SSV Works WP3-PN304A Instructions

SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against
defects in material or workmanship. All SSV Works Electronics are covered by
a limited 1 year warranty against defects in material or workmanship. All SSV
Works Speakers are covered by a limited 1 year warranty against defects in
material or workmanship. Labor for replacement of defective components is
not covered. Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
- 4mm Hex Key
- #3 Philips Screw Driver
PARTS LIST IMAGES
1. WP3-PN3O4A
7. Enclosure Mounting 8. J Mounting Bracket
Brackets x 2
INSTALLATION NOTES
To make wiring easier, locate the battery in the vehicle before
beginning the installation. The use of a thread locker is
recommended on all screws to prevent loosening due to vibration. If
the vehicle has a roof, it will need to be removed prior to installation.
Once the installation of the WP3-PN3O4A is complete the roof may be
re-installed, modification to the roof may be required for proper fit.
- 10mm Socket and Ratchet
- Strippers and Crimppers
2. M6 Screws x 12 3. M6 Washers x 16
9. J Bracket Rubber
Instert x2
4 Speaker Overhead WP System
!
PARTS LIST
1. WP3-PN3O4A x 1
2. M6 Screw x12
3. M6 Washers x16
4. Lock Nuts x4
5. 30mm Hex bolts x2
6. Aluminium Spacer x2
4. Lock Nuts x4 5. 30mm Hex Bolts x2
10. Fuse Holder with 11. Crimp on ring
Fuse
Be sure to pre-install the J
Bracket Rubber inserts before
installing the WP3-PN3O4A
WP3-PN3O4A
Honda Pioneer 1000
Please read and understand these
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
7. Enclosure Mounting Bracket x2
8. J Mounting Brackets x 2
9. J Bracket Rubber Insert x2
10. Fuse Holder with Fuse
11. Crimp on ring terminal
12. Zip Ties
6. Aluminimum
Spacer x2
12. Zip ties
terminal
