1784-PKTCS

  • Page 1 ControlNet Universal PCI Scanner Card 1784-PKTCS Installation Instructions...
  • Page 2 In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment.
  • Page 3 Environment and Enclosure This equipment is intended for use in a Pollution Degree 2 industrial environment, ATTENTION in overvoltage Category II applications (as defined in IEC publication 60664-1), at altitudes up to 2000 meters without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR Publication 11.
  • Page 4 Hazardous Location Approval The following information applies when Informations sur l’utilisation de cet équipement en operating this equipment in hazardous environnements dangereux: locations: Products marked “CL I, DIV 2, GP A, B, C, D” are Les produits marqués "CL I, DIV 2, GP A, B, C, D" ne suitable for use in Class I Division 2 Groups A, B, C, D, conviennent qu’à...
  • Page 5 This could cause an explosion in hazardous location installations. Be sure that power is removed or the area is nonhazardous before proceeding. Windows 2000, NT, and XP are trademarks of Microsoft Corporation. RSLogix5000, RSNetWorx, RSLinx, and IOLinx are trademarks of Rockwell Automation.
  • Page 6 Preface About the 1784-PKTCS Universal PCI Scanner Card For Information On This Topic Refer To Page About the 1784-PKTCS Universal PCI Scanner Card Purpose of This Manual Intended Audience Terminology What Your Package Contains For Further Reference What I a 1784-PKTCS Universal PCI Scanner Card? The ControlNet 1784-PKTCS card is a Universal Peripheral Component Interconnect (PCI) open-bus interface card.
  • Page 7 Preface Terminology this term means ControlNet networking standard maintained by ControlNet International peripheral component interconnect What Your Package Contains With this package you should receive: • one 1784-PKTCS card • one IOLinx 1784-PKTCS driver CD-ROM • ControlNet Universal PCI Scanner Card Installation Instructions, publication 1784-IN042 For Further Reference Refer to these publications for more information on installing and using your 1784-PKTCS...

  • Page 8: Table Of Contents

    Table of Contents Chapter 1 Install IOLinx Uninstall the Previous Version of IOLinx ......1-1 Install IOLinx ..........1-2 Chapter 2 Install the 1784-PKTCS Card Before You Begin.
  • Page 9 Table of Contents Chapter 6 Use IOView to Verify the Configuration Before You Begin..........6-11 Start IOView .

  • Page 10: Install Iolinx

    Chapter Install IOLinx For Information On This Topic Refer To Page Uninstall the Previous Version of IOLinx Install IOLinxInstall IOLinx Do not install the 1784-PKTCS ControlNet Universal PCI scanner card IMPORTANT in the same PC as a 1784-KTCS ControlNet ISA-bus scanner card. Before installing the 1784-PKTCS card, remove all the 1784-KTCS cards and uninstall the associated drivers.

  • Page 11: Install Iolinx

    Install IOLinx 4. Select Yes to uninstall IOLinx. If you are prompted to remove unused shared files, select No to All. 5. Reboot the computer. Install IOLinx We recommend that you exit all Windows programs before running this IMPORTANT Setup program. The CD-ROM supports Windows Autorun.
  • Page 12 Install IOLinx 4. At the Run pop-up window, type x:\setup where x is the drive where the installation files are stored. You see the ControlNet Universal PCI Scanner Card screen. 5. Select Install IOLinx for ControlNet. 6. If the Microsoft .NET Framework is already installed on your computer, go to step 10.
  • Page 13 Install IOLinx 10. Click Next. 11. Use the default path to the folder. Select the Everyone or Just me radio button, depending on your application. 12. Click Next. You see the Confirm Installation screen. Publication 1784-IN042A-EN-P - April 2005...

  • Page 14: Install The 1784-Pktcs Card

    Chapter Install the 1784-PKTCS Card For Information On This Topic Refer To Page Before You Begin Access the Computer’s PCI Local Bus Expansion Slots Insert the Card into the Computer Connect to the Network Connect the Card Directly to the ControlNet Network Connect to a Device on the ControlNet Network Before You Begin To install the card, you need to:...

  • Page 15: Access The Computer's Pci Local Bus Expansion Slots

    Install the 1784-PKTCS Card Access the Computer’s PCI Local Bus Expansion Slots To install the card, you must access the computer’s PCI local bus expansion slots. Follow these general steps, or refer to your computer’s user guide for further instructions: 1.

