  • Page 1 TWIN MINI SV/LS USER INSTRUCTIONS REV. “-” - 25.06.19...
  • Page 2 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 2/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE INDEX CAP. N° N° PAG. pag.2 INDICE SAFETY ADVICE pag.3 SECTIONS pag.4...

  • Page 3: Safety Advice

    ANY OTHER USE NOT EXPLICITLY MENTIONED IN THIS BOOKLET MUST BE CONSIDE- RED AS HAZARDOUS. THE MANUFACTURER DISCLAIMS ALL LIABILITY FOR DAMAGE RESULTING FROM IMPROPER, INCORRECT OR UNREASONABLE USE. The manual is available in digital format at EPTA S.p.A. - Solesino. Contact the number +39.0429.707311 or send an email at: sales@eurocryor.it...
  • Page 4 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 4/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE SECTIONS TWIN MINI SV TWIN MINI LS...
  • Page 5 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 5/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE 1. INTRODUCTION 1.1 CLAUSES THIS INSTRUCTION MANUAL IS AN INTEGRAL PART OF THE PRODUCT AND MUST BE KEPT UNTIL THE PRODUCT IS DISMANTLED.
  • Page 6 8. Climate class, temperature and relative humidity of the reference climate class. 9. Insulation blowing gas 10. CE marking and any other marks The plate must remain unchanged over time; it shows the details to provide to EUROCRYOR if the need for assistance arises.
  • Page 7 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 7/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE The noise level generated by the operation of the equipment complies with the requirement set out in the Machine Directive.
  • Page 8 4.4 COPYRIGHT This manual is the exclusive property of EUROCRYOR. Handing this manual over to third parties must be authorized by EUROCRYOR’s management team. It is strictly prohibited to copy, reproduce with any medium, even partially, drawings and docu- ments contained in this manual.

  • Page 9: Intended Use

    It is prohibited to remove any guard or panel if a tool is required to do so. It is forbidden to tamper with or alter the product. Any other use which is not specifically indicated in the manual is considered hazardous and EUROCRYOR cannot be held responsible for any damage caused by improper and unreasonable use.
  • Page 10 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 10/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE 6. HANDLING AND STORAGE (SPECIALIST TECHNICIAN) 6.1 HANDLING The loading and unloading operations must be performed by qualified staff, who will verify the exact weights and lifting points;...
  • Page 11 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 11/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE 6.2 STORAGE The equipment must be stored in a dry humidity-free environment. It must be covered with a sheet before storage to protect it from dust or dirt.
  • Page 12 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 12/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE 7. AMBIENT CONDITIONS FOR INSTALLATION The equipment must be installed in a closed environment, covered and safe from atmospheric agents.

  • Page 13: Preliminary Cleaning

    IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 13/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE 8. FIRST START-UP (OPERATOR) 8.1 PRELIMINARY CLEANING Wear protection gloves when carrying out the jobs explained in this chapter.
  • Page 14 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 14/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE Before loading the foods in the cabinet, remember to adjust the thermal- expansion valves •...
  • Page 15 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 15/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE WARNING: DANGER OF DEATH PRESENCE OF ELECTRIC VOLTAGE DO NOT TOUCH THE COMPONENTS Fig.
  • Page 16 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 16/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE The regulation is necessary for the correct operation of the cabinet, in particular with the remo- te or centralised condensing unit.
  • Page 17 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 17/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE Fig. 2 positioning thermometer probe (2). Fig. 1 positioning thermometer probe (1) Remove the cap indicated by the arrow and regulate.

  • Page 18: Loading Product

    IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 18/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE 9. USE OF THE CABINET (OPERATOR) 9.1 PERFORMANCE The Cabinet is suited exclusively to displaying refrigerated food/beverages: •...
  • Page 19 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 19/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE When loading the goods, and as long as the products are in the cabinet, pay the utmost atten- tion: •...
  • Page 20 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 20/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE 9.4 SET POINT MODIFY CAREL mod. IR33C0HB00 / IRMPX_MM000 / MPX PRO30 SET POINT MODIFY 1.
  • Page 21 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 21/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE ELIWELL EW971EO CONTROLLER IN ORDER TO MODIFY THE SET POINT 1.
  • Page 22 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 22/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE DANFOSS EKC202D / AK-CC550 / AK-CC550A CONTROLLER SET POINT MODIFY 1.
  • Page 23 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 23/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE DIXELL XR77CX CONTROLLER IN ORDER TO MODIFY SET POINT 1.
  • Page 24 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 24/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE 10. CLEANING Before starting any cleaning operation switch off the power. È...

  • Page 25: Internal Cleaning

    IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 25/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE 1. Chlorine-based detergents such as bleach or similar products normally on sale, as they pro- duce serious effects of corrosion if not thoroughly, quickly and appropriately rinsed.
  • Page 26 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 26/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE Fig. 4 Detail A. Drain hole Fig. 3 Dett. A Note: to clean the area below the evaporator, using a suitable recipient, pour some hot water slowly being careful not to splash the surrounding components.
  • Page 27 11.1 REPLACEMENT OF LED MODULES Caution: to replace a LED lighting body (module/strip) or Power supply voltage, it is obligatory to contact the dealer of the cabinet and use exclusively original Eurocryor spare parts. 11.2 REPLACEMENT OF FUSES The protection fuses are installed inside the electric board. To replace them, access the inside of the board (see chapter) and follow the images below.
  • Page 28 Modification of the parameters, other than the SETPOINT, which modify the operation of the cabinet, must only be made by the installer or by a qualified technician. The manuals of the electronic controllers can be found on the links below or requested from EUROCRYOR: http://www.eliwell.it/filedownload.aspx?id=8582 http://www.carel.com...
  • Page 29 IN CONFORMITY TECHNICAL DOCUMENTATION STATE REVISION OF THE CHAPTER WITH THE APPROVED PRODUCT TWIN MINI ORD. DATE ORD. DATE ORIGINAL N° DOC. PAGE 29/30 N° CHAP. FIRST ISSUE 17.06.19 MKTG ISSUE 12. DISPOSAL (SPECIALIST TECHNICIAN) All countries have different legislations; therefore, the specific prescriptions enforced by the legislation and local authorities of the country where the equipment is demolished must be observed.
