Rollei Sunglasses Cam 100
Dear Customer:
Congratulations on purchasing a high quality Rollei product. You have
chosen a modern Sunglasses Cam with excellent technical equipment
and related accessories that is particularly easy to use. Please read all the
instructions carefully and thoroughly. Pay particular attention to all safety
instructions.
You have a two year warranty on the device.
If the Sunglasses Cam should ever break down, you will need the enclosed
warranty card and your purchase receipt. Store them carefully with the
operating instructions. When passing the device on to a third party, be sure
to include the instruction manual.
1. Package Contents
Unpack the Sunglasses Cam carefully and check that all the items listed below are
included:
1. Rollei Sunglasses Cam
2. 4 GB microSD memory card, including SD card adapter
3. USB cable
4. 2 additional interchangeable lenses
5. Cleaning cloth
6. Bag
7. Warranty and service documents
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sunglasses Cam 100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rollei Sunglasses Cam 100

  • Page 1: Introduction And Package Contents

    Rollei Sunglasses Cam 100 Dear Customer: Congratulations on purchasing a high quality Rollei product. You have chosen a modern Sunglasses Cam with excellent technical equipment and related accessories that is particularly easy to use. Please read all the instructions carefully and thoroughly. Pay particular attention to all safety instructions.

  • Page 2: Table Of Contents

    2. Table of Contents 1. Introduction and Package Contents 2. Table of Contents 3. Notes Regarding Risks, Safety and Warnings 4. Welcome to Your Sunglasses Cam Front view Controls Changing the lenses 5. Descriptions of Functions 5.1. Inserting a memory card 5.2.

  • Page 3: Notes Regarding Risks, Safety And Warnings

    Rollei Sunglasses Cam 100 3. Notes Regarding Risks, Safety and Warnings Handling the Sunglasses Cam and its accessories improperly poses a risk to your- self and others, or the Sunglasses Cam can be damaged or destroyed. Therefore, please read and strictly observe the following notes regarding risks, safety and warnings.
  • Page 4 Electrical hazard • If foreign objects or a liquid has entered the Sunglasses Cam, turn it off. Let everything dry thoroughly. Otherwise, there is a risk of fire or electric shock. • If the housing of the Sunglasses Cam has been damaged, turn the cam off. Otherwise, there is a risk of fire or electric shock. • The Sunglasses Cam must not be taken apart, modified or repaired. There is a risk of fire and electric shock.
  • Page 5 Rollei Sunglasses Cam 100 Notes regarding the Sunglasses Cam • The Sunglasses Cam is suitable for use only in moderate climates. • The Rollei Sunglasses Cam is a Class 1 optical device. The protective lenses provided are not suitable for looking directly at the sun. Please observe the cleaning instructions in Section 7 on page 17.

  • Page 6: Welcome To Your Sunglasses Cam

    4. Welcome to Your Sunglasses Cam 4.1. Front view On/Off/Record Video camera 4.2. Controls Reset button Working LED Microphone Memory card slot Power LED USB port...

  • Page 7: Changing The Lenses

    Rollei Sunglasses Cam 100 4.3. Changing the lenses You can choose which of the included lenses you want to use. Remove an already installed lens with a quick downward pull. Then place the new lens in the guides on the left and right and push it as shown below until it clicks into place.

  • Page 8: Descriptions Of Functions

    5. Descriptions of Functions 5.1. Inserting a memory card Before you can record videos with the Rollei Sunglasses Cam, you need to insert a microSD or microSDHC memory card. To do this, open the cover of the memory card compartment on the bottom of the right earpiece Insert the microSD/SDHC memory card into the card slot (see the illustration) and push the memory card in until it clicks into place. Then close the...

  • Page 9: Charging The Battery

    Rollei Sunglasses Cam 100 5.2. Charging the battery To charge the built-in lithium-polymer battery, you must connect the Sunglasses Cam to the USB port of a computer or a power adapter with a USB output using the mini-USB connector. Open the cover of the mini-USB port on the bottom of the right earpiece and insert the included mini-USB cable.