  • Page 16: Connect To The Network

    • remove all other non-essential cards and try again If you continue to experience difficulty, contact your local Rockwell Automation sales representative or distributor, or call Rockwell Automation Technical Support at 440.646.5800. Connect to the Network If you connect or disconnect the ControlNet cable with power applied...
  • Page 17 Install the 1784-PKTCS Card Figure 2.1 1784-PKTCS card Diagnostic status indicators Network Access Port (NAP) RJ-45 connector for connecting programming terminals to devices on a ControlNet network Channel A BNC connectors for connecting directly to ControlNet network Redundant media BNC connectors Channel B Do not connect different ControlNet networks to this card.

  • Page 18: Connect The Card Directly To The Controlnet Network

    Install the 1784-PKTCS Card Connect the Card Directly to the ControlNet Network To connect the card directly to a ControlNet network as shown in Figure 2.2, follow the instructions in these publications: • ControlNet Coax Tap Installation Instructions, publication 1786-IN007 •...

  • Page 19: Connect To A Device On The Controlnet Network

    Install the 1784-PKTCS Card Connect to a Device on the ControlNet Network The 1786-CP cable (Figure 2.3) connects a host computer to another ControlNet device. It has two RJ-45 8-pin connectors. Figure 2.3 1786-CP cable RJ-45 8-pin connectors Connector 2 Connector 1 1786-CP cable 30124-m...
  • Page 20 Install the 1784-PKTCS Card Table 2.2 Wiring for 1786-CP connector cable Connector 2 Wire Number Signal Mnemonic Signal Name ISO-GND Isolated Ground N.C. No Connection PTRX-H Receive Data High PTRX-L Receive Data Low PTTX-L Transmit Data Low PTTX-H Transmit Data High N.C.
  • Page 21 Install the 1784-PKTCS Card Figure 2.4 Connect a programming terminal to a ControlNet network through another ControlNet device Programming terminal 1784-PKTCS 1786-CP cable ControlNet ControlNet network product 42199 The 1786-CP cable can be plugged into any ControlNet product’s NAP to provide programming capability on the ControlNet network.

  • Page 22: What Is Next

    Install the 1784-PKTCS Card Figure 2.5 Connect a portable host computer to the ControlNet network through the 1784-PKTCS card 1784-PKTCS Desktop host Portable host 1784-PCC computer computer 1784-PCC1 cable ControlNet network 42198 What Is Next? In This Operating System Do This Windows XP go on to Chapter 3 to install the driver Windows 2000...

  • Page 23: Install The Driver In Windows Xp

    Chapter Install the Driver in Windows XP For Information On This Topic Refer To Page Install the Driver in Windows XP for the First Time Update the Existing Driver in Windows XP Be sure that your 1784-PKTCS card is properly installed. Refer to IMPORTANT Chapters 1 and 2 of this manual to install the card.
  • Page 24 Install the Driver in Windows XP 1. When you boot up your computer for the first time after installing your 1784-PKTCS card, you see the Found New Hardware Wizard screen. 2. Select the Install from a list or specific location (Advanced) radio button. 3.

  • Page 25: Update The Existing Driver In Windows Xp

    Install the Driver in Windows XP 6. In the Found New Hardware wizard, click Browse and browse to this location: x:\Program Files\Rockwell Software\IOLinx\IOLinx for ControlNet\Drivers where x:\ is the drive where IOLinx is installed. 7. Click OK. 8. Click Next. If prompted to overwrite existing files, click Yes.
  • Page 26 Install the Driver in Windows XP 3. Click Manage. 4. In the left window pane, click the + to the left of System Tools to open it. 5. Under System Tools, click Device Manager. 6. In the right window pane, click the + to the left of A-B Virtual Backplane to expand it.
  • Page 27 Install the Driver in Windows XP 8. Click Update Driver. The Hardware Update Wizard appears. 9. Select the Install from a list or specific location (Advanced) radio button. 10. Click Next. 11. Click the Don’t search. I will choose the driver to install radio button. 12.
  • Page 28 Install the Driver in Windows XP 14. Click Browse and browse to this location: x:\Program Files\Rockwell Software\IOLinx\IOLinx for ControlNet\Drivers where x:\ is the drive where IOLinx is installed. 15. Click Open. 16. Click OK. 17. Click A-B 1784-PKTCS to highlight it. 18.

  • Page 29: Install The Driver In Windows 2000

    Chapter Install the Driver in Windows 2000 For Information On This Topic Refer To Page Install the Driver in Windows 2000 for the First Time Update the Existing Driver in Windows 2000 Be sure that your 1784-PKTCS card is properly installed. Refer to IMPORTANT Chapters 1 and 2 of this manual to install the card.
  • Page 30 Install the Driver in Windows 2000 1. When you boot up your computer for the first time after installing your 1784-PKTCS card, you see the Found New Hardware Wizard screen. 2. Click Next. 3. Click the Search for a suitable driver for my device (recommended) radio button. 4.
  • Page 31 Install the Driver in Windows 2000 5. Check the Specify a location checkbox and uncheck the remaining checkboxes. 6. Click Next. Publication 1784-IN042A-EN-P - April 2005...

