  • Page 1 XD series BD board...
  • Page 2 Fast manual Features XD series expansion communication BD board includes RS232 port expansion board XD-NS-BD, RS485/fieldbus/motion control bus communication port expansion board XD-NE-BD, RS485/fieldbus communication port expansion board XD-NO-BD. ➢ XD-NS-BD can be used to RS232 communication between XD series PLC and other device. ➢...
  • Page 3 Product information Naming rule ◼ XD– n - BD ① ② ③ ① Series XD: XD series extension BD board ② Communication type: NS: RS232 NE: RS485/fieldbus/motion fieldbus NO: RS485/fieldbus ③ Extension type BD: extension BD board ◼ Basic parameters XD series PLC 24/32 points can extend 1 BD board, XD series PLC 48/60 points can extend 2 BD boards, XD series PLC 16 points cannot extend BD board.

  • Page 4: Installation

    Part name: Name Function Communication The LED is ON when BD board Wiring 485+ communication normal 485- terminal Signal ground ● Vacant End resistor switch Select end resistor through the switch (120Ω) XD-NE-BD has switch inside which can select the end resistor. XD-NE-BD switch default setting is OFF (not use resistor).
  • Page 5 39.4 Electric design reference Configuration mode ➢ XD-NS-BD can be used to communicate between the XD series PLC, XD PLC and other devices through RS232. ➢ XD-NE-BD can be used to communicate between XD series PLC, TN series HMI, DS3E series servo drive, other devices through RS485 or fieldbus(X-NET).
  • Page 6 3. choose the com port no. between PC and PLC, the device type please select PLC, then click confirm. Then back to main window, click Config/single device/com port. 4. it will show the com port setting window. 5. As XD3-32T-E only can connect one BD board, which is COM4, here we set Comport 4 for XD-NE- BD.
  • Page 7 NetID: the network no. of the two PLC. The network no. must be same for the same network, here it is set to 1. StationID: every PLC station no. in the network. In this network, the two PLC station no. is 1 and 2. Net type: please select TBN for PLC communication, OMMS or TBN is for communication between HMI and PLC.
  • Page 8 Net: it is same to the Net ID set in the former serial port configuration window. COM no.: the PLC serial port no., here we use XD-NE-BD, so the port no. is COM4. Gateway: please keep it as default value 0. 11.
