Summary of Contents for TEi Lighting BRAINSPOT250II

  • Page 1: Table Of Contents

    TABLE OF CONTENTS 1.Safety Instruction 2.Technical Specification 85-05275 3.Lamp BRAINSPOT250II 4.How To Set The Unit 4.1 Control Panel 4.2 Main Function 4.3 Home Position Adjustment 5.How To Control The Unit 5.1 Master/Slave Built-In Preprogrammed Function 5.2 Easy Controller 5.3 DMX Controller 5.4 DMX 512 Configuration...
  • Page 2 1. Safety Instruction Warning To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture. Please read care fully the instruction, which includes important Never touch bulb with bare fingers, as it is very hot after using. information about the installation, usage and maintenance.
  • Page 3 2. Technical Specification Luminous intensity: Pow er supply - AC 120V~60Hz or AC 230/240/250V~50/60Hz Light Source - MSD 250W/ NSD 250/2 W - LED: Total 12pcs, Red: 4pcs, Green: 4pcs, Blue: 4pcs Optical syste m - High efficiency optical system Dime nsion: 428 x 369 x 466 mm (L x W x H) - High quality optical lens and dichroic colors...

  • Page 4: How To Set The Unit

    CAUTION! 4. How To Set The Unit Never unscrew the screws of the rotating gobo as the ball bearing 4.1. Control Panel will otherwise be opened! 3. Lamp In case of replacement of the lamp or maintenance, do not open the fixture within 15 minutes until the unit cools down after switching WARNING Because of its high internal pressure, there might be a risk that the Discharge lamp...

  • Page 5: Main Function

    4.2. Main Function Show Mode To select any of the pre-set functions, press the MENU button up to when the required one is shown on the display. Select the function by ENTER button and the display will blink. Use Press the MENU button up to when the is showing on the display.
  • Page 6 ENTER (pan inversion) mode. Once the mode has been selected, press the Display inversion mode for the fixture fixing under ceiling. button to setup. Idling 8 seconds automatically exit menu mode. Back to the functions Focus Adjust without any change press MENU button.

  • Page 7: Home Position Adjustment

    DMX RESET will blink. Use DOWN button to adjust the tilt home position. Once the position has Set DMX value of channel 8 and channel 16 to 255, then all channels of the unit will return been selected, press the ENTER button to setup or automatically return to the offset to their standard home position.

  • Page 8: Easy Controller

    via menu. the functions without any change press the MENU button again. By linking the units in master/slave connection, the first unit will control the other units to Please refer to the following diagram to address your DMX512 channel for the first 4 units. give an automatic, sound activated, synchronized light show.

  • Page 9: Dmx512 Connection

    5.5. DMX512 Connection The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. If you use a controller with 5 pins DMX connector, you need to use a 5 to 3 pin adapter. i.) For DMX reset, put DMX value of CH-8 & CH-16 to 255, the unit will reset after about At last unit, the DMX cable has to be terminated with a terminator.

  • Page 10: Troubleshooting

    5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+) head. 6. Troubleshooting G. If The pan be lt is broken Following are a few common problems that may occur during operation. Here are 1.
  • Page 11 Pay attention to the belt tension when install the belt. F. If The tilt belt is broken Please refer to the photos below: 1. Turn off the main power. 2. Unscrew all the screws (A) and open the right arm cover (B). 3.
  • Page 12 Photo 2 7. Maintenance and Cleaning Maintenance: EC Declaration of Conformity Anti-interference plate Ignitor We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN 55103-1:1996, EN 55103-2:1996, EN 61000-3-2:2006, EN 61000-3-3:1995+A1:2001+A2:2005 Ballast...

This manual is also suitable for:

85-05275
