TREND TONN/BAT Installation Instructions

Important: Retain these instructions
These instructions shall be used by trained service personnel only
If the equipment is used in a manner not specifi ed by these instructions, the protection provided by the equipment may be impaired.
CONTENTS
1 Unpacking .....................................................................1
1 UNPACKING
2 INSTALLATION
The TONN/BAT kit can be used as a replacement battery for TONN units requiring a backup battery for back up and shutdown in
the event of power failure, or as a uninterrupterable Power Supply (UPS) for TONN (E) units. See the TONN Data Sheet (TA201127)
for details.
Important
▪ If replacing a battery follow steps (1), (2), (3), (4), (5) and (6)
▪ If using a a UPS follow steps (1), (2), (4) and (5)
WARNING:
Power to TONN must be OFF when replacing the
battery, or damage will occur.)
1
Disconnect Power
Switch OFF
Disconnect Power
TONN/BAT TONN UPS Option or Battery Replacement Installation Instructions TG201133 Issue 2, 12-Jun-2013
TONN UPS or Battery Replacement
TONN/BAT TONN UPS Option or Battery Replacement Installation Instructions
(TG201133)
O
I
Installation Instructions
TONN/BAT
2 Installation .....................................................................1
It is recommended that the installation should comply
with the local electrical safety installation practices (e.g.
HSE Memorandum of Guidance on Electricity at Work
Regulations 1989, USA National Electric Code).
Remove Cover
2
Caution:
This unit contains static sensitive devices.
Suitable anti-static precautions should be
taken throughout this operation to prevent
damage to the unit.
BS EN100015/1
protection of electrostatic sensitive devices.
Basic Specifi cation:
1