  • Page 32: Update The Existing Driver In Windows 2000

    Install the Driver in Windows 2000 7. In the Found New hardware wizard, click Browse and browse to this location: x:\Program Files\Rockwell Software\IOLinx\IOLinx for ControlNet\Drivers\abpktcs.inf where x:\ is the drive where IOLinx is installed. 8. Click Open. 9. Click OK. 10.
  • Page 33 Install the Driver in Windows 2000 1. Right-click My Computer. 2. Click Manage. 3. In the left window pane, click the + to the left of System Tools to open it. 4. Under System Tools, click Device Manager 5. In the right window pane, click the + to the left of A-B Virtual Backplane to expand it.
  • Page 34 Install the Driver in Windows 2000 8. Click the Driver tab. 9. Click Update Driver. The Upgrade Device Driver Wizard appears. 10. Click Next. 11. Click the Display a list of the known drivers for this device so I can choose a specific driver radio button.
  • Page 35 Install the Driver in Windows 2000 13. Click Have Disk. 14. Click Browse and browse to this location: x:\Program Files\Rockwell Software\IOLinx\IOLinx for ControlNet\Drivers\abpktcs.inf where x:\ is the drive where IOLinx is installed. 15. Click Open. 16. Click OK. Publication 1784-IN042A-EN-P - April 2005...
  • Page 36 Install the Driver in Windows 2000 17. Click A-B 1784-PKTCS to highlight it. 18. Click Next. 19. Click Next to install the new driver. If prompted to overwrite existing files, click Yes. IMPORTANT 20. Click Finish. 21. Close the A-B 1784-PKTCS Properties screen. 22.

  • Page 37: Once You Have Completed The Installation

    Chapter Once You Have Completed the Installation Once you have installed the card and drivers, you can do the following: For Information On This Topic Refer To Page Register the EDS File Configure the Card Configure a Virtual Backplane Driver in RSLinx Software Configure the Scan List Go On Line With RSNetWorx for ControlNet Software Register the EDS File...

  • Page 38: Configure The Card

    Once You Have Completed the Installation Configure the Card Use the IOLinx configuration application to set the card’s ControlNet node address, IOLinx port number, and virtual backplane slot. 1. If the IOlinx gears do not appear in the system tray, start the IOLinx configuration application by selecting Start ⇒Programs ⇒Rockwell Software ⇒IOLinx for ControlNet ⇒IOLinx for ControlNet.

  • Page 39: Configure A Virtual Backplane Driver In Rslinx Software

    Once You Have Completed the Installation 4. You see the Port Configuration screen. In This Field Do This ControlNet Address select an unused ControlNet address from the pull-down menu IOLinx Port Number select an unused IOLinx port number from the pull-down menu Slot Number select an unused virtual backplane slot address from the pull-down menu (note that this is not the physical PCI slot in which the card is inserted)

  • Page 40: Configure The Scan List

    Once You Have Completed the Installation Configure the Scan List Use RSNetWorx for ControlNet to configure the scan list for the 1784-PKTCS card. Refer to publication CNET-UM001, ControlNet Modules in Logix5000 Control Systems User Manual, for details. Go On Line With RSNetWorx for ControlNet Software When going on line with RSNetWorx for ControlNet software via the 1784-PKTCS card: 1.

  • Page 41: When You Use Rsnetworx For Controlnet Software

    Once You Have Completed the Installation When You Use RSNetWorx for ControlNet Software Keep the following in mind when you use RSNetWorx for ControlNet software. 1784-PKTCS Card Will Not Establish Connections Until Output Data is Initialized The 1784-PKTCS card will not establish new or modified connections that require data to be produced by the 1784-PKTCS card until the controlling application has initialized the output data.
  • Page 42 Once You Have Completed the Installation RSNetWorx for ControlNet 6.00.00 or later is required to display these error messages. If RSNetWorx for ControlNet 5.11.00 is used, “Unknown Error” will be displayed on the Connection Status tab of the scan list configuration screen. Resolve the Errors Follow this procedure to resolve error conditions on the PC containing the 1784-PKTCS card reporting the error:...
  • Page 43 Once You Have Completed the Installation • If you modify or delete connections that are being controlled by your application, RSNetWorx for ControlNet displays the following screen when you attempt to save your changes: If you see this screen, you should: –...
  • Page 44 Once You Have Completed the Installation Follow these steps to see the resources required for your configuration: 1. On the RSNetWorx for ControlNet main window, right-click the 1784-PKTCS card. 2. Select Scanlist Configuration. 3. Select the Node Memory Usage tab to see the number of scan list entries used and the Data File usage.
  • Page 45 Once You Have Completed the Installation 6. Select Properties…, and select the Device Usages tab to see the CPU usage and the Consume and Produce usage. If the system exceeds any of the usage limits described previously, use RSNetWorx for ControlNet to reconfigure your system.

