LED Module Lighting System
Spectrum S30

BEFORE YOU BEGIN

STOP
Read these instructions completely and carefully.
Prepare Electrical Wiring
• Acceptable for use in dry, damp and wet locations
• Follow all National Electric Codes (NEC) and local codes.
• This product is intended to be installed and serviced by a qualified, licensed electrician.
• Ensure applicable wire is installed between driver, fixture, and any controls in between.
• When choosing wire, factor in voltage drop, amperage rating, and type (in-wall rated, wet
location rated, etc.). Inadequate wire installation could overheat wires, and cause a fire.
• Do not install if product has any visible damage.
• Do not modify or disassemble this product beyond instructions or the warranty will be void.
WARNING
RISK OF ELECTRICAL SHOCK
• Turn power off before inspection, installation or
removal.
• Properly ground power supply.
RISK OF FIRE
• Use only UL approved wire for input/output
connections
• Minimum wire size 18 AWG
• Follow all NEC and local codes.
!
1936 Premier Row, Orlando, FL 32809 • Tel: 407-250-6706 Fax: 888-567-4532 • Toll Free: 1-888-567-4LED (4533)
www.everylite.com
Shock Hazard.
May result in serious injury or death.
Turn off power at the circuit breaker
before installing this product.
