e-conolight E-TFP Series Installation Instructions Manual

INSTALLATION INSTRUCTIONS
E-TFP LED Flat Panel
1x4
CAUTIONS

IMPORTANT SAFEGUARDS

When using electrical equipment, basic safety
precautions should always be followed including the
following:
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1. DANGER- Risk of shock- Disconnect power before

installation.

DANGER – Risque de choc – Couper l'alimentation
avant l'installation.
2. Caution - Risk of Fire.
Attention - Risque D'incendie
3. This luminaire must be installed in accordance with the
nec or your local electrical code. If you are not familiar
with these codes and requirements, consult a qualified
electrician.
Ce produit doit être installé conformément à nec ou votre
code électrique local. Si vous n'êtes pas familier avec ces
codes et ces exigences, veuillez contacter un électricien
qualifié.
4. Suitable for damp locations.
Convient aux emplacements humides.
5. Min 90°C supply conductors.
Les fils d'alimentation 90°C min.
6. Inherently protected.
Protection inherente.
7. Type IC. Vapor barrier must be suitable for 90°C.
Type IC. Le pare-vapeur doit convenir pour 90°C.
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE
2x2
2x4
www.e-conolight.com
Document:
Created By:
1. Locate desired fixture location in ceiling grid.
2. Remove existing ceiling panel at chosen location. Remove
adjacent ceiling panel to allow for wiring access from above.
3. Place fixture into T-bar ceiling grid. Bend clips on top of fixture up
and rotate out to engage with T-bar support grid. See Figure 1.
Secure fixture to grid in compliance with state and local codes.
4. Remove screw on driver wiring chamber and remove cover. Set
screw and cover aside to be reinstalled later.
5. Remove appropriate 1/2" knockout(s) to allow for entry of supply
wiring into wiring chamber.
6. Make wiring connections per the Fixture Wiring section.
NOTE:
• Terminal blocks in driver wiring chamber will accommodate
12-20 AWG solid or stranded leads for supply and 18-24
AWG solid or stranded leads for dimming.
• For dimming connections (if used) use Class 1 wiring
methods only.
7. Reattach cover of wiring chamber with screw that was removed in
Step 4 above.
8. Replace adjacent ceiling panel removed in Step 2.
