Table of Contents
Summary of Contents for Dayal 2000
-
Page 1: Table Of Contents
Catalogue Introduction ………………………………………………………………………2 Attention ……………………………………………………………………………2-3 Functions ……………………………………………………………………………3-4 Parts …………………………………………………………………………………..4 Main machine…………………………………………………………………………...4 Remote control………………………………………………………………………….5 Portable Battery Case and the Charger………………………………………………….5 Installment Instruction ………………………………………………………..6 Packing list………………………………………………………………………………6 Assembling……………………………………………………………………………6-9 Use Instruction …………………………………………………………………...10 Remote control mode………………………………………………………………...10-20 Panel control…………………………………………………………………………….20 Maintenance ………………………………………………………………………21 Normal phenomenon……………………………………………………………………21 Trouble examination…………………………………………………………………..21 Maintenance……………………………………………………………………………..22... -
Page 2: Introduction
Introduction Dear customer: Please read this manual carefully before using the machine. Only when you are familiar with the machine and you understand the correct usage can you use the machine on the tennis court. Avoid misoperation which could result in damaging the tennis ball machine or other accidents. -
Page 3: Functions
The products are the professional sports-goods equipment. We are not responsible for any legal responsibility if any other people change the products for other purpose and cause damage. Functions Model:2000 Micro-computer smart tennis ball machine Inside control the ball shooting direction, XCL Humanistic design ... -
Page 4: Parts
Machine sideview Bottom si de SSV8-8 protector AC socket R i ght si de Back side Left side Front side O ver si de Parts ： Main machine Bal l basket Fol dabl e pul l r od Panel cont r ol AC/ DC choosi ng sw i t ch M ai n m achi ne speed... -
Page 5: Remote Control
REM OTE REM OTE Accessory : charger, power cable Warning▲ DAYAL products are the professional sports-goods equipment. We are not responsible for any legal responsibility if any other people change the products for other purpose and cause damage. -
Page 6: Installment Instruction
Installment Instruction Packing list Description Quantity Description Quantity Main machine parts charger Ac power cable Remote control Fuse pipe manual (ii) Assembling Note: When demolishing the machine packing module, it can possibly see the tennis surface down on the packing protective film and the machine , this is the normal phenomenon leaving on the product ex-factory after testing examination. - Page 7 Ball basket m ake al i gnm ent and Keep t he pul l r od i m i t i l pr ess l i ght l y condi t i on Fi xed r ubber st opper assem bl i ng hol e Pul l r od sl ot Bal l basket M ai n m achi ne...
- Page 8 4. Ball –separating i nser t t he bal l seper at i ng devi ce bal l f eed pl at e dow nw ar d bal l - seper at i ng devi ce m at ch t he f i xed hol e bal l f eed pl at e i nser t t he f ast l at ch pul l up...
- Page 9 Charging Chor ger concave par t convex par t panel cont r ol DC pow er socket speed ( K/ H) Horizontal ( Second) frequency Battery Level Lob ball Top spin Vertical SSV8- 8 Back spin Wide Random Among Narrow (3-Line) Reset speed...
-
Page 10: Use Instruction
Use Instruction The place of the machine in the court. The machine should be placed in the middle of the baseline. t enni s bal l m achi ne Firstly,Remote control mode ◆ Choose the power speed ( K/ H) frequency ( Second) ON /OFF... - Page 11 2． Choose the switch position“I”,ie,choose the DC power.then the power indication light will be on, the ball speed of LCD display is“00”and the frequency is “0” . The position of serving ball to be checked in the middle place in the horizontal line and in the place for flat stroking in the vertical line by itself at the same time.
- Page 12 1． Select “AC” or “DC” power. 2． Softly touch the “ON/OFF” button, then will a sound ”di”， the main engine begins to work, and the ball speed of the LCD display is 120 km/hr(set by factory)。The machine begin to serving ball after 5 seconds,the frequency of serving show 8 seconds/ball (set by factory).
- Page 13 1． Touch softly the “ON/OFF” button and start the machine. 2． Touch softly the button “frequency△Up” “frequency▽Down”, then adjust the ball frequency in the range of 2 to 12 sec/ball. 3． Touch softly again the “ON/OFF” or “Reset” button, the machine stop working. ◆...
- Page 14 1. Touch softly the “ON/OFF” button and start the machine. 2. Touch softly the “W/A/N” button the fourth time,to set horizontal swing ball,at the same time the horizontal show led are on in the LCD. 3. Touch softly again the “ON/OFF” or “Reset” button, the machine stop working. Note：Touch softly the “W/A/N”...
- Page 15 ◆ Choose the top spin ball shooting speed ( K/ H ) frequency Horizontal ( Second) Top spin Top spin Vertical Back spin /OFF SSV8- 8 Wide Among Random Narrow OFF DC protector DC lamp DC socket AC socket 1． Touch softly the “ON/OFF” button and start the machine. 2．...
- Page 16 ◆ Choose the lob ball shooting speed ( K/ H) frequency Horizontal ( Second) Vertical Top spin Vertical SSV8- 8 Back spin /OFF Wide Among Random Narrow OFF DC protector DC lamp DC socket AC socket 1. Touch softly the “ON/OFF” button and start the machine. 2.
- Page 17 ◆Choose the forehand or backhand Middle-line ball shooting speed ( K/ H ) frequency ( Second) SSV8- 8 /OFF W/A/N Wide protector DC lamp DC socket AC socket 1.uch softly the “ON/OFF” button and start the machine. 2.uch softly the ‘W/A/N’ button the 2 forehand or backhand Middle-line ball time to set shooting.
- Page 18 ◆ Self-programming（Set） Pattern stock /OFF Vertical Horizontal The machine could shoot 20 consecutive balls at 5 horizontal positions and 4 vertical position. The last program is constantly saved, also after resetting or power off the machine. Because the machine saves the program but the remote control doesn’t, the remote control will show at the display that no balls were programmed after a power off of the machine.
- Page 19 ◆ Self-programming（Cancel） O F F P a t t e r n Stock W/A/N ON/OFF Vertical Horizontal While the machine doesn’t display the order of the shooting balls at several positions, you should manage yourself which balls to remove. When removing a programmed ball, the next balls shift just one position to become the next ball.
-
Page 20: Panel Control
◆ Choose the random ball shooting Pattern ON /OFF Select AC/DC power 1. Touch softly the “ON/OFF” button and start the machine 2. Touch softly ‘Pattern’ button the 2 time,to set the random ball shooting. different combinations of ball speed、 fixed、 flat stroke、 horizontal swing、 horizontal displacement、 vertical displaceement、... -
Page 21: Remote Control Mode
Maintenance 1. Normal phenomenon Note: When softly touch the function button, the LCD has the relevant show, but the machine is not working, it means the main machine maybe did not receive the signal, only need touching the reset button and re-operation. It is the normal phenomenon. The normal phenomenon as follows: phenomenon Reason... -
Page 22: Maintenance
3． Maintenance Note: If you do not use the machine for a long time, please pay attention to these items as follows: ▲The battery and electricity must be far away with the heat power. ▲Take out the battery of the remote control. ▲Preserve the power cable and the battery cable.