  • Page 10: Switching The Sunglasses Cam On And Off

    5.3. Switching the Sunglasses Cam on and off To turn the Sunglasses Cam on, press the On/Off button briefly. The indicator LED on the inside will then go green and you will hear 4 beeps. When the Sunglasses Cam is turned on, video recording automatically starts. During recording, the blue Record LED also flashes. If you turn on the Sunglasses Cam with no card installed, the indicator LED will go red briefly and the Sunglasses Cam will switch itself off after a long beep.

  • Page 11: Setting The Date And Time

    Rollei Sunglasses Cam 100 5.4. Setting the date and time To save video files with the current date and time, a clock can be set in the Sunglasses Cam. To do this, use a text editor on your computer to create a text file named “settime. txt” in the start-up folder of the memory card and enter the following values: YYYY MM DD hh mm ss where: Y = year, M = month, D = day, h = hour, m = minute, s = second Make sure that exactly one space is entered between the values. Example: To set the camcorder to March 1, 2013, 10:00 AM, enter the following line of text: 2013 03 01 10 00 00 Re-insert the memory card into the Sunglasses Cam. The next time the Sunglasses Cam is switched on, the date and time are transferred and the “settime.txt” is subsequently deleted from the memory card. 5.5. Changing the settings You can change various camera settings. To do so, please connect the camera to your computer using the USB cable. The camera appears as a removable drive on your desktop.
  • Page 12 You can make the following changes: • UPDATE: To ensure that the changes are transferred the next time you start your Sunglasses Cam, please change this value to “Y” (Yes). Y = changes are applied, N = changes are not applied. • EV (Exposure Value): Enter a value between 1-21.

  • Page 13: Resetting The Sunglasses Cam

    Rollei Sunglasses Cam 100 • AudioVol (Audio volume): Record your videos with or without sound. 1 = audio on (default), 0 = audio disabled • LIGHTFREQ (Light frequency): 0 = 60 Hz, 1 = 50 Hz (default) • RTCDisplay (Real time clock display): Here you can choose whether the date and time you have set are displayed as...

  • Page 14: Connecting To A Computer

    5.7. Connecting to a computer System requirements 1. Operating systems: Microsoft Windows® ME / 2000 / XP / VISTA / Windows® 7 / 8; Mac OS 10.5; Linux 2. Processor: Intel® Pentium 2 G Hz or equivalent 3. USB 1.1 or USB 2.0 4. CD-ROM/DVD drive 5. 10 GB or more free space on the hard disk 6. RAM: 1 GB or more Open the cover of the mini-USB port on the bottom of the right earpiece and insert the included mini-USB cable.

  • Page 15: Conformity

    Rollei Sunglasses Cam 100 6. Conformity This device has been tested in accordance with Part 15 of the FCC regulations and it has been confirmed that the limit values for a Class B digital device have been satisfied. These limits are designed to provide reasonable protection from harmful interference when installed in a residential community. If this device is not installed in accordance with the instructions, television, radio and wireless devices may be susceptible to interference.

  • Page 16: Maintenance

    7. Maintenance To clean the Sunglasses Cam frame and the accessories that are included, do not use harsh cleaners such as alcohol, paint thinner, etc. Clean the components of the system as needed with a soft, dry cloth. Always clean the lenses with a normal lens cloth.

  • Page 17: Technical Data

    Rollei Sunglasses Cam 100 9. Technical Data technical Data Image sensor 5 megapixel CMOS sensor Video format MOV (H.264) 1080 p (1920x1080/30fps) | 720p (1280x720/60 fps) Shooting angle 63 degrees Memory slot for TF memory card up to 32 GB...

  • Page 18: Warranty And Service

    2 years. Please refer to the warranty card enclosed separately for details. Please contact our hotline before sending in your defective device. Sales: Service address: RCP Technik GmbH & Co. KG Rollei Service Deutschland Tarpen 40/Gebäude 7b Denisstraße 28a D-67663 Kaiserslautern, Germany D-22419 Hamburg, Germany welcome@rcp-technik.com...