  • Page 46: Before You Begin

    Chapter Use IOView to Verify the Configuration For Information On This Topic Refer To Page Before You Begin 6-11 Start IOView 6-12 Create a View 6-12 Read Inputs and Write Outputs 6-14 Change the View State 6-16 Delete a View 6-16 Included with the IOLinx for 1784-PKTCS driver CD is a stand-alone test application (called IOView.exe) that lets you diagnose simple problems over the network before the control...

  • Page 47: Start Ioview

    6-12 Use IOView to Verify the Configuration Start IOView The test application IOView is automatically installed as part of the driver installation procedure. To start IOView, click Start Programs Rockwell Software IOLinx IOLinx for ControlNet Samples IOView. You may invoke multiple instances of IOView at the same time. Create a View The 1784-PKTCS card supports Network views and I/O Set (IoSet) views.
  • Page 48 Use IOView to Verify the Configuration 6-13 2. Create either a Network view or an I/O Set view. • To create a Network view, select Edit Create Network View. • To create an I/O Set view, select Edit Create I/O Set View. You see this screen: In This Field Do This...

  • Page 49: Read Inputs And Write Outputs

    6-14 Use IOView to Verify the Configuration Read Inputs and Write Outputs The input data (if any) and output data (if any) associated with the view are displayed in the Input Data and Output Data sections, respectively. Change the Read/Write Period The data transfer between IOView and the card occurs at the Read/Write Period.
  • Page 50 Use IOView to Verify the Configuration 6-15 Manually Enter Values To manually enter the output values: 1. On the IOView screen, select Manual from the Output Pattern pull-down list. 2. In the Output data area of the IOView screen, enter the desired output values. Select Manual from the Output Pattern pull-down...

  • Page 51: Change The View State

    6-16 Use IOView to Verify the Configuration Change the View State When the view is initially created, the view state is set to Idle. The view state must be set to Run in order for the I/O adapters and I/O modules to energize their outputs based on the output data associated with the view.

  • Page 52: Interpret Status Indicators

    Chapter Interpret Status Indicators The status indicators on the card give you information about the card and the network when the card is connected to the network with the BNC connectors. Table 7.1 outlines the states and explains what each state means to you and the action you should take, if any, to correct that state.
  • Page 53 Interpret Status Indicators • flashing - the indicator alternates between the two defined states (applies to each indicator viewed independent of the other). If both indicators flash, they must flash together, in phase. Table 7.1 ControlNet status interpretation Cause: Action: •...
  • Page 54 Interpret Status Indicators Table 7.1 ControlNet status interpretation Cause: Action: • normal operation • none steady green • temporary • check media for broken cables, loose flashing green/off network errors connectors, missing terminators, etc. • if condition persists, refer to the ControlNet Media Planning and Installation Manual, publication CNET-IN002 •...
  • Page 55 Appendix Specifications PCI local bus compliant to PCI Rev. 2.2 The 1784-PKTCS card is compatible with 5V and 3.3V PCI slots, 32-bit and 64-bit PCI slots, and PCI-X slots. Attention: The 1784-PKTCS card is not compatible with PCI Express and should not be inserted into a PCI Express slot. mechanical form factor Universal PCI 32-bit short card 4.2 in.
  • Page 56 Specifications storage temperature IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold), IEC 60068-2-2 (Test Bb, Un-packaged Non-operating Dry Heat), IEC 60068-2-14 (Test Na, Un-packaged Non-operating Thermal Shock): -40 to 85 °C (-40 to 185 °F) relative humidity IEC 60068-2-30 (Test Db, Un-packaged Non-operating Damp Heat): 5 to 95% non-condensing vibration IEC 60068-2-6 (Test Fc, Operating):...
  • Page 57 Specifications 2 - on communications ports wiring category UL Recognized Component Industrial Control Equipment certifications (when product is marked) CSA CSA Accepted Component for Process Control Equipment CSA Accepted Component for Process Control Equipment in Class I, Division 2 Group A,B,C,D Hazardous Locations European Union 89/336/EEC EMC Directive, compliant with: EN 50082-2;...
