Summary of Contents for IDVIEW IV-HDCM-500DF
- Page 1 IV-HDCM-500DF DAY/NIGHT HD-SDI CAMERA 7/14/21 Wall Anchor Plastic Camera Unit User Manual Positioning stricker Wrenches Wall Anchors Sheath O-ring...
- Page 2 STEP 7 Open the IR module, Align the marks of and adjust the black mount plate and zoom lens. camera cover,then tighten the vandal screw as figure. Camera cover STEP 5 Loosen the screws LEFT RIGHT to adjust camera direction,the vertical angle is 15°...
- Page 3 SET UP MENU LENS •DC•MANUAL ‧DEFOG : DEFOG or Rain : Select Auto Iris Lens ● • SHUTTER •AGC •SENS-UP •BRIGHTNESS ‧BACKLIGHT : OFF, BLC,HBLC When DC is select, you can control screen brightness. The range EXPOSURE • ACCE •DEFOG •BACKLIGHT •RETURN of bright control is between 0 and 100 (45 in case of WDR mode).
- Page 4 ﹣SENSITIVITY : 0 ~ 60. •D-EFFECT : Select this to adjust the image. ‧DEFECT : ﹣MOTION VIEW : ON/OFF ﹣FREEZE : OFF/ON ﹣LIVE DPC : Dead pixel compensation on live. ﹣DEFAULT : Reset the motion setting to the factory defaults. ﹣MIRROR : OFF/MIRROR/V-FLIP/ROTATE ﹣LEVEL : 0 ~ 60.
