  • Page 1 JetBox 9310 User Manual Demo Box www.korenix.com 0.0.9...
  • Page 2: Copyright Notice

    Korenix assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. Korenix reserves the right to make changes in the product design without notice to its users. Acknowledgments Korenix is a registered trademark of Korenix Technology Co., Ltd.
  • Page 3: Table Of Contents

    Other Functions ................ 11 3-2-2-1 Serial service modes—TCP server ........12 3-2-2-2 Serial service modes—VCOM ..........14 3-2-2-3 DIO Control & Web UI ............18 Chapter 4 Appendix ..................19 Index for Picture, Notice ..............19 Customer Service ................21 Korenix | Overview...
  • Page 4: Chapter 1 Overview

    Korenix Demo Kit is designed to demonstrate Korenix products. In order to let customers understand Korenix product’s features and applications, Korenix produces this portable demo box. In the Demo box, Korenix presents the best results, and impresses customers with product introduction as well as live demonstration.
  • Page 5 You still need to prepare a notebook for the demonstrations. Set a fixed WAN IP for JetBox 9310: 1. Connect your notebook into the JetBox 9310 LAN port 2. Enter the JetBox 9310 Web UI by LAN IP address (Default LAN IP is 192.168.10.1) Open browser. Enter http://192.168.10.1...
  • Page 6: Chapter 3 Demo Box Installation

    Picture 2: Go to Save and press [Save to Flash] to save changes in flash Chapter 3 Demo Box Installation 48V DC power module JetBox 9310 PoE IP Cam JetBox 9310 DIO Control 110~240V demo box power input Picture 3: The overview of the JetBox 9310 demo box Demo Box Installation | Korenix...
  • Page 7: Demo Box Wiring

    Picture 4: The front panel of JetBox 9310 DIO control Notice 1: There is a fuse near the demo box power switch to protect the demo box from the improper current. The power input for the demo box is 110~240V AC.
  • Page 8: Picture 6: Demo Box Wiring Diagram

    3. Connect 10-pin terminal block and the JetBox 9310 DIO 4. Connect 4-pin terminal block and the JetBox power connector 5. Connect the Ethernet port of your notebook and the JetBox 9310 WAN port (Need to set a fixed WAN IP for the JetBox 9310 first)
  • Page 9: Demo Processes

    Notice 2: Please connect power (positive and negative) correctly, otherwise the devices might be damaged. Notice 3: While the JetBox 9310 is booting up, the status of all digital outputs are temporary high. Demo Processes Notice 4: All snapshots are for image reference only, not real settings of demo processes.
  • Page 10: Poe, Routing, Nat & Dmz

    LAN network to WAN network), and NAT & DMZ (your notebook can only access the DMZ server). 3. If you did not set any DMZ server in the JetBox 9310 when NAT function is enabled, the devices in WAN network can only access the Web UI of JetBox 9310 and can’t access the LAN devices.
  • Page 11: Other Functions

    The Ethernet configuration of PoE IP cam is set as follows: IP address: 192.168.10.55 (also set this IP address as DMZ server in JetBox 9310) Subnet mask: 255.255.255.0 Gateway: 192.168.10.1 Video port: under 1000 Picture 9: The frame captured by the PoE IP camera...
  • Page 12: Serial Service Modes-Tcp Server

    JetBox 9310 through TCP server mode Step by step to demo serial modes: 1. Install USB-to-Serial driver in your notebook 2. Enter the JetBox 9310 Web UI by LAN IP address. (Default: 192.168.10.1). Open browser. Enter http://192.168.10.1 User name: admin Password: admin 3.
  • Page 13: Picture 11: Serial Port Configuration| Service Mode Of The Jetbox 9310 Web Ui

    Picture 11: Serial port configuration| Service mode of the JetBox 9310 Web UI 4. Use hyper terminal (named Physical COM) in your notebook to connect with the JetBox 9310 through physical COM (often COM1 or COM2) The physical COM is connected by RJ45-to-DB9 male and USB-to-serial cables.
  • Page 14: Serial Service Modes-Vcom

    Picture 15: The demo diagram of serial service mode—TCP server & VCOm Demo purpose: Use USB-to-Serial cable to simulate a COM port in your notebook and communicate with the JetBox 9310 through VCOM mode. Step by step to demo serial modes: 1. Install USB-to-Serial driver in your notebook 2.
  • Page 15: Picture 16: Add A Vcom In Your Notebook

    For example: COM port number 20, Remote [IP & port] 192.168.10.1, 62004 This is to set a VCOM (COM 20) in your notebook to the JetBox 9310 COM4. Picture 16: Add a VCOM in your notebook Picture 17: the JetBox Virtual COM Commander Picture 18: the JetBox Virtual COM in the device manager 4.
  • Page 16: Picture 19: Serial Port Configuration| Service Mode Of The Jetbox 9310 Web Ui

    COM4. (Refer to the JetBox 9310 user manual to operate.) COM4: set as VCOM mode Picture 19: Serial port configuration| Service mode of the JetBox 9310 Web UI 6. Use hyper terminal (named Physical COM) in your notebook to connect with the JetBox 9310 through physical COM (often COM1 or COM2) The physical COM is connected by RJ45-to-DB9 male and USB-to-serial cables.
  • Page 17: Picture 21: Hyper Terminal Connection-Vcom

    8. Type some words in hyper terminal of physical COM and they show in hyper terminal of Virtual COM. Type some words in hyper terminal of Virtual COM and they show in hyper terminal of physical COM. Picture 22: Key in some words in hyper terminal Korenix | Demo Box Installation...
  • Page 18: Dio Control & Web Ui

    DIs don’t have power to do the demo. Keep DO 0 enabled during this DIO demonstration. Demo Purpose: Control switches and indicators on the demo box front panel though the JetBox 9310 Web UI DIO functions Step by step to demo DIO control and Web UI: 1.
  • Page 19: Chapter 4 Appendix

    Picture 24: DIO configuration| Digital output control in the JetBox 9310 Web UI 4. Check the status of switches (DI) in the JetBox 9310 web UI| DIO configuration| DIO status. Picture 25: DIO configuration| DIO status in the JetBox 9310 Web UI...
  • Page 20 Picture 24: DIO configuration| Digital output control in the JetBox 9310 Web UI ..................... 19 Picture 25: DIO configuration| DIO status in the JetBox 9310 Web UI ..19 Notice (Limitation of this demo box) Notice 1: There is a fuse near the demo box power switch to protect the demo box from the improper current.
  • Page 21: Customer Service

    Customer Service Korenix Technologies Co., Ltd. 9F, No. 100-1, Ming-Chuan Rd., Shing Tien City, Taipei, Taiwan Tel:+886-2-82193000 Fax:+886-2-82193300 Business service: sales@korenix.com Customer service: koreCARE@korenix.com Korenix | Appendix...
