- Page 1 DVN CAB E Installation instructions www.dynavin.de...
- Page 2 DVN CAB E product information The cable set is required for all Mercedes vehicles of the E-class (W211) series 2002-2009, SLK (R171) 2004-2011 and CLS (C219) 2004-2010, where the electronic unit (e.g. amplifier) is located in the trunk. 1. Cable routing We recommend routing the cable harness on the left-hand side of the vehicle to the front and leading it up at right angles to the centre console in front of the left-hand front seat.
- Page 3 Pull the carpet upwards and open the cover of the black plastic channel underneath by unhooking it. The lid is held in place by plastic hooks (marked). The CAN bus distributors are located in the channel. Pull the marked distributor upwards out of its socket. www.dynavin.de...
- Page 4 www.dynavin.de...
